Chapter 6 - Heater Mode
The splicer provides max 32 heat modes including 7 heat modes preset by INNO Instrument and the reset that can be
defined by users.
Select a heating mode that best matches with the protection sleeve used.
For each type of protection sleeve, VIEW 3 Pro has its optimum heating mode. These modes can be found in the database
area for reference. Copy the appropriate mode and paste it to the user–programmable area. Users can edit those
parameters.

6.1 Selecting Heater Mode

Select [Select Heat Mode] in [Heater Mode] menu.

6.2 Editing Heat Mode

Heating conditions stored in heating mode can be edited or changed.
① Select [Heater Mode] menu.
③ Selected heat mode appears on the screen. Press [R]
button to return to initial interface.
① Select [Edit Heat Mode] in [Heater mode] menu.
19
② Select heat mode.
