Quick Start Guide
SAFETY CHECKLIST
S
urvey the test station. Make sure it is safe & orderly.
A
lways keep unqualified/unauthorized personnel away from the test area.
F
amiliarize yourself with safety protocols in the event of a problem.
E
xercise caution and never touch products or connections during a test.
T
rain operators. Never touch clips directly and always connect the return lead first.
Y
ou should always know when a test is being performed.
WARNING: THIS GUIDE WAS CREATED FOR OPERATORS HAVING SOME FAMILIARITY WITH ELECTRICAL SAFETY
TESTING. AN ELECTRICAL SAFETY TESTER PRODUCES VOLTAGES AND CURRENTS THAT CAN CAUSE HARMFUL
OR FATAL ELECTRIC SHOCK. TO PREVENT ACCIDENTAL INJURY OR DEATH, THESE SAFETY PROCEDURES MUST
BE STRICTLY OBSERVED WHEN HANDLING AND USING A TEST INSTRUMENT. CONTACT US AT
INFO@ARISAFETY.COM FOR MORE INFO ON HOW TO GET TRAINED ON ELECTRICAL SAFETY TESTING.
HypotULTRA
Models 7804 and 7854
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HypotULTRA 7804 and is the answer not in the manual?

Questions and answers

Related Manuals for Associated Research HypotULTRA 7804

Summary of Contents for Associated Research HypotULTRA 7804

  • Page 1 Quick Start Guide HypotULTRA ® Models 7804 and 7854 SAFETY CHECKLIST urvey the test station. Make sure it is safe & orderly. lways keep unqualified/unauthorized personnel away from the test area. amiliarize yourself with safety protocols in the event of a problem. xercise caution and never touch products or connections during a test.

  • Page 2: Instrument Setup

    INSTRUMENT SETUP WARNING: LOCATE A SUITABLE TESTING AREA WITH A THREE-PRONG, GROUNDED OUTLET. BE SURE THAT YOUR THREE-PRONG OUTLET HAS BEEN TESTED FOR PROPER WIRING. READ THE SAFETY CHECKLIST OF THIS GUIDE BEFORE STARTING TO TEST. Connect the female end of the power input plug into the rear of the instrument and plug the male end of the cord into a grounded power source.

  • Page 3: Touch Screen Operations

    TOUCH SCREEN OPERATIONS Test Back Home Screen TOUCH Tap the virtual buttons to open various functions. SWIPE UP, DOWN, LEFT & RIGHT Simple gestures allow you to quickly move through screens & parameters. DRAG & DROP Simply touch and hold the test file, test step, or parameter and drag the file to the appropriate...

  • Page 4: Test Setup

    TEST SET UP TAP SETUP TESTS TAP ADD FILE ADD FILE NAME Home Screen File Screen Tap the ENTER ( ) key to save your selection TAP ADD STEP TAP TEST SETTING EDIT PARAMETERS Add Step Tap the test parameter you would like to edit.

  • Page 5: Test Connection

    TEST CONNECTION ADAPTER BOX CONNECTIONS (7804/7854) The adapter box (P/N 38482) provides an easy way to connect the HypotULTRA ® a device under test (DUT). Note: If you are testing a Class I product, safety agencies may require you to perform a Ground Bond test on the ground circuit of the DUT along with the Hipot test.

  • Page 6: Test Connections

    TEST CONNECTIONS WARNING: DO NOT TOUCH THE DEVICE UNDER TEST ONCE YOU START THE TEST. TEST LEAD CONNECTIONS Plug the black return lead (P/N 38490) into the Return terminal. Plug black sense lead into the Sense (-) terminal. Attach the clip-terminated end of the return lead to the dead metal on the chassis of the DUT.

  • Page 7: Perform Tests

    PERFORM TESTS TAP PERFORM TAP THE PUSH THE TESTS TEST SCREEN TEST BUTTON BUTTON RESULTS After a test has completed, the Results icon will be available on the screen. Tap RESULTS to view your test results. Tap “Present test step” to view Tap “Last”...
  • Page 8 Safety Is Our Only Focus ® For additional information about these and other key features of the HypotULTRA , please consult the ® full Operation and Service Manual or call us toll-free 1-800-858-TEST (8378) or +1-847-367-4077 © Associated Research arisafety.com • FOLLOW US! 1/2018...
