More options

Pause
Pauses the image, allowing you to examine the image in detail.
The pause function stops the echosounder from pinging. The system is not collecting data
when paused in this manner.
Range Lines
Range lines can be added to the image to make it easier to estimate distance.
Recording SideScan data
Displays the record log dialog. SideScan data can be recorded by selecting the correct file
format (xtf) in the record dialog. For more information, refer to "Recording log data" on page 70.

Echosounder settings

Use the echosounder settings dialog to make settings to your echosounder system. Refer to
"Echosounder settings" on page 78.
