- Page 1 Manual for installation, use and maintenance MS200 Single Oven year parts 1 year labour guarantee www.matrixappliances.co.uk...
-
Page 2: Table Of Contents
Contents: Important information Important notes Recommendations and steps before first use Control panel and using your appliance Cleaning and maintenance Removing the appliance door Replacing the appliance door Removing the inner door glass Changing the oven lamp Installation Mains electrical connection Troubleshooting Energy efficiency information doors) - Page 3 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
-
Page 4: Important Information
Parts intended to come into contact with food conform to 1935/2004/ IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. - Page 5 • Do not grill food containing fat without using the grill pan grid. • Do not cover the grill pan grid or the oven walls with aluminium foil. • Do not use the oven tray for roasting. • Do not perform maintenance or cleaning of the oven without first switching off the electricity supply.
- Page 6 15 minutes of full grill 30 minutes of fan oven Please note: • This oven has been fitted with a cooling fan to achieve maximum efficiency and to maintain low surface temperatures. The cooling fan will switch on automatically when the oven switches on. It is normal for the cooling fan to run for an hour or more after use, depending on the duration, temperature and type of cooking programme used.
- Page 7 Control Panel fig.1 Control panel: A. Temperature control knob D. Menu sensor B. Timer display E. Timer ‘Right’ sensor C. Timer ‘Left’ sensor F. Function control knob Oven Controls and Use Temperature knob • To set the temperature, turn the temperature knob clockwise to the required temperature.
- Page 8 Eco fan oven This function provides the most ecomonical method for cooking food. It is similar in operation to the fan oven function below. However, cooking times may be longer. Fan Oven Using the circular element and the fan with a temperature between 50°C and 250°C, this cooking function blows the air into and around the oven cavity.
- Page 9 For each grill function please note: • Always grill with the oven door closed. • Put the grill pan as close to the grill as possible. • Do not grill for more than 30 minutes at a time. • Preheat the grill for up to five minutes with the oven door closed. Internal shelf positions The shelves and grill pan can be inserted into any one of five different positions.
- Page 10 Setting the minute minder function The minute minder function can be set at any time, regardless of the state of activity of the oven. The minute minder can be set anywhere from 1 minute to 23 hours and 59 minutes. •...
- Page 11 To switch on semi-automatic cooking • Set the desired oven function and temperature. • Press the menu sensor until the display illuminates the symbol and the timer display shows ‘dur’. • Set the required cooking time using the timer left and right sensors. The cooking time that can be set ranges from between 1 minute and 10 hours.
- Page 12 To switch on automatic cooking • Press the menu sensor until the display illuminates the symbol and the timer display shows ‘dur’. • Set the required cooking time using the timer left and right sensors. The cooking time that can be set ranges from between 1 minute and 10 hours.
-
Page 13: Cleaning And Maintenance
Cleaning and maintenance Keeping your oven clean and well maintained helps to prolong the fault-free lifespan of it. It is important that, before any cleaning or maintenance is performed, you switch off the oven at the mains supply. Do not start any cleaning or maintenance until the oven has been allowed to cool completely. -
Page 14: Removing The Appliance Door
IMPORTANT: • Steam cleaners must not be used when cleaning this appliance. • Once care and maintenance is complete, ensure that all parts are correctly replaced before using the oven. Removing the appliance door In order to allow for easier access into the oven cavity for cleaning, it is possible to remove the door. -
Page 15: Replacing The Appliance Door
Replacing the appliance door • Hold the door to the appliance in the closed position and manoeuvre the hinges so that the part of the hinge, highlighted by the star in fig. 3, inserts into the hinge slot in the cavity frame. •... -
Page 16: Removing The Inner Door Glass
Removing the inner door glass With the door removed, the inner glass can also be taken out for cleaning purposes. • Use a flathead screwdriver or to unhook the door slat, as shown in fig. 5 • Remove the door slat, as per fig. 6, and place it somewhere safe where it will neither receive nor cause damage. - Page 17 • removed. There are a number of rubber guides attached to the inner pane and these must be returned to their original positions when reassembling the door. Fig. 7 shows these guides and their position on and around the inner glass. •...
-
Page 18: Changing The Oven Lamp
Changing the oven lamp Important: Before any maintenance is started involving electrical parts, the appliance must be disconnected from the power supply. If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. Never use screwdrivers or other utensils to remove the light cover. -
Page 19: Installation
Installation The installation of this appliance must be carried out by a suitably qualified person. If the oven is being installed into a built under oven housing unit ensure that the front rail at the top of the unit is not installed as it could restrict ventilation. -
Page 20: Mains Electrical Connection
The oven is designed to fit into a cabinet of 600mm width. The oven can be built in or built under the kitchen units, but you must ensure that it is properly ventilated. In the diagram below the built-in oven is ventilated by means of a space at the top of the kitchen cabinet. - Page 21 3mm in all poles and protected by a 13a fuse. The switch must be positioned no further than 2m from the appliance. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T.
-
Page 22: Troubleshooting
specialised personnel. • When installing this product we recommend you seek the help of another individual. • Should the mains cable be damaged or need to be replaced, it should only be done so by a qualified electrician or engineer. The terminal block on the appliance is clearly marked with regards to the positions of live, neutral and earth. -
Page 23: Energy Efficiency Information
Energy Efficiency Information Model c i f MS200/1 Mass of the i l p Number of i t i Heat source per cavity (electricity or c i r y t i Volume per y t i Energy consumption (electricity) required to... - Page 24 Serviced by For our Customer Care Department, or for Service, please contact us on: The CDA Group Ltd. Harby Road, Langar, Nottinghamshire, NG13 9HY Tel: 01949 862012 Fax: 01949 862003 Email: customer.care@cda.eu...
