Quick Start Guide

SAFETY CHECKLIST

S
urvey the test station. Make sure it is safe & orderly.
A
lways keep unqualified/unauthorized personnel away from the test area.
F
amiliarize yourself with safety protocols in the event of a problem.
E
xercise caution and never touch products or connections during a test.
T
rain operators. Never touch clips directly and always connect the return lead first.
Y
ou should always know when a test is being performed.
WARNING: THIS GUIDE WAS CREATED FOR OPERATORS HAVING SOME FAMILIARITY WITH ELECTRICAL SAFETY
TESTING. AN ELECTRICAL SAFETY TESTER PRODUCES VOLTAGES AND CURRENTS THAT CAN CAUSE HARMFUL
OR FATAL ELECTRIC SHOCK. TO PREVENT ACCIDENTAL INJURY OR DEATH, THESE SAFETY PROCEDURES MUST
BE STRICTLY OBSERVED WHEN HANDLING AND USING A TEST INSTRUMENT. CONTACT US AT
INFO@ARISAFETY.COM FOR MORE INFO ON HOW TO GET TRAINED ON ELECTRICAL SAFETY TESTING.
Hypot
Models 3705, 3765, 3770 and 3780
III
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYPOT III 3705 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Associated Research HYPOT III 3705

  • Page 1 Quick Start Guide Hypot ® Models 3705, 3765, 3770 and 3780 SAFETY CHECKLIST urvey the test station. Make sure it is safe & orderly. lways keep unqualified/unauthorized personnel away from the test area. amiliarize yourself with safety protocols in the event of a problem. xercise caution and never touch products or connections during a test.
  • Page 2 INSTRUMENT SETUP WARNING: LOCATE A SUITABLE TESTING AREA WITH A THREE-PRONG, GROUNDED OUTLET. BE SURE THAT YOUR THREE-PRONG OUTLET HAS BEEN TESTED FOR PROPER WIRING. READ THE SAFETY CHECKLIST OF THIS GUIDE BEFORE STARTING TO TEST.  Select the correct input line voltage on the rear panel of the instrument, either 115 VAC or 230 VAC.
  • Page 3 EDIT SYSTEM PARAMETERS Configure the instrument system parameters to your preferences. The instrument system parameters are global and will affect all tests that you perform regardless of memory location and memory step. Settin g s M0-1 M0-1 Menu Menu Menu M1-1 0.0s Settin g s...
  • Page 4 EDIT TEST PARAMETERS You may configure your test routine by following the outlined steps: Settin M0-1 Menu Menu Settin g s M1-1 0.0s ______________ ____________ START Memory O.0OkV 10.OOuA Step O.O00mA 1.Os Exit From the Perform Test screen, Select the MENU soft key again. select the MENU soft key.
  • Page 5 TEST CONNECTION WARNING: DO NOT TOUCH THE DEVICE UNDER TEST ONCE YOU START THE TEST. Adapter Box Connections To increase operator safety, you may elect to use an adapter box for products terminating in either a two-prong or three-prong line cord. Note: Be sure to enable the Ground Continuity check before moving forward (see page 3).
  • Page 6 TEST CONNECTION WARNING: DO NOT TOUCH THE DEVICE UNDER TEST ONCE YOU START THE TEST. DUT Connections Connect the clip end of the return lead (P/N 2100A-13) to the exposed or  dead metal of the chassis of the DUT. Always connect the ground return clip first and double check that it has a solid connection to the DUT.
  • Page 7 CONDUCT A TEST Connect the Interlock Disable Key (P/N 38075) to the signal input  connector on the rear panel of the instrument. If you’re not utilizing a DUT enclosure (P/N 39064 or 39656) or other safety device, the Interlock Disable Key is required in order to run a test.
  • Page 8 ® For additional information about these and other key features of the Hypot III, please consult the ® full Operation and Service Manual or call us toll-free 1-800-858-TEST (8378) or +1-847-367-4077 © 2017 Associated Research arisafety.com • FOLLOW US! 3/2017...
