- Page 1 Manual for installation, use and maintenance MD721 & MD921 Built-Under and Built-In Double Ovens year parts 1 year labour guarantee www.matrixappliances.co.uk...
- Page 2 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
- Page 3 Parts intended to come into contact with food conform to 1935/2004/ IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
-
Page 4: Before First Use
• Do not grill food containing fat without using the grill pan grid. • Do not cover the grill pan grid or the oven walls with aluminium foil. • Do not use the oven tray for roasting. • Do not perform maintenance or cleaning of the oven without first switching off the electricity supply. - Page 5 For the upper oven: 15 minutes of full grill 30 minutes of conventional oven For the lower oven: 60 minutes of fan oven Please note: • This oven has been fitted with a cooling fan to achieve maximum efficiency and to maintain low surface temperatures. The cooling fan will switch on automatically when the oven switches on.
-
Page 6: Oven Controls And Use
Oven Controls and Use Cooking function knob To set the function, turn the cooking function knob for the required oven clockwise to the required function. Each of the oven functions uses different elements within the oven to offer you the best choice of cooking every time. - Page 7 Oven Lamp This function switches on the oven light in the cavity. Please note: the oven light will operate on all cooking functions. Defrost Using the fan only this oven function circulates the air around the oven cavity, speeding up the natural defrost process (1kg takes approximately one hour, depending on the type of food).
-
Page 8: Programming The Oven
Programming the Oven Please note: • The semi-automatic and automatic cooking programmes will only work with the main oven. • The alert beep will cut off after 1. Cooking time indicator two minutes if it is not switched off 2. End of cooking time indicator manually. - Page 9 The minute minder The minute minder can be used when the oven is switched on or off. It can be set for up to 23 hours and 59 minutes. To set the minute minder: • Touch repeatedly until the minute minder indicator flashes. •...
- Page 10 Automatic and semi-automatic cooking The oven can be set for semi-automatic cooking where the oven is programmed to switch off at a specific time, and for automatic cooking, where the oven is set to switch on and off at specific times. To set a semi-automatic programme •...
- Page 11 • Then touch to select the required end of cooking time. When the correct time shows on the display, wait for approximately five seconds. The cooking time and end of cooking time indicators will remain lit to confirm the automatic programme is on. •...
-
Page 12: Care And Maintenance
Care and Maintenance IMPORTANT Before any maintenance is started, the appliance must be disconnected from the power supply. If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. The oven exterior As the oven has a stainless steel or enamel surface, you should use a nonabrasive cleaner. -
Page 13: Changing The Oven Lamp
IMPORTANT: • Steam cleaners must not be used when cleaning this appliance. • Once care and maintenance is complete, ensure that all parts are correctly replaced before using the oven. Changing the Oven Lamp Before any maintenance is started, the appliance must be disconnected from the power supply. -
Page 14: Oven Door
IMPORTANT Never replace the bulb with bare hands as contamination from your fingers can cause premature failure. Always use a clean cloth or gloves. Please note: fig. 3 The bulb replacement is not covered by your guarantee. Oven Door Removing the Oven Door fig. -
Page 15: Installation
Installation Important Failure to allow adequate ventilation to the appliance may result in overheating or damage to adjacent units and could invalidate the warranty. The diagram below shows the minimum required. This appliance is type X installation. The walls of the kitchen units must be able to withstand temperatures of 75 °... - Page 16 MD921 MD720 MD721 MD920 Dimen- Oven Housing Dimen- Oven Housing sions sions Height Height (mm) (mm) Width Width (mm) (mm) Depth (min) Depth 560 (min) (mm) (mm) 30-50 MD720 MD721 MD921 = airflow end support panels 720 min = airflow fig.
-
Page 17: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed To connect this appliance to a UK standard mains supply, connect the bridging links between 1-2-3 for the live feed and 4-5 for the neutral feed. Ensure all terminals are tightened. We recommend that the appliance is connected by a qualified electrician, who is a... - Page 18 Tighten the cable clamp securely and close the connector cover. Green and Yellow = Earth (PE) Blue = Neutral Brown = Live Please note: • The mains cable must only be replaced by a qualified electrician or service engineer and must be of equivalent or better rating (i.e. 2.5mm , HO5RR-F).
-
Page 19: Troubleshooting
Troubleshooting If you have any problems with your appliance, you should check the troubleshooting prior to calling CDA Customer Care, to prevent unnecessary service calls and potential cost. Contact details for CDA Customer Care are on page 20 and the rear cover of this manual. - Page 20 A function is on and the internal light is not working It’s most likely that the bulb has blown. Switch the appliance off at the mains power supply and fit a replacement bulb that matches the bulb specification laid out on page 13. If any of the previous steps do not resolve your issue, please contact CDA Customer Care to arrange a repair.
- Page 21 NOTES:...
- Page 22 NOTES:...
- Page 23 Energy Efficiency Information Value Model c i f Mass of the i l p Number of i t i Heat source per cavity (electricity or gas) Electricity Electricity Volume per y t i Upper: 34 Lower: 50 Lower: 59 Energy consumption (electricity) required to Upper: 0.66 Upper: 0.66 kWh/cycle...
- Page 24 Serviced by For our Customer Care Department, or for Service, please contact us on: The CDA Group Ltd. Harby Road, Langar, Nottinghamshire, NG13 9HY Tel: 01949 862012 Fax: 01949 862003 Email: customer.care@cda.eu...
