Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
MT07G
MT07AG
1WS-28199-2A

Advertisement

Table of Contents
loading

Related Manuals for Yamaha MT-07M 2015

Summary of Contents for Yamaha MT-07M 2015

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MT07G MT07AG 1WS-28199-2A...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the MT07G / MT07AG, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 MT07G / MT07AG OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, November 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 Luggage strap holders ....4-24 Valve clearance......7-15 Sidestand ........4-24 Tires ..........7-16 Safety information......2-1 Ignition circuit cut-off system ..4-25 Cast wheels ........7-18 Auxiliary DC connector ....4-27 Adjusting the clutch lever free Description ........
  • Page 7 Table of contents Battery ...........7-29 Replacing the fuses.......7-31 Replacing the headlight bulb..7-32 Replacing the auxiliary light bulb ..........7-34 Brake/tail light .......7-35 Replacing a turn signal light bulb ..........7-35 Replacing the license plate light bulb ..........7-36 Supporting the motorcycle....7-36 Front wheel (for non-ABS models) ........7-37 Rear wheel (for non-ABS models) ........7-38...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 : 2 5 0 kPa , {2. 50 k gf /c m ²}, 36 ps i 1TP-21668-00 4 MT07G 4 MT07AG STATIONARY NOISE TEST INFORMATION STATIONARY NOISE TEST INFORMATION TESTED 91 dB(A) 4500 r/min TESTED 90 dB(A) 4000 r/min SILENCING SYSTEM : YAMAHA SILENCING SYSTEM : YAMAHA IDENTIFICATION : 1WS IDENTIFICATION : 1WS 1WS-2118G-20 1WS-2118G-10...
  • Page 10 Location of important labels 5 MT07G 5 MT07AG 39R-00 9639 39R-00 9640 41R-04 9604 41R-04 9593 53R-01 0716 53R-01 0716 78R-03 5068 78R-03 5068 1WS-2811P-10 1XB-2811P-00...

  • Page 11: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 12 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 13 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 14 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 Safety information  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 16: Description

    Description EAU10411 Left view 1. Seat lock (page 4-19) 9. Coolant reservoir (page 7-11) 2. Storage compartment (page 4-22) 3. Owner’s tool kit (page 7-2) 4. Shift pedal (page 4-14) 5. Engine oil filler cap (page 7-9) 6. Engine oil drain bolt (page 7-9) 7.

  • Page 17: Right View

    Description EAU10421 Right view 1. Fuses (page 7-31) 9. Rear brake fluid reservoir (page 7-21) 2. Battery (page 7-29) 3. Shock absorber assembly spring preload adjusting ring (page 4-23) 4. Fuel tank cap (page 4-16) 5. Headlight (page 7-32) 6. Coolant drain bolt (page 7-12) 7.

  • Page 18: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-14) 2. Left handlebar switches (page 4-13) 3. Multi-function meter unit (page 4-6) 4. Main switch/steering lock (page 4-2) 5. Front brake fluid reservoir (page 7-21) 6. Right handlebar switches (page 4-13) 7.

  • Page 19: Instrument And Control Functions

     Do not expose any key to exces- cess, take the vehicle along with all three keys to a Yamaha dealer to have sively high temperatures.  Do not place any key close to them re-registered. Do not use the key with the red bow for driving.

  • Page 20: Main Switch/Steering Lock

    Instrument and control functions  Keep other immobilizer system EAU10474 EAU38531 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 21 Instrument and control functions EAU1068A ECA20760 LOCK NOTICE The steering is locked and all electrical If the steering will not lock, try turning Using the hazard or turn signal lights systems are off. The key can be re- the handlebars back to the right slight- for an extended length of time may moved.

  • Page 22: Indicator Lights And Warning Lights

    High beam indicator light “ ” is correct, immediately turn the en- This indicator light comes on when the gine off and have a Yamaha dealer high beam of the headlight is switched check the vehicle. EAU59962 If the warning light does not go off after Oil pressure warning light “...
  • Page 23 Instrument and control functions  does not come on when the key is The electrical circuit of the warning have a Yamaha dealer check the self- light can be checked by turning the key diagnosis system. (See page 4-12 for turned to “ON”...

  • Page 24: Multi-Function Meter Unit

    If the indicator light does not come on initially when the key is turned to “ON”, or if the indicator light remains on, have a Yamaha dealer check the electrical circuit.
  • Page 25 Instrument and control functions Tachometer EWA12423 WARNING Be sure to stop the vehicle before making any setting changes to the multi-function meter unit. Changing settings while riding can distract the operator and increase the risk of an accident. 1. Fuel meter Except when accessing the brightness 2.
  • Page 26 Fuel meter warning indicator will flash repeatedly. If this occurs, have a Yamaha dealer check the vehicle. Eco indicator 1. Clock The clock uses a 12-hour time system.
  • Page 27 Instrument and control functions Multi-function display stantaneous fuel consumption “km/L” or “L/100 km”, average fuel consump- Consider the following tips to reduce tion “AVE_ _._ km/L” or “AVE_ _._ fuel consumption: L/100 km”, coolant temperature “_ _  Avoid high engine speeds during °C”, and air temperature “Air_ _ °C”...
  • Page 28 Instrument and control functions  You can manually reset the fuel re-  “L/100 km”: The amount of fuel serve tripmeter, or after refueling necessary to travel 100 km under  The odometer will lock at 999999. and traveling 5 km, it will reset au- the current riding conditions is ...
  • Page 29 Instrument and control functions The average fuel consumption can be Coolant temperature Air temperature set to either “AVE_ _._ km/L” or “AVE_ _._ L/100 km”.  “AVE_ _._ km/L”: The average dis- tance that can be traveled on 1.0 L of fuel is shown.
  • Page 30 2. Push and hold the left set button. a Yamaha dealer to have them re- play changes to self-diagnosis mode. If 3. Turn the key to “ON” and continue registered.

  • Page 31: Handlebar Switches

    Instrument and control functions EAU1234K EAU12352 EAU68270 Handlebar switches Pass switch “ ” Start/Engine stop switch “ / ” Press this switch to flash the headlight. To crank the engine with the starter, Left set this switch to “ ”, and then slide the switch toward “...

  • Page 32: Clutch Lever

    Instrument and control functions ECA10062 EAU12822 EAU12872 Clutch lever Shift pedal NOTICE Do not use the hazard lights for an extended length of time with the en- gine not running, otherwise the bat- tery may discharge. 1. Clutch lever 1. Shift pedal The clutch lever is located on the left The shift pedal is located on the left side of the handlebar.

  • Page 33: Brake Lever

    Brake lever Brake pedal ABS (for ABS models) The brake lever is located on the right The Yamaha ABS (Anti-lock Brake side of the handlebar. To apply the System) features a dual electronic con- front brake, pull the lever toward the trol system, which acts on the front and throttle grip.

  • Page 34: Fuel Tank Cap

    However, special tools are opened. required, so please consult your Yamaha dealer. To close the fuel tank cap 1. Rear wheel sensor 1. Push the fuel tank cap into posi- ECA20100 2.

  • Page 35: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.

  • Page 36: Fuel Tank Breather Hose And Overflow Hose

     Make sure that the end of each as well as to the exhaust system. hose is not blocked, and clean if Your Yamaha engine has been de- necessary. signed to use regular unleaded gaso-  Make sure that each hose is rout- line with a research octane number of ed through the clamp.

  • Page 37: Catalytic Converter

    Instrument and control functions EAU13434 ECA10702 EAU59901 Catalytic converter Seats NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. Passenger seat of leaded gasoline will cause unre- EWA10863 pairable damage to the catalytic WARNING To remove the passenger seat converter.
  • Page 38 Instrument and control functions To install the passenger seat To install the rider seat 1. Insert the projections on the front 1. Fit the slot in the seat onto the pro- of the passenger seat into the seat jection on the frame cross mem- holders as shown, and then push ber as shown, and then place the the rear of the seat down to lock it...

  • Page 39: Helmet Holding Cable

    Instrument and control functions EAU59981 Helmet holding cable When removing the screwdriver, slide Make sure that the screwdriver is se- A helmet holding cable is located on the screwdriver toward the “ ” mark curely positioned between its holders, the bottom of the passenger seat. Use on the passenger seat.

  • Page 40: Storage Compartment

    Instrument and control functions  Do not exceed the maximum To release a helmet from the helmet EAU14465 Storage compartment holding cable load of 173 kg (381 lb) (MT07AG) 1. Remove the passenger seat. 176 kg (388 lb) (MT07G) for the 2.

  • Page 41: Adjusting The Shock Absorber Assembly

    Spring preload setting: sembly yourself. Take the shock the adjusting ring in direction (a). To Minimum (soft): absorber assembly to a Yamaha decrease the spring preload and there- dealer for any service. by soften the suspension, turn the ad- Standard: justing ring in direction (b).

  • Page 42: Luggage Strap Holders

    (or does not stay up), otherwise the sidestand could contact the ground and distract the operator, resulting in a possible loss of control. Yamaha’s ignition circuit cut-off 1. Luggage strap holder system has been designed to assist There are six luggage strap holders,...

  • Page 43: Ignition Circuit Cut-Off System

    Instrument and control functions this system regularly and have a EAU68280 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system function properly. (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.
  • Page 44 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the start/engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 45: Auxiliary Dc Connector

    Instrument and control functions EAU70640 Auxiliary DC connector This vehicle is equipped with an auxil- iary DC connector. Consult your Yamaha dealer before installing any accessories. 4-27...

  • Page 46: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-11 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 47 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-15, 7-25 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-25 •...
  • Page 48 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-24 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 49: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 50: Shifting

    4-4 neutral position. The neutral indi- for the corresponding warning cator light should come on. If not, and indicator light circuit check. ask a Yamaha dealer to check the  After going off once, the oil electrical circuit. pressure warning...
  • Page 51 Operation and important riding points 4. At the recommended shift points clutch lever in, use the brakes to ECA10261 NOTICE shown in the following table, close slow the motorcycle, and continue  Even with the transmission in the throttle, and at the same time, to downshift as necessary.

  • Page 52: Tips For Reducing Fuel Consumption

    Operation and important riding points EAU64150 EAU16811 EAU16842 Recommended shift points Tips for reducing fuel con- Engine break-in The recommended shift points during sumption There is never a more important period acceleration and deceleration are in the life of your engine than the period Fuel consumption depends largely on shown in the table below.

  • Page 53: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle.  Do not park on a slope or on soft...
  • Page 54 To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 55: Owner's Tool Kit

    Owner’s tool kit If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. 1. Owner’s tool kit The owner’s tool kit is located under the passenger seat. Some tools are also located on the bottom of the pas- senger seat.

  • Page 56: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.

  • Page 57: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU1770M General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ 1 * Air filter element •...
  • Page 58 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for exces- √ √...
  • Page 59 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for oil leak- √...
  • Page 60 Periodic maintenance and adjustment EAU18681  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 61: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 62: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment 4. Remove the engine oil filler cap, EAU60471 Engine oil and oil filter car- the engine oil drain bolt and its tridge gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 63 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt and 7. Install the new oil filter cartridge its new gasket, and then tighten 6.

  • Page 64: Coolant

     The coolant level must  In order to prevent clutch slip- gine off and have a Yamaha dealer checked on a cold engine since check the vehicle. page (since the engine oil also the level varies with engine tem- lubricates the clutch), do not 11.
  • Page 65 If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as 7-12...
  • Page 66 Periodic maintenance and adjustment 5. Remove the coolant reservoir cap. 8. Remove the coolant drain bolt and its gasket to drain the coolant from the cooling system. 1. Radiator cap 2. Radiator cap retaining bolt 1. Coolant reservoir cap 2. Coolant reservoir 4.

  • Page 67: Replacing The Air Filter Element And Cleaning The Check Hose

    EAU60451 Antifreeze/water mixture ratio: Replacing the air filter ele- the vehicle for coolant leakage. If ment and cleaning the check coolant is leaking, have a Yamaha Recommended antifreeze: hose High-quality ethylene glycol anti- dealer check the cooling system. freeze containing corrosion inhibi-...

  • Page 68: Checking The Throttle Grip Free Play

    Measure the throttle grip free play as and/or engine noise. To prevent this shown. from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Throttle grip free play Throttle grip free play: 3.0–5.0 mm (0.12–0.20 in)

  • Page 69: Tires

    Never overload your vehicle. Opera- Operation of this vehicle with im- wall is cracked, have a Yamaha dealer tion of an overloaded vehicle could proper tire pressure may cause se- replace the tire immediately.
  • Page 70 Tire information characteristics of the motorcy- EWA10472 WARNING cle may be different, which  Have a Yamaha dealer replace could lead to an accident.  Always make sure that the valve excessively worn tires. Besides being illegal, operating the vehi-...

  • Page 71: Cast Wheels

    If any damage is found, have high speeds. a Yamaha dealer replace the  Brand-new tires can have a rel- wheel. Do not attempt even the atively poor grip on certain road smallest repair to the wheel.

  • Page 72: Checking The Brake Lever Free Play

    There should be no free play at the play, turn the adjusting nut in di- brake lever end. If there is free play, rection (b). have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 73: Brake Light Switches

    EAU36891 takes effect. If necessary, have a Front brake pads Yamaha dealer adjust the brake light switches. 1. Rear brake light switch 2. Rear brake light switch adjusting nut The brake light, which is activated by...

  • Page 74: Checking The Brake Fluid Level

    Rear brake EAU40262 Checking the brake fluid level Yamaha dealer replace the brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 75: Changing The Brake Fluid

    EAU22733 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the further riding. may deteriorate, causing leak- brake fluid at the intervals specified in age.

  • Page 76: Drive Chain Slack

    EAU22762 EAU59921 Drive chain slack To adjust the drive chain slack Consult a Yamaha dealer before ad- The drive chain slack should be justing the drive chain slack. checked before each ride and adjusted 1. Loosen the locknut at each end of if necessary.

  • Page 77: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment 3. Tighten the axle nut, and then EAU23026 Cleaning and lubricating the tighten the locknuts to the speci- drive chain fied torques. The drive chain must be cleaned and lubricated at the intervals specified in Tightening torques: Axle nut: the periodic maintenance and lubrica- 105 Nm (10.5 m·kgf, 76 ft·lbf)

  • Page 78: Checking And Lubricating The Cables

    Yamaha dealer at the intervals cated if necessary. If a cable is specified in the periodic maintenance damaged or does not move smoothly, chart.

  • Page 79: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment EAU44276 EAU23144 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...

  • Page 80: Checking And Lubricating The Sidestand

    The operation of the sidestand should The pivoting points of the rear suspen- be checked before each ride, and the sion must be lubricated by a Yamaha sidestand pivot and metal-to-metal dealer at the intervals specified in the contact surfaces should be lubricated periodic maintenance and lubrication if necessary.

  • Page 81: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 82: Checking The Steering

    If any free This model is equipped with a VRLA smoothly, have a Yamaha dealer play can be felt, have a Yamaha (Valve Regulated Lead Acid) battery. check the wheel bearings. dealer check or repair the steer- There is no need to check the electro- ing.
  • Page 83 To charge the battery ge it if necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before installation. NOTICE: When in- tery as soon as possible if it seems to have discharged.

  • Page 84: Replacing The Fuses

    Periodic maintenance and adjustment MT07G MT07AG EAU59871 Replacing the fuses The main fuse and the fuse boxes, 9 10 which contain the fuses for the individ- 1 2 3 4 5 1 2 3 4 5 ual circuits, are located under the rider seat.

  • Page 85: Replacing The Headlight Bulb

    If the headlight bulb age to the electrical system and 4. If the fuse immediately blows burns out, replace it as follows. possibly a fire. again, have a Yamaha dealer [EWA15132] ECA10651 check the electrical system. NOTICE Specified fuses:...
  • Page 86 Periodic maintenance and adjustment 1. Do not touch the glass part of the bulb. 1. Bolt and washer 1. Headlight bulb holder 2. Headlight bulb 1. Remove the headlight unit by re- 2. Disconnect the headlight coupler, 4. Place a new headlight bulb into moving the bolt and washer on and then remove the headlight position, then secure it with the...

  • Page 87: Replacing The Auxiliary Light Bulb

    Periodic maintenance and adjustment 7. Have a Yamaha dealer adjust the EAU46405 Replacing the auxiliary light headlight beam if necessary. bulb If the auxiliary light bulb burns out, re- place it as follows. 1. Remove the headlight unit. (See page 7-32.) 2.

  • Page 88: Brake/Tail Light

    1. Remove the turn signal light lens If the brake/tail light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Turn signal light bulb 3. Insert a new bulb into the socket, push it in, and then turn it clock- wise until it stops.

  • Page 89: Replacing The License Plate Light Bulb

    Periodic maintenance and adjustment EAU59890 EAU67131 Replacing the license plate Supporting the motorcycle light bulb Since this model is not equipped with a centerstand, use maintenance stands 1. Remove the license plate light unit when removing the front or rear wheel by removing the nuts, washers or when performing other maintenance and collars, and then remove the...

  • Page 90: Front Wheel (For Non-Abs Models)

    Periodic maintenance and adjustment EAU44792 Front wheel (for non-ABS models) EWA14841 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU61491 1. Front wheel axle pinch bolt 1. Brake hose holder 2. Wheel axle 2. Brake hose holder bolt To remove the front wheel 3.

  • Page 91: Rear Wheel (For Non-Abs Models)

    WARNING 23 Nm (2.3 m·kgf, 17 ft·lbf) sidestand down. For the ABS model, have a Yamaha 4. Install the brake calipers and the 8. Push down hard on the handlebar dealer remove and install the wheel.
  • Page 92 Periodic maintenance and adjustment 1. Drive chain slack adjusting plate 1. Brake caliper 2. Drive chain slack adjusting nut 2. Drive chain slack adjusting plate  If the drive chain is difficult to re- 3. Locknut 3. Wheel axle 4. Axle nut and washer move, remove the wheel axle first, and then lift the wheel upward 3.
  • Page 93 Periodic maintenance and adjustment Tightening torques: Axle nut:  Make sure that the slot in the 105 Nm (10.5 m·kgf, 76 ft·lbf) brake caliper bracket is fit over the Locknut: retainer on the swingarm. 16 Nm (1.6 m·kgf, 12 ft·lbf) ...

  • Page 94: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 95: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 96 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 97: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 98 Motorcycle care and storage off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.

  • Page 99: Storage

    EWA11132 poorly ventilated room or cover- WARNING ing it with a tarp, while it is still  Consult a Yamaha dealer for ad- Contaminants on the brakes or tires wet, will allow water and humid- can cause loss of control.
  • Page 100 Motorcycle care and storage 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 101: Specifications

    Specifications Bore × stroke: Dimensions: Fuel: 78.0 × 68.6 mm (3.07 × 2.70 in) (MT07AG) Overall length: Recommended fuel: 80.0 × 68.6 mm (3.15 × 2.70 in) (MT07G) 2085 mm (82.1 in) Regular unleaded gasoline (Gasohol [E10] Compression ratio: Overall width: acceptable) 11.0 : 1 (MT07AG) 745 mm (29.3 in)
  • Page 102 Specifications 2nd: Manufacturer/model: Front suspension: 2.125 (34/16) BRIDGESTONE/BT023R M Type: 3rd: Loading: Telescopic fork 1.632 (31/19) Maximum load: Spring: 4th: 173 kg (381 lb) (MT07AG) Coil spring 1.300 (26/20) 176 kg (388 lb) (MT07G) Shock absorber: 5th: (Total weight of rider, passenger, cargo Hydraulic damper 1.091 (24/22) and accessories)
  • Page 103 Specifications Bulb wattage × quantity: Auxiliary fuse: 2.0 A Headlight: Headlight fuse: H4, 60.0 W/55.0 W x 1 15.0 A Brake/tail light: Signaling system fuse: 10.0 A Front turn signal light: 10.0 W × 2 Ignition fuse: 10.0 A Rear turn signal light: 10.0 W ×...

  • Page 104: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.

  • Page 105: Motorcycle Noise Regulation (For Australia)

    This infor- TROL SYSTEM PROHIBITED: mation will be needed when ordering Owners are warned that the law may spare parts from a Yamaha dealer. prohibit: a. The removal or rendering inopera- tive by any person other than for...

  • Page 106: Index

    Index Engine oil and oil filter cartridge ..... 7-9 Matte color, caution ........8-1 Engine serial number......10-1 Model label ...........10-1 ABS (for ABS models)......4-15 Engine trouble warning light....4-5 Multi-function meter unit......4-6 ABS warning light (for ABS models) ..4-5 Air filter element and check hose, replacing and cleaning .......7-14 Front and rear brake pads, checking ...
  • Page 107 Index Throttle grip free play, checking... 7-15 Tires ............7-16 Tool kit............ 7-2 Troubleshooting........7-41 Troubleshooting charts......7-42 Turn signal indicator lights ..... 4-4 Turn signal light bulb, replacing ... 7-35 Turn signal switch......... 4-13 Valve clearance ........7-15 Vehicle identification number ....10-1 Wheel bearings, checking ....
  • Page 110 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2015.12-0.4×1 CR...
