- Page 1 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Intensifier Series Camera HT-INTB1 HT-INTB2 Please read this manual thoroughly before operation and keep it handy for further reference.
-
Page 3: Table Of Contents
Contents Package Contents Precautions Camera Installation Focusing Features Operating Your Camera * SET UP --------------------------------------------------------------11~12 * SET UP LENS ------------------------------------------------------13~14 * SHUTTER SPEED CONTROL ----------------------------------15~18 * BACK LIGHT--------------------------------------------------------------19 * AUTO GAIN (AGC) -----------------------------------------------------20 * WHITE BALANCE --------------------------------------------------21~22 * REDUCE NOISE---------------------------------------------------------23 * INTENSIFIER-------------------------------------------------------------24 * CAMERA TITLE-------------------------------------------------------25~26 * DAY/NIGHT/SYNC----------------------------------------------------27~28... -
Page 4: Package Contents
PACKAGE CONTENTS Please make sure that the following items are included in the package: 1 HT-INTB CAMERA 1 SUNSHIELD 1 REMOTE CONTROLLER 1 IR RECEIVER 4 MOUNTING SCREWS M2.6 WRENCH (“L" TYPE) 1 VIDEO TEST CABLE 1 POWER CABLE ADAPTOR (for optional use) Please leave this manual with the end-user for future reference. -
Page 5: Camera Installation
CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 600 mA) CONNECT 2. WHEN USING 24 VOLTS AC (40 Volt Amps) POWER RED(+) CONNECT BLACK:(-) 3. CONNECT VIDEO CABLE -CONNECT BNC CABLE TO THE BNC JACK. YELLOW:VIDEO OUT ▣... - Page 6 Features ♣ SLC When the image is in front of strong background lighting, your camera allows you to get the best image. ♣ INTENSIFIER 1/3 inch high density CCD and digital processor permit high quality pictures to be captured in very low light conditions.
-
Page 7: Operating Your Camera
LENS OPTION ●DC ●MANUAL SHUTTER ●OFF ●F/L ●MANUAL WHITE BALANCE ●ATW ●AWC MANUAL● SLC – ( Speco Light Compensation ) ●OFF ●LOW ●MIDDLE ●HIGH Auto Gain ●OFF ●LOW ●MIDDLE ●HIGH REDUCE NOISE ●OFF ●LOW ●MIDDLE ●HIGH INTENSIFIER ●AUTO ●OFF NEXT PAGE ●CAMERA TITEL ●DAY/NIGHT ●SYNC... - Page 8 Operating your camera 1. When controlled by RS-485, Pelco-D protocol (Option), refer to the following. A. DIP Switch Setting on the Camera (Factory default : Camera Address = 01, Baud Rate = 2400bps) ① ② ① RS485 Address Set •Up to 15 Cameras can be controlled by 1 IR Remote Controller &...
- Page 9 Operating your camera 1. Press the SET button to access the SETUP mode. ●SETUP menu is displayed on the monitor screen. 2. Select the desired feature using the UP or DOWN buttons. ●Each time you press the UP or DOWN button, the arrow indicator moves up or down.
- Page 10 Operating your camera – SHUTTER SPEED CONTROL① ▶When DC LENS is selected, press SET button to control the BRIGHTNESS. Notes ●AUTO IRIS LENS (DC TYPE) is recommended 2) Shutter status and speed control You can control brightness of the screen by the shutter speed. ①...
-
Page 11: Shutter Speed Control
Operating your camera – SHUTTER SPEED CONTROL ② ▶MANUAL : When setting the shutter speed manually. ▶ELC : You can control the BRIGHTNESS. You can select speed from ‘1/60’ to ‘1/200,000’sec ③ When completed, press ‘SET’ Notes ●Avoid pointing the camera directly at a fluorescent lamp. ●When the SHUTTER menu is set to FLK mode, the INTENSIFIER will not work. -
Page 12: Backlight
Operating your camera - BACKLIGHT 3) SLC (Speco Light Compensation) - BACKLIGHT A built-in SR chip provides intelligent light level control to overcome severe Backlight conditions. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘SLC’ using the UP or DOWN button. -
Page 13: White Balance
Operating your camera - 5) WHITE BALANCE (WHITE BAL.) ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘WHITE BALANCE’ using the UP or DOWN button. ② Set ‘WHITE BAL.’ to the desired mode using LEFT or RIGHT button. ▶ATW (Auto Tracking White Balance) : When color temperature is 2400~12000K, select this mode. -
Page 14: Reduce Noise
Operating your camera - 6) REDUCE NOISE( Dynamic Noise Reduction) DNR reduces the video noise on the screen. ① Press the SET button to display the SETUP menu and move the arrow to ‘REDUCE NOISE’ using the UP or DOWN button. ②... -
Page 15: Camera Title
Operating your camera – CAMERA TITLE① 8) NEXT PAGE ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘NEXT PAGE’ using the UP or DOWN button. ② SET ‘NEXT PAGE’ to the desired mode using the LEFT or RIGHT button. - Page 16 Operating your camera – COLOR/SYNC (2) COLOR : You can choose color and B/W mode electronically. ① Press the SET button to display the setup menu and move the arrow indicator to ‘COLOR’ using the UP and DOWN button. ② SET ‘COLOR’ to the desired mode using the LEFT or RIGHT button. ▶COLOR : The camera will always display a color picture ▶AUTO : The camera will switch into the B/W mode under low light conditions.
-
Page 17: Motion Detection
Operating your camera – MOTION DETECTION (4) Whenever your camera detects motion, THE WORDS “motion detected’ will appear on the screen. ① Press the SET button to display the setup menu and move the arrow indicator to ‘MOTION’ using the UP and DOWN button. ②... -
Page 18: Privacy
Operating your camera - PRIVACY (5) PRIVACY : To mask an area that you want to be private. ① Press the SET button to display the setup menu and move the arrow to ‘PRIVACY’ using the UP and DOWN button. ②... -
Page 19: Detail
Operating your camera – DETAIL (7) DETAIL ① Press the SET button to display the setup menu and move the arrow indicator to ‘DETAIL’ using the UP and DOWN button. ② SET ‘DETAIL’ to the desired mode using the LEFT or RIGHT button. ▶OFF : Deactivation ▶ON : DETAIL control mode (level 0~31) When the level is up, the sharpness will increase. -
Page 20: Troubleshooting
Troubleshooting If you have trouble operating your camera, refer to the following. Problem Solution Nothing appears on ●Check that the power cord and line connection the screen. between the camera and monitor are proper. ●Check that you have properly connected the VIDEO cables. -
Page 21: Specifications Dimensions
Built - in PRIVACY Function ON / OFF (4 Programmable Zone) Operational Temperature -10℃ ~ +50℃ (14℉ ~122℉) Operational Humidity 30% ~90% RH DIMENSIONS * SIDE VIEW : HT-INTB1 410,000 pixels * SIDE VIEW : HT-INTB2 Speco technologies Speco technologies... -
Page 22: Warranty
WARRANTY...
