- Page 1 OPERATION AND SERVICE MANUAL ® HYAMP MODEL 3145 DC GROUND BOND TESTER SERIAL NUMBER Model © Associated Research, Inc., 2013 13860 West Laurel Drive 3145 Lake Forest, Illinois 60045-4546 U.S.A. Item 39411 Ver 1.01 Printed June 3, 2013...
- Page 3 DECLARATION OF CONFORMITY Manufacturer: Associated Research, Inc. Address: 13860 W. Laurel Dr. Lake Forest, IL 60045 ® Product Name: HYAMP III DC Ground Bond Tester Model Number: 3145 Conforms to the following Standards: Safety: IEC61010-1:2010 EN61010-1:2010 EMC: EN61326-1:2006(EN55011:2009+A1:2010 CLASS A, EN61000-3-3:2008, IEC61000-4-2:2008,...
-
Page 5: Table Of Contents
3. SPECIFICATIONS AND CONTROLS ............12 3.1. 3145 Specifications ................. 12 3.2. Instrument Controls ................. 14 3.2.1. Front Panel Controls for 3145 ............14 3.2.2. Rear Panel Controls for 3145 ............15 4. PROGRAMMING INSTRUCTIONS ..............17 4.1. Power Up ....................17 4.1.1. - Page 6 10.2.1...................... Cali bration of Parameters ................... 49 10.2.2...................... Cali bration of Ground Bond DC Current for 3145 ............ 49 10.2.3...................... Cali bration of Ground Bond DC Voltage for 3145 ............ 50 11. REPLACEMENT PARTS LIST ..............51...
-
Page 7: Introduction
5-Year Program All Associated Research instruments include the opportunity to extend the standard warranty for up to a period of 5 years. Returning instruments to Associated Research for their annual calibration and inspection will extend the instrument's warranty for an additional year. -
Page 8: Safety Symbols
Elimination of any connections in the earth grounding system or bypassing any safety systems will void this warranty. This warranty does not cover accessories not of Associated Research, Inc. manufacture. Parts used must be parts that are recommended by Associated Research, Inc. as an acceptable specified part. Use of non-authorized parts in the repair of this instrument will void the warranty. - Page 9 Arc: A partial momentary breakdown due to the force of a strong electric field on closely spaced conductors, sometimes evidenced by corona or a luminous flashover. Breakdown: The failure of insulation to effectively prevent the flow of current. If the test voltage is gradually raised, breakdown will begin suddenly at a certain voltage level and current flow will not be directly proportional to voltage.
-
Page 10: Safety
Reactive Current: The current component due to the reactive impedance of a load. Also called imaginary current. Real Current: The current component due to the resistance of a load. Resistance: The property of a substance that impedes current and results in the dissipation of power in the form of heat. -
Page 11: Test Station
LAKE FOREST, IL 60045-4546 U.S.A. info@asresearch.com E-MAIL: Service Interval Associated Research, Inc. will not be held liable for injuries suffered if the instrument is not properly maintained and safety checked annually. See section 1.1. Warranty Policies for more information. 1.4.2. Test Station... -
Page 12: Test Operator
Power Power to the test station should be arranged so that it can be shut off by one prominently marked switch located at the entrance to the test area. In case of an emergency, anyone should be able to cut off the power before entering the test area to offer assistance. -
Page 13: Key Features And Benefits
are very dangerous. If contacted, the instrument may cause heart-related problems. Please have the test operator consult a physician for recommendations. 1.5. Key Features and Benefits: HYAMP III Provides the operator with an easy-to-use THE FIRST MANUAL interface, eliminating the need to decipher cryptic GROUND BOND abbreviations. -
Page 14: Getting Started
2. GETTING STARTED Introduction This section contains information for the unpacking, inspection, preparation and storage of your Associated Research, Inc., product. 2.1. Unpacking and Inspection 2.1.1. Packaging Your instrument was shipped in a custom foam insulated container. If the shipping carton is damaged, inspect the contents for visible damage such as dents, scratches or a broken display. - Page 15 Please include all accessories and test leads. Mark the container “ FRAGILE” to ensure proper handling. Before shipping, contact an Associated Research, Inc. customer support representative at 1-800-858-TEST (8378) to indicate and explain the reason for service.
-
Page 16: Installation
2.2. Installation 2.2.1. Work Area Locate a suitable testing area and be sure you have read all safety instructions for the operation of the instrument and suggestions on the test area setup in section 1.4. Safety. Make sure the work area you choose has a three-prong grounded outlet capable of supplying the necessary input current to the power source. -
Page 17: Environmental Conditions
The output power supplies of this instrument are referenced directly to earth ground. Any conductor that completes a path between the high voltage and earth ground will form a completed circuit. 2.2.4. Environmental Conditions This equipment is intended for indoor use only. The equipment has been evaluated according to Installation Category II and Pollution Degree 2 as specified in IEC 664. -
Page 18: Specifications And Controls
3. SPECIFICATIONS AND CONTROLS 3.1. 3145 HYAMP III Functional Specifications INPUT 100-120 / 200-230 VAC ± 10%, auto-detection Voltage 50/60 Hz ± 5% Frequency Fuse 10 Amp, slow-blow 250 V AC TEST MODE Output Rating Current: 1.00 – 40.00 Amps DC Resolution: 0.01 Amp/step... - Page 19 GENERAL Remote Control And Signal The following input and output signals are provided Output through two 9 pin D type connectors; 1. Remote control: Test, Reset, Interlock, and Withstand Processing. 2. Remote recall of memory program #1, #2 and #3. 3.
-
Page 20: Instrument Controls
3.2. Instrument Controls 3.2.1. Front Panel Controls for 3145 1. RESET BUTTON: Momentary contact switch used to reset the instrument. If a failure condition occurs during a test, you will need to reset the system to shut off the alarm and signal the system that you are aware of a failure condition. The reset button must be pressed before you can proceed to the next test or change any of the set-up parameters. -
Page 21: Rear Panel Controls For 3145
10. RETURN OUTPUT JACK: Connector used to attach the Return test lead, adapter box, or test fixture to the instrument. 3.2.2. Rear Panel Controls for 3145 1. RS-232 CONNECTOR: 9-Pin D subminiature connector for interconnection to RS- 232 Bus interface. - Page 22 7. REMOTE SIGNAL OUTPUT: 9-Pin D subminiature female connector for monitoring PASS, FAIL, PROCESSING, and RESET output relay signals. 8. REMOTE SIGNAL INPUT: 9-Pin D subminiature male connector for remote control of TEST, RESET, and INTERLOCK functions, as well as remote program memory selection and withstand processing input.
-
Page 23: Programming Instructions
4. PROGRAMMING INSTRUCTIONS 4.1. Power Up The HYAMP III automatically defaults to the Perform Tests screen upon power up. The Perform Tests screen will appear as follows: The Perform Tests screen is the main operational screen of instrument. From this screen, all test parameters are monitored while the test is being performed. -
Page 24: Results, Tests And System Selections
Memory The HYAMP III has 10, 3-step programmable memory locations (M0-M9). Press the “ Memory” soft key to increment the instrument to the desired memory location. As the “ Memory” soft key is pressed, the parameters of the selected memory location are automatically loaded into the instrument. -
Page 25: System Setup
Results Pressing the “ Results” soft key from this menu will allow you to review the test results of the last test performed. An example of a Results screen is shown below. Test Pressing the “ Test” soft key from this menu will allow you to access the Parameter Review screen. -
Page 26: System Setup Soft Keys
You can control your I/O. If you attempt to start a test from the Associated Research, Inc. TEST button on the front panel when the instrument using basic PLC PLC Remote function is turned ON, a pop- inputs and outputs. - Page 27 Refer to the section 6. Connection of Remote I/O for more details. Single Step This function is used to temporarily override the automatic connection feature. When the Single Step function is ON the instrument will pause after each test step is completed.
- Page 28 When P/F is selected, a Pass or Fail screen will be displayed at the end of the test. The Pass and Fail screens will appear as follows: When P/F is selected, it is not possible to see the test results directly at the end of the test.
- Page 29 The Hipot Start parameter is only used when connecting the HYAMP III with an Associated Research Hipot tester. If G→W is selected, the Hipot test will run after the HYAMP III has completed its test. If G + W is selected, the Hipot test will run at the same time as the HYAMP III.
-
Page 30: Default System Parameters
Alert (Alert Date) The Alert Date is like an alarm clock that will warn you in advance of the actual Calibration Due Date. After a calibration is performed, the Alert Date is automatically set for 11 months after the calibration date. For example, if the calibration is performed on 12/15/2002 the Alert Date will automatically be set to 11/15/2003. -
Page 31: Memory, Step, And Default System Parameter Initialization
Single Step Alarm Contrast Results Last Lock Mem Lock Hipot Start G→W Date Format mdy (month, day, year) Cal Alert Alert Date Cal Date + 11 months 4.2.4. Memory, Step, and Default System Parameter Restore Restoring the instrument’ s System parameters will overwrite all memories and steps with ACW default parameters! Press the two bottom soft keys and power the instrument at the same time, then press the soft key next to the word “... -
Page 32: Test Parameters
+/- keys The “ +” and “ -“ soft keys are used to increase or decrease numerical values or toggle settings ON and OFF. Enter key The “ Enter” soft key is used to store a specific value for each test parameter. Edit key The “... -
Page 33: Default Parameters
To automatically set an Offset value, set the current and frequency to the values that will be used on the DUT and connect the test cables or test fixture with fixturing to the instrument. Next, short circuit the ends of the test cables and press the TEST button. The instrument will now read the lead resistance and update Offset parameter automatically. -
Page 34: Operating Instructions
Connect the High Current lead (38489 Heavy gauge wire, red markers) to the Current receptacle on the 3145 HYAMP III, then connect the Kelvin lead (smaller gauge wire... -
Page 35: Adapter Box Connections (Adapter Box Is Sold Separately)
5.1.2. Adapter Box Connections (Optional, for use with 3145 only) The adapter box provides an easy way to connect a DUT to a 3145 HYAMP III that is terminated in a two or three-prong line cord. The following diagram shows how to connect the adapter box to the HYAMP III and to the device under test. -
Page 36: Performing A Test
Remote Interlock feature connect the Interlock Key into the Signal Input port located on the back of the tester. 5.2. Performing a Test 1. From the Main Menu, select the memory and step you wish to perform then press the “ Exit” soft key to return to the Perform Tests screen. 2. -
Page 37: Error Messages
NOTE: For multi-step tests, use the “ ∧” and “ ∨” soft keys to scroll through the results. 5.5. Error Messages While performing tests a number of messages will be displayed to indicate the test state or test results. These messages are displayed in the status area of the screen located on the first line at the top of the LCD. - Page 38 Interlock Open: This message appears on the display if the Remote Interlock feature is activated before or during a test. See section 6.2. Remote Signal Inputs and Memory Access for more information. Out-Error: This message appears on the display if the instrument has an internal problem and the TEST button is pressed.
-
Page 39: Connection Of Remote I/O
6. CONNECTION OF REMOTE I/O Two 9 pin D-type connectors mounted on the rear panel provide REMOTE-INPUT- OUTPUT control and information. These connectors mate with a standard 9 pin D- type subminiature connector provided by the user. The output mates to a male (plug) connector while the input mates to a female (receptacle) connector. - Page 40 The Hipot Start parameters main purpose is to control the sequential timing between HYAMP III and a connected Associated Research Hipot. The parameter controls if the Hipot will run after the HYAMP III has completed its test, G→W, or if the Hipot will...
-
Page 41: Signal Inputs Of Remote I/O And Memory Access
6.2. Remote Signal Inputs and Memory Access The HYAMP III remote connector enables remote operation of the TEST, RESET, and REMOTE INTERLOCK functions, and allows the operator to select Memory Location 1, 2, and 3. When the PLC Remote mode is on, the HYAMP III will respond to simple switch or relay contacts closures. - Page 42 Memory Location 3 – Momentarily connecting terminal 7 to terminals 8 and 9 signals the instrument to immediately begin the test program that is stored in Memory Location 3. Remote Interlock HYAMP III is equipped with a Remote Interlock feature. Remote Interlock utilizes a set of closed contacts to enable the instrument’...
- Page 43 If the Hipot start signal is set to G+W then a small “ W-T” indicator will appear in the upper right of the display. PLC Remote Pop-up message If you attempt to start a test from the front panel TEST button and the PLC remote function is turned “...
-
Page 44: Hyamp Iii Connected To Hypot Iii
Both front and rear connections may be used to connect the adapter box and interconnect. If you order the 3145 HYAMP III interconnect kit you will receive the following items: INTERCONNECT KIT FOR 3140 ONLY, AR PART #260-03 Part Number Description Qty. - Page 45 The Hipot Start parameter is only used when connecting the HYAMP III with an Associated Research Hypot III. The parameter determines if the Hipot will run after the HYAMP III has completed its test, G→W, or if the Hipot will run at the same time as the HYAMP III, G + W.
-
Page 46: Bus Remote Interface
7. BUS REMOTE INTERFACE RS-232 Interface The RS-232 cabling should be configured as follows for a 9-pin serial port interface: Instrument RS-232 Port PC / Bus Controller The COM port should have the following configuration: 19200 baud 8 data bits 1 stop bit No parity This interface does not support XON/XOFF protocol or any hardware handshaking. - Page 47 The following conventions are used to describe the commands syntax for the HYAMP III. Braces ({ }) enclose each parameter for a command string. Triangle brackets (< >) indicate that you must substitute a value for the enclosed parameter. The Pipe ( | ) is used to separate different parameter options for a command.
- Page 48 SALL <memory+step, p1, p2, p3… > This command edits all parameters in a memory and step. Parameters will be edited at the step location that has been selected. Example: SALL<11,10.00,100,0… > The parameter <memory+step> indicated the memory and step number. The parameters <p1,p2>...
- Page 49 SSTP {1|0} Single Step ON/OFF 1=On, 0=Off ALAR <value> Alarm Level 0-9, 0=Off, 9=High CNTR <value> Contrast Level 0-9, 9=High RLT {L|A|P} Result Setting L=Last, A=All, P=P/F HS {1|0} Hipot Start 0=GàW, 1=G+W Query Commands These query commands will retrieve data from the instrument. These commands include functions for retrieving test data, test results and remote hardware.
- Page 50 Read the remote Reset input signal. When the remote reset has be activated by closing the contacts the query will return a value of 0 to indicate the instrument is being Reset. Read the remote Interlock input signal. When the remote Interlock has be activated by opening the contacts the query will return a value of 1 to indicate the instrument is in the Interlock state and will not be able to generate output voltage or current.
-
Page 51: Options
On the rear panel of the instrument, you will find a label that contains the option code. For example, your options code would appear as follows: Fitted with option 04 ..........OPT: 04 Fitted with option 01and04........OPT: 0104 HYAMP III Options Model 3145 does not include any options. ____________________________________________________________________________... -
Page 52: Instrument Verification
9. INSTRUMENT VERIFICATION Verification is the process by which an instrument’ s failure detectors are proven to be functioning properly by performing basic tests in open and short circuit conditions. Verifying the failure detection circuitry of the electrical safety tester is required by safety agencies such as CSA, UL, and TÜV. - Page 53 Ground Bond Verification From the Verification screen, press the TEST button to begin the verification process. At the end of the Verification process, a message will appear indicating the outcome of the process. If the instrument passes the Verification (test failure, indicating the fail detectors are working properly) the RESET button will illuminate, the alarm will sound and the following message will appear: If the instrument fails the Verification (test pass, indicating the fail detectors are not...
-
Page 54: Calibration Procedure
Associated Research, Inc. offers a standard one-year manufacturer’ s warranty. This warranty can be extended an additional four years provided that the instrument is returned each year to Associated Research, Inc. for its annual recertification. In order to be eligible for the extended warranty instruments must be returned to Associated Research, Inc. -
Page 55: Bration Of Parameters
Adjust the numeric value of the parameter using the “ +” and “ -” soft keys and press the “ Enter” soft key to accept the new parameter or press RESET to escape the edit. 10.2.2. Calibration of Ground Bond DC Current for 3145 ____________________________________________________________________________... -
Page 56: Cali
10.2.3. Calibration of Ground Bond AC Voltage for 3145... -
Page 57: Replacement Parts List
11. REPLACEMENT PARTS LIST Rev. B 04/28/04 ECO 5034 3145 Part Reference Qty. Description Number Designator Supplied Accessories 38503 Fuse, 10 Amp slow-blow 250VAC 38489 Cable HC Current 2Wire MC 40A 38490 Cable HC Return 2Wire MC 40A 38075 Interlock Connector... -
Page 58: Schematic Index
12. SCHEMATIC INDEX DRAWING REFERENCE DESCRIPTION PAGES NUMBER DESIGNATOR S03145 Wiring Diagram 3145 S39405 Main Control Board CONM001 S39406 DC to DC Converter Board DDCSD140 S39407 Analog Board ANGSD140 S39412 Keypad Board KEYSD140 S39408 Input Power Board PWRSD130 RS-232 Interface... - Page 59 Index Adapter Box ..................14, 15, 30, 39, 47 Arc .......................... 3, 28 Benefits ......................... 8 Breakdown ........................ 3, 4 Calibration ....................9, 23, 24, 44 Calibration Alert Alert Date ........................23, 24 Cal Alert ......................19, 23, 24, 25 Cal Date ........................
- Page 60 Test Parameters ..................8, 13, 17, 19, 26 PLC ......................19, 20, 25, 36 Power ........................4, 6, 10 Power Factor......................... 4 Programming ......................17 Rear Panel Controls ....................10, 15 Receptacle ......................15, 34 Regulation ........................12 Remote ....... 8, 13, 16, 19, 20, 21, 25, 30, 33, 34, 35, 36, 37, 38, 40, 42 Remote Interlock ..................
