Important safety instructions:
Please read carefully all instructions before assembly.
For your safety and ease, assembly by two or more adults is recommended.
Keep instructions for future use.
Pre-assembly:
Do not discard any content until assembly is complete to avoid accidentally discarding small parts or hardware.
Take out all parts and hardware from box.
Parts List
Description
Item
P1
Table top
Leg Frame
P2
P3
Stretcher Frame
Height
Gathering
P4
Connector
Hardware List
Description
Item
H1
Bolts Ø5/16"x30mm
H2
Hex Bolts Ø5/16"x80mm
H3
Bolts Ø5/16"x85mm
H4
Lock Washers Ø5/16"
H5
Flat Washers Ø5/16"x19mm
Wrench
H6
12mm
H7
Allen Key 4mm
DISCLAIMER:
WHEN PROPERLY ASSEMBLED, THIS ITEM IS SAFE FOR INTENDED USE. SELLER IS NOT LIABLE FOR ANY DAMAGES
RESULTING FROM ITEM BEING IMPROPERLY ASSEMBLED AFTER PURCHASE.
Assembly Procedures:
Step1: Assemble the table on a flat, soft surface such as a carpet or cloth to prevent scratching the finish.
Attach the Leg Frame (P2) to Stretcher Frame (P3) as shown below.
(H2)x4
Hex Bolts Ø5/16"x80mm
(H4)x4
Lock Washers Ø5/16"
(H5)x4
Flat Washers Ø5/16"x19mm
Wrench
12mm
(H6)x1
H6
H5
H4
H2
ASSEMBLY INSTRUCTIONS
Description: LANCASTER WOODEN GATHERING TABLE
Please follow step1~2 for Dining table Assembly.
QTY
1
2
1
2
QTY
8
4
4
16
16
1
1
P2
Page 1 of 3
P2
P3
