Chapter1 - Technical Parameters

1.1 Applicable Fiber Type

＊ SM(ITU-T G.652&T G.657)/MM(ITU-T G.651)/DS(ITU- T G.653)/NZDS (ITU-T G.655)
＊ Fiber count: Single
＊ Applicable fiber / cable diameter: 0.2mm to 3.0mm/Indoor Cable
＊ Applicable fiber diameter: Cladding diameter:

1.2 Splice Loss

Same fiber is spliced, measured by cut-back method relevant to ITU-T standard. The typical values of splice loss are:
＊ SM:0.03dB
＊ MM:0.01dB
＊ DS:0.05dB
＊ NZDS:0.05dB
＊ G.657:0.03dB

1.3 Splice Mode

＊ It can be preset 128 kinds of splice mode.
＊ It can store 10000 records of the latest splice results.
＊ Splice time: Quick Mode : 7 sec (Avg.) / SM Auto Mode : 9 sec (Avg.)

1.4 Heat Oven

＊ 5 kinds of applicable protection sleeve: 20mm, 30mm, 40mm, 50mm, 60mm.
＊ Heating time: 8 to 900s optional.
＊ Typical heating time: 13 sec (45mm, slim 60mm), 15 sec(60mm)
＊ Heating mode: Various in-built heat modes available.
＊ Heater: Specific heater for VIEW 3 Pro fusion splicer.

1.5 Power Supply

＊ Standard AC power voltage: AC 100 to 240V, 50 to 60Hz；
＊ Standard DC power voltage: DC 9 to 14V

1.6 Size and Weight

＊ Size：Length×width×height= 149W x 177D x 151H mm (including rubber bumper)
＊ weight：2.21kg (with battery) / 1.85kg (without battery)

1.7 Environmental Conditions

＊ Operating conditions: altitude: 0 to 5000m, relative humidity: 0 to 95%, temperature: -10 to 50 ℃ , the maximum wind
velocity: 15m / s;
＊ Storage conditions: relative humidity: 0 to 95%, temperature: -20 to 60 ℃ ,
battery: -20 to 30 ℃ for long-term storage.
to 125μm
100
130W x 166D x 140H mm (excluding rubber bumper)
