Speco CVC-3805TP Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
CVC-745TP
Color Vandal Resistant Dome Camera
with Fixed Lens
Our 1/4" color CCD vandal resistant dome has a 3.6mm fixed lens, an ultra high
impact dome cover and a heavy duty metal base. It is ideal for indoor, as well as
outdoor environments. It features a 1.0 lux with 350 line resolution. This unit
mounts to the ceiling. A B/W version of this camera is available and can be
found under model number CVC-385TP. A varifocal lens version of this camera is
also available, and can be found under model numbers CVC-7405P (Color) and
CVC-3805TP (B/W). Day/Night Operation - The color picture automatically
changes to B/W in low light situations to enhance viewing quality, minimize
video noise and conserve HDD storage space.

Specifications

Resolution
Image Device
Minimum Illumination
Electronic Shutter
Lens
Number of Pixels
Output
Operating Temperature
Humidity
Scanning Frequency
Scanning System
Video S/N Ratio
Video Output
Housing
Power Supply
Dimensions
For more information contact us at:
350 line
1/4" color CCD image sensor
1.0 lux
Auto 1/60 - 1/100,000 seconds
3.6mm fixed lens
512 horizontal 492 vertical
Video-BNC, power-DC jack
-14˚ to 122˚F
Within 95% RH
Horizontal 15.75KHz, Vertical 60Hz
NTSC color 525 line
Greater then 48 dB
1.0 Vp-p 75 ohm
Vandal resistant, weatherproof, ultra high impact
dome cover, heavy duty metal base, black
Regulated 12V DC power supply
included (UL and CSA listed)
5"L x 5"W x 3.5"H
