Chapter 4 - Splice Mode
VIEW 3 Pro has an intuitive and simple but very powerful program structure to operate. Splice programs define arc
currents, splice times as well as various parameters used when performing a splice. Therefore, it is essential to select the
correct splice program. There are a number of "Preset" splice programs for common fiber combinations. Therefore, it is
much easier to modify and further optimize the parameters for more unusual fiber combinations.

4.1 Displaying the Active Splice

The active splice program is always displayed at the top of the screen (see below).

4.2 Selecting a Splice Mode

① Select [Splice mode] from the main menu.
② Select an appropriate splice mode
③ Selected splice mode appears on the screen.
Press [Reset] button to return to initial interface
page.
15
Displaying the active splice program
