Summary of Contents for Euro Appliances ER90UMBG
- Page 1 U S A G E A N D C A R E G U I D E PRODUCT CODE: ER90UMBG...
-
Page 2: Table Of Contents
Content Safety instructions Installation Start using your cooker hood Troubleshooting Maintenance and cleaning Environment protection... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS This manual explains the proper installation and use of your cooker hood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. Never to do: After installation, of a range hood or other cooking fume extractor, the... - Page 4 Always to do: Always to do: • Caution: The appliance and its • Always put lids on pots and pans accessible parts can become hot when cooking on a gas cooker. • When in extraction mode, air in the during operation. Be careful to avoid touching the heating elements.
-
Page 5: Installation
INSTALLATION (VENT OUTSIDE) MOUNTING OF THE V-FLAP If the cooker hood does not have an assembled V-flap 1, you should mount the half-parts to its body. The images only show an example of how to mount the V-flap, because the outlet may vary according to different models and configurations. To mount the V-flap 1 you should: •... - Page 6 4. Fix the expansion pipe on the outlet with cable tie. Note: the expansion pipe is not included in the product. See Pic 3 WARNING: • For safety reason, please use only the same size of fixing or mounting screws which are recommended in this instruction manual.
-
Page 7: Start Using Your Cooker Hood
Start Using Your Cooker Hood LED touch control LED touch control has five buttons, see picture. (Decrease), (Increase), (Lamp), (Timer), (Power) 1. Power-on: After connecting the cooker hood to the main supply, the backlight of button will turn on, output will be closed and the cooker hood will enter into stand- by mode. -
Page 8: Troubleshooting
( Decrease) button Press (Decrease) button, the cooker hood will decrease one speed, and the display will show the current working speed. When press (Decrease) button again when it is working on the low speed, the cooker hood will turn off and the backlight of (Decrease) button will be off. -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING Caution: • Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the mains power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. • External surfaces are susceptible to scratches and abrasions, so please follow the cleaning instructions to ensure the best possible result is achieved without damage. - Page 10 INSTALLING GREASE MESH FILTERS To install filters for the following four steps: • Angle the filter into the slots at the back of the hood • Push the button on the handle of the filter • Release the handle once the filter fits into a resting position •...
- Page 11 BULB REPLACEMENT Important • Always switch off the electricity supply before carrying out any operations on the appliance. When handling bulb, make sure it has completely cooled down before any direct contact with hands. • When handling bulbs hold with a cloth or gloves to ensure perspiration does not come in contact with the bulb as this can reduce the life of the bulb.
-
Page 12: Environment Protection
ENVIRONMENTAL PROTECTION This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/EU. - Page 13 Pronto Service + Support: 1800 440 335 Email: service@eurostylegroup.com.au HEAD OFFICE 65 Glynburn Road, Glynde SA 5070 Ph: 08 8165 1012 www.euroappliances.com.au...
