・This document contains descriptions of how to set the new functions and their restrictions.
Refer also to the Operating Instructions of this product.
・Depending on the model used, the screens shown in the explanations may differ to the
actual camera screens.
・This document is for the following models.
Notation
WV-S1136, WV-S1536L, WV-S1536LN, WV-S1536LN-B, WV-S1536L-B, WV-S1536LNS,
SSeriesS
SC384B
WV-S1536LTN, WV-S2136, WV-S2136-B, WV-S2136G, WV-S2136G-B, WV-S2136L,
WV-S2136L-B, WV-S2136LG, WV-S2136LG-B, WV-S2236L, WV-S2236L-B,
WV-S2236LG, WV-S2236LG-B, WV-S2536L, WV-S2536LG, WV-S2536LGN,
WV-S2536LN, WV-S2536LTN, WV-S1536LT, WV-S2536LT,
WV-S1136A, WV-S1536LA, WV-S1536LNA, WV-S1536LNA-B, WV-S1536LA-B,
WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B, WV-S2136GA,
WV-S2136GA-B, WV-S2136LA, WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B,
WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B, WV-S2536LA,
WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA, WV-S1536LTA,
WV-S2536LTA
WV-S15700-V2L Series, WV-S15500-V3L Series, WV-S22600-V2L Series,
SSeriesH
SC384B
WV-S25700-V2L Series, WV-S25500-V3L Series, WV-S25500-V3L Series,
WV-S15500-F3L Series, WV-S22500-F3LSeries, WV-S25500-F3L Series,
WV-S15600-V2L Series, WV-S22700-V2L Series, WV-S22500-V3L Series,
WV-S25600-V2L Series, WV-S15500-F6L Series, WV-S22500-F6L Series,
WV-S25500-F6L Series
WV-S4156, WV-S4176, WV-S4556L, WV-S4556LM, WV-S4576L, WV-S4576LM,
fisheye
WV-S4156A, WV-S4176A, WV-S4556LA, WV-S4556LMA, WV-S4576LA, WV-S4576LMA
WV-S8543, WV-S8543G, WV-S8543L, WV-S8543LG, WV-S8543LN, WV-S8543N
Multi
WV-S8544, WV-S8544G, WV-S8544L, WV-S8544LG, WV-S8544LN, WV-S8544N,
WV-S8563L, WV-S8563LG,WV-S8563LN,WV-S8564L,WV-S8564LG,WV-S8564LN,
WV-S8573L, WV-S8573LG, WV-S8573LN, WV-S8574L, WV-S8574LG, WV-S8574LN
WV-S71300-F3, WV-S71300A-F3
miniAI
WV-S65340-Z4K, WV-S65340-Z4N, WV-S61302-Z4, WV-S65340-Z2K, WV-S65340-Z2N,
PTZ S
WV-S61301-Z2, WV-S65340-Z4G, WV-S65340-Z2G, WV-S61301-Z1, WV-S61300-ZY,
WV-S61300-ZYG, WV-S61501-Z1, WV-S65302-Z2, WV-S65302-Z2G, WV-S65302-Z2-1,
WV-S65301-Z1, WV-S65301-Z1G, WV-S65301-Z1-1, WV-S65301-Z1S, WV-S65300-ZY,
WV-S65300-ZYG, WV-S65501-Z1, WV-S65501-Z1G
WV-U65302-Z2, WV-U65302-Z2G, WV-U61301-Z2, WV-U65301-Z1, WV-U65301-Z1G,
PTZ U
WV-U61301-Z1, WV-U65300-ZY, WV-U65300-ZYG, WV-U61300-ZY, WV-U61300-ZYG
New functions and addendum
Model
1
Advertisement
Related Manuals for Panasonic WV-S15700-V2L Series
Summary of Contents for Panasonic WV-S15700-V2L Series
- Page 1 WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B, WV-S2136GA, WV-S2136GA-B, WV-S2136LA, WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B, WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B, WV-S2536LA, WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA, WV-S1536LTA, WV-S2536LTA WV-S15700-V2L Series, WV-S15500-V3L Series, WV-S22600-V2L Series, SSeriesH SC384B WV-S25700-V2L Series, WV-S25500-V3L Series, WV-S25500-V3L Series, WV-S15500-F3L Series, WV-S22500-F3LSeries, WV-S25500-F3L Series,...
- Page 2 Due to software upgrade, the following functions have been added and changed to this product. ・Firmware Ver.1.20 SSeriesS SC384B (Except for WV-S1536LTN, WV-S2536LTN, WV-S2136G, WV-S2136LG, WV-S2236LG, WV-S2536LG, WV-S2536LGN) Functions Item (Page) Page Add to the system log when recording stream fails to write Status (Maintenance) Add a function to notify the user of writing failures in the Status (Maintenance)
- Page 3 ・Firmware Ver.1.41 SSeriesS SC384B Functions Item (Page) Page Add Genetec Stratocast Service Network (Stratocast) *1 Except for WV-S1136A, WV-S1536LA, WV-S1536LNA, WV-S1536LNA-B, WV-S1536LA-B, WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B, WV-S2136GA, WV-S2136GA-B, WV-S2136LA, WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B, WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B, WV-S2536LA, WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA, WV-S1536LTA, WV-S2536LTA.
- Page 4 Add NTP test function Advanced (Network) Add TLS settings to HTTPS Advanced (Network) Add MQTT function Advanced (Network) Add a system log when MQTT function fails Status (Maintenance) Add log indications/error indications relating to System log (Maintenance) Firmware Upgrade ・Firmware Ver.2.20 Functions Item (Page) Page...
- Page 5 Firmware Ver.2.20 miniAI Functions Item (Page) Page Add AI-VMD alarm area information on TCP alarm Notification (Alarm) notification Add Image transmission log on Status page Status (Maintenance) Firmware Ver.2.30 Functions Item (Page) Page Add 2fps and 3fps to FTP/SFTP refresh interval, add Advanced (Network) 1920x1080 to pre-alarm resolution, expand image destination server to 2 locations...
- Page 6 Firmware Ver.2.32 Functions Item (Page) Page Add new model number: WV-S1136A, WV-S1536LA, WV-S1536LNA, WV-S1536LNA-B, WV-S1536LA-B, WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B, WV-S2136GA, WV-S2136GA-B, WV-S2136LA, , WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B, WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B, WV-S2536LA, WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA, WV-S1536LTA, WV-S2536LTA, WV-S4156A, WV-S4176A, WV-S4556LA, WV-S4556LMA, WV-S4576LA, WV-S4576LMA For the above models, the previous firmware is not available earlier than Ver.2.32.
- Page 7 1. Add to the system log when recording stream fails to write (Operating Instructions “Others” – “Maintenance” - Check the status [Status]) A system log has been added for errors in the write process of the recording stream to the log related to SD memory cards.
- Page 8 [Alarm]) － Configuration of the settings relating to alarm notification［Notification］ －Configure the settings relating to Panasonic alarm protocol) Add the write processing error of the recording stream to the occurrence condition of the Panasonic alarm protocol notification of “Diag.” Panasonic alarm protocol •...
- Page 9 3. Add a note when the bit rate of the recording stream is set to a value exceeding recommended value (Operating Instructions “Image/Audio” - Configure the settings relating to Stream [Image] Add the statement that it is possible that an error may occur in the continuity of SD memory card recording, if you set a bit rate that exceeds the recommended value in “Note”...
- Page 10 4. SDK version display (Operating Instructions – Perform management of the extension software and the schedule setting [Ext. software] - Perform the installation, uninstallation and version upgrade of the extension software [Software mng.]) The firmware version and SDK version of the camera and ext. software have been added to the software management screen.
- Page 11 Extension software [Version] If you have installed ext. software, the version information of the installed ext. software is displayed along with the version information of the SDK installed in the ext. software. If the version information of the SDK embedded in the camera is less than the version number required by the ext.
- Page 12 5. Extend authentication password for the destination of notification (Operating Instructions – Configure the network settings [Network] – Configure advanced network settings [Advanced] - Configure the settings related to sending E-mails) The number of characters that can be entered for the authentication password of the destination of notification has been expanded to 128 characters.
- Page 13 6. Change AI-VMD and AI People Detection to be pre-installed (Operating Instructions – Perform management of the extension software and the schedule setting [Ext. software]) Change the pre-installed Ext. software ) and AI Privacy Guard to AI Video Motion Detection (“AI-VMD” AI-VMD and AI People Detection.
- Page 14 7. Add RAM capacity expansion mode (Operating Instructions – Perform management of the extension software and the schedule setting [Ext. software] – Perform the installation, uninstallation and version upgrade of the extension software [Software mng.]) RAM capacity expansion mode has been added to the software management screen. This mode increases the amount of RAM available to the Ext.
- Page 15 8. Add LLDP function (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) LLDP (Link Layer Discovery Protocol) has been added to [Advanced] of [Network]. Interoperability can be achieved by sending and receiving camera's device information to and from LLDP-compatible devices.
- Page 16 Fabric Attach [Fabric Attach authentication key] Enter the key to be used for Fabric Attach authentication. Note that this is valid only when “LLDP” is “Enable”. Available number of characters: 0 - 32 characters (If Fabric attach authentication is not performed, leave it blank.) Available characters: Alphanumeric characters Default: None (blank)
- Page 17 9. Add SFTP periodic image transmission to “Event operation” of Easy Setup (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]) With the addition of the SFTP function, SFTP periodic image transmission has been added to the “Event action”...
- Page 18 Flow of event action setup Schedule Event function type: Alarm → Schedule: Configure SD Select the trigger (→Alarm: Configure the terminal recording or SFTP periodic image according to the and VMD (alarm setup menu)) transmission (schedule function purpose of setting. type setup menu)) Terminal/VMD/SCD/Audio detection SD memory...
- Page 19 Configure the schedule/alarm (event function type setup menu) (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action] – Configure the schedule/alarm (event function type setup menu)) Here, select the function type of the event. [Trigger] •...
- Page 20 Alarm: Configure the alarm function type (Alarm function type setup menu) (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action] – Alarm: Configure the alarm function type (Alarm function type setup menu)) Select the alarm function type as “SFTP transfer” or “SD memory recording”. Configure “Recording format”...
- Page 21 Alarm: Configure the details for image transfer or recording conditions (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action] – Alarm: Configure the details for recording conditions) Set SFTP transfer (SFTP transfer setup menu) SFTP transfer when an alarm is detected is set in this section.
- Page 22 Schedule: Configure SD recording or SFTP periodic image transmission (schedule function type setup menu) (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action] – Schedule: Configure SD recording or SFTP periodic image transmission (schedule function type setup menu) ) Here, the schedule type is selected as “SD memory recording”...
- Page 23 Schedule: Configure SFTP periodic image transmission (SFTP periodic image transmission setup menu) (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]) The SFTP periodic image transmission is configured in this section. • To configure SFTP periodic image transmission settings: Refer to “12.
- Page 24 •To configure SFTP periodic image transmission schedule settings: Refer to “Configure the settings relating to the schedules [Schedule]” for information about how to set the above screen. [Set] button If you click the [Set] button, setup will be completed. [Back] button If you click the [Back] button, the SFTP periodic image transmission setup menu will be displayed.
- Page 25 10. Add “SFTP periodic image transmission error” to “Save trigger” of SD memory card (Operating Instructions – Configure the basic settings of the camera [Basic] – Configure the settings relating to the SD memory card [SD memory card]) With the addition of the SFTP function, “SFTP periodic image transmission error” has been added to the “Save trigger”...
- Page 26 11. Add link to SFTP settings in Camera action on alarm (Operating Instructions – Configure the alarm settings [Alarm] – Configure the settings relating to the camera action on alarm occurrence [Alarm]) Click the [Alarm] tab on the “Alarm” page. (→“How to display the setup menu”, “How to operate the setup menu”) The settings related to the camera action on alarm can be configured in this section.
- Page 27 [SNMP transmission upon alarm detection] Click “To SNMP setting” to display the setup menu that can configure the settings relating to SNMP transmission when an alarm occurs. The setup menu will be displayed in a newly opened window. (→“Configure settings relating to SNMP transmissions of alarm images”)
- Page 28 Configure settings relating to SFTP transmissions of alarm Images (Operating Instructions – Configure the alarm settings [Alarm] – Configure the settings relating to the camera action on alarm occurrence [Alarm]) Click “SFTP setup >>” of “Camera action on alarm” on the [Alarm] tab of the “Alarm” page. (→”Configure the settings relating to the camera action on alarm occurrence [Alarm]”) Refer to “12.
- Page 29 12. Add SFTP image transmission function (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) SFTP (SSH File Transfer Protocol) function has been added to securely send images to the server by using SSH (Secure Shell) encrypted data stream. It has the following two transmission functions.
- Page 30 • Available number of characters: 1 - 256 characters • Unavailable characters: " & ; [File name] Enter the file name used for the alarm image to be transmitted to an SFTP server. The file name will be as follows. File name: [“Entered file name”...
- Page 31 Image quality 1280x960 Image 1280x720 capture size 640x360 QVGA 320x180 [Post alarm] • Transmission interval Select the transmission interval for the alarm image transmission to the FTP server from the following. When 30fps mode or 15fps mode is selected for [Image capture mode]: 0.1fps/ 0.2fps/ 0.33fps/ 0.5fps/ 1fps When 25fps mode or 12.5fps mode is selected for [Image capture mode]: 0.08fps/ 0.17fps/ 0.28fps/ 0.42fps/ 1fps...
- Page 32 [Directory name] Enter the directory name where the images are to be saved. For example, enter “/img” to designate the directory “img” under the root directory of the SFTP server. • Available number of characters: 1 - 256 characters • Unavailable characters: " & ; •...
- Page 33 • Default: 22 The following port numbers are unavailable since they are already in use. 20, 23, 25, 42, 53, 67, 68, 69, 80, 110, 123, 161, 162, 443, 995, 10669, 10670 [Host key hash] Enter the hash value of the public key of the SFTP server. •...
- Page 34 13. Add SFTP periodic image transmission to “Schedule mode” of Schedule (Operating Instructions – Configure the settings relating to the schedules [Schedule]) “SFTP periodic image transmission” was added to “Schedule mode” of the schedule setting. [Schedule mode] Select an action to be assigned to the schedule from “Schedule mode”. “Off”...
- Page 35 Note • Select “On” for “User auth.” on the [User auth.] tab of “User mng.” page (→“Configure the settings relating to the user authentication [User auth.]”) and “Off” for “Host auth.” on the “Host auth.” page (→“Configure the settings relating to the host authentication [Host auth.]”) to validate “Access permission”.
- Page 36 14. Using the recording function is changed when the Ext. software mode is On (Operating Instructions – Configure the basic settings of the camera [Basic]) – Configure the settings relating to the SD memory card [SD memory card]) Even if the Ext. software mode is set to On, the recording function to SD memory card by this product function can be used.
- Page 37 15. Change the initial value of “Overwrite” of SD memory card to On (Operating Instructions – Configure the basic settings of the camera [Basic]) – Configure the settings relating to the SD memory card [SD memory card]) [Overwrite] Determine whether or not to overwrite when the remaining capacity of the SD memory card becomes insufficient.
- Page 38 16. Add NTP test function (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced] – Configure the settings relating to the NTP server) Add a test function for time synchronization to check if it can communicate with NTP server. [NTP test] Select “Synchronization with NTP server”...
- Page 39 17. Add TLS settings to HTTPS (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced] – Configure the HTTPS settings) Add TLS1.1, TLS1.2 and TLS1.3 selection items to the HTTPS connection method. [HTTPS - Connection] Select the protocol used to connect the camera.
- Page 40 18. Add MQTT function (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) MQTT (Message Queueing Telemetry Transport) has been added to “Advanced” of “Network”. When an alarm occurs, the MQTT server can be notified of the event action by the alarm. [MQTT settings] Set On/Off whether to enable/disable the MQTT function.
- Page 41 [Port] Enter the port number of the MQTT server. Available port number: 1 - 65535 Default: 8883 The following port numbers cannot be set because they are used by this product. 20, 21, 23, 25, 42, 53, 67, 68, 69, 80, 110, 123, 161, 162, 443, 554, 995, 10669, 10670 [Protocol] Select the protocol to use when connecting to an MQTT server from MQTT over SSL/MQTT over TCP.
- Page 42 Notification setting [Alarm] Check the alarm events to be notified to the MQTT server. Terminal 1: Notifies the MQTT server when an alarm occurs at terminal 1. Terminal 2: Notifies the MQTT server when an alarm occurs at terminal 2. Terminal 3: Notifies the MQTT server when an alarm occurs at terminal 3.
- Page 43 19. Add a system log when MQTT function fails (Operating Instructions – Others – About the displayed system log) Add a system log when an error occurs in the MQTT function. Error display related to MQTT Category Indication Description When the connection to the server fails, MQTT <MQTT>...
- Page 44 20. Add Genetec Stratocast Service (Operating Instructions – Configure the network settings [Network] – Configure Stratocast [Stratocast]) Add settings for connecting to Genetec Stratocast. Stratocast is a cloud-based video monitoring service provided by Genetec. You can register the network camera on the cloud server and check the camera images. [Stratocast] Enables/disables the Stratocast connection function.
- Page 45 Activation Started: The connection to Stratocast has started. Time Synchronization failed: Failed to connect to the Stratocast NTP server. Registration failed: Failed to register the camera with the Enrollment service. Device unregistered: The camera has been unregistered. Device Registered: The camera has been registered with Stratocast. Balancer failed: Failed to connect to Device Load Balancer.
- Page 46 Note You can also start the camera registration from the Stratocast portal site. In this case, use the “Copy” • button to enter the MAC address of the camera into the portal site. For information about Stratocast registration, click [Trouble Shooting or help?] on the camera screen to •...
- Page 47 21. Changed new GUI (Graphical User Interface) (Operating Instructions) Changed to a new GUI. The “Set” menu of the GUI before change is displayed by clicking the “Settings” [ ] button of the new GUI and then clicking the “Camera detailed setting” [ ] button on the “Detailed setting”...
- Page 48 22. Add AI-VMD alarm area information on TCP alarm notification ( Operating Instructions - Configure the alarm settings [Alarm] - Configuration of the settings relating to alarm notification [Notification] - Configure the settings relating to TCP alarm protocol) Add AI-VMD alarm area information on TCP alarm notification. [AI-VMD alarm area information］...
- Page 49 23. Add Image transmission log on Status page (Operating Instructions - Maintenance of the camera [Maintenance] - Check the status [Status]) Add Image transmission log on Status page. Click the “Confirm” button, to display the image transmission log in a separate window. Up to 4,000 image transmission logs can be saved on the SD memory card when the SD memory card is inserted after selecting “Use”...
- Page 50 [Number of pages display] The currently opened page will be displayed in the “page/total page” format. [<< Previous 100] When clicking “<< Previous 100”, the previous 100 image transmission logs will be displayed. [No.] The serial number of the image transmission logs will be displayed. [Time] Time and date at the error occurrence will be displayed.
- Page 51 24. About removal of functions due to end of Internet Explorer support (Operating Instructions) Microsoft ended support for the Web browser "Internet Explorer" on June 15, 2022. We have also terminated support for "Internet Explorer" for our cameras, and deleted the following functions that are only compatible with "Internet Explorer".
- Page 52 25. Changed the initial value of “Audio input encoding format” (Operating Instructions Configure the settings relating to images and audio [Image/Audio] - Configure the settings relating to audio [Audio]) Due to the end of support for Internet Explorer, the initial value of [Audio input encoding format] on the [Audio] tab will be changed to "AAC-LC".
- Page 53 26. Add “Close (Continue)” and “Open (Continue)” to the operation setting values of [Terminal 1], [Terminal 2], and [Terminal 3] on the [Alarm] tab (Operating Instructions – Configure the alarm settings [Alarm] – Configure the settings relating to the alarm action [Alarm]) Alarm [Terminal 1] [S4556] [S4156] [S4576] Determine how to use terminal 1.
- Page 54 [Terminal 3] [S4556] [S4156] [S4576] Determine how to use terminal 3. • Off: Not used. • Alarm input(TRM3): Receives alarms. When “Alarm input” is selected, a pull-down menu for “Close” and “Open” is displayed. – Close: An alarm is detected when the terminal status is changed to “Close”. –...
- Page 55 27. Add alarm test function to the alarm (Operating Instructions Configure the alarm settings [Alarm] - Configure the settings relating to the alarm action [Alarm]) An alarm test function has been added to the alarm. [Alarm test] Click the [Execute] button to execute the alarm test function. Note •...
- Page 56 28. Add log indications/error indications relating to Firmware Upgrade (Operating Instructions Others - About the displayed system log) Added system logs for log indications/error indications relating to firmware upgrades. Log indications relating to Firmware Upgrade Category Indication Description Firmware Upgrade Upgraded successfully •...
- Page 57 29. Add FTP to the communication protocol of the file transfer function (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) Added FTP to the communication protocol of the file transfer function. FTP (File Transfer Protocol) and SFTP (SSH File Transfer Protocol) are protocols for transferring files, and are used when sending images to a server.
- Page 58 •［Transmission protocol］ Select and set the protocol with the destination server from FTP/SFTP. • SFTP：SFTP is used as the protocol for transmitting with the server. • FTP：FTP is used as the protocol for transmitting with the server. • Default：SFTP IMPORTANT •...
- Page 59 [FTP transmission retry] Select “On” or “Off” to determine whether or not to resend failed FTP transmissions. • On: If transmission fails, transmissions are resent until they are successfully sent. • Off: If transmission fails, the image that failed to be sent is discarded and the next image is sent. •...
- Page 60 [Post alarm] • Transmission interval Select the transmission interval for the alarm image transmission from the following. When 60fps mode, 30fps mode or 15fps mode is selected for [Image capture mode]: 0.1fps/ 0.2fps/ 0.33fps/ 0.5fps/ 1fps When 50fps mode, 25fps mode or 12.5fps mode is selected for [Image capture mode]: 0.08fps/ 0.17fps/ 0.28fps/ 0.42fps/ 1fps •...
- Page 61 • Name w/time&date: File name will be [“Entered file name” + “Time and date (year/ month/ day/ hour/ minute/ second)” + “Serial number (starting from 00)”]. • Name w/o time&date: File name will be the characters entered for “File name” only. When “Name w/o time&date”...
- Page 62 [Host key hash] Enter the hash value of the public key of the SFTP server. • Available number of characters: 43 - 44 characters • Available characters: Alphanumeric characters, +, /, [User name] Enter the user name (login name) to access the SFTP server. •...
- Page 63 [FTP mode] Select “Passive” or “Active” for the FTP mode. Normally, select “Passive”. When it is impossible to connect after select “Passive”, try to connect after selecting “Active”. • Default: Passive...
- Page 64 30. Add SFTP periodic image transmission to “Event operation” of Easy Setup (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]) By adding the FTP function to the SFTP function, “SFTP periodic transmission” in “Event action” of Easy Setup was changed to “FTP/SFTP periodic transmission”.
- Page 65 Flow of event action setup Schedule Event function type: Alarm → Schedule: Configure SD Select the trigger (→Alarm: Configure the terminal recording or FTP/SFTP periodic according to the and VMD (alarm setup menu)) image transmission (schedule purpose of setting. function type setup menu)) Terminal/VMD/SCD/Audio detection SD memory FTP/SFTP...
- Page 66 Configure the schedule/alarm (event function type setup menu) (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]-schedule/alarm (event function type setup menu)) Here, select the function type of the event. [Trigger] • Alarm: Select when setting the alarm detection settings. •...
- Page 67 Alarm: Configure the terminal and VMD（alarm setup menu） (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]-schedule/alarm (event function type setup menu)) Here, select from “SD recording” or “FTP/SFTP transfer” in “Operating conditions” for the alarm type. Also select from each JPEG/each stream for “Recording compression method”.
- Page 68 [Back] button If you click the [Back] button the alarm setup menu will be displayed. （→Alarm: Configure the terminal and VMD (alarm setup menu)） ） Alarm：Configure the details for images transfer or recording conditions (Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]- Alarm：...
- Page 69 Refer to “29. Add FTP to the communication protocol of the file transfer function” for information about how to configure the above screen” how to set the above screen. [Next] button If you select “Alarm output” in the alarm setup menu and click the [Next] button, the alarm output setup menu will be displayed.（→Alarm: Configure the output terminal）<Terminal input/output supported models only>...
- Page 70 <SD memory card supported models only> If you select “FTP/SFTP periodic image transmission” and click the [Next] button, the FTP/SFTP periodic image transmission setup menu will be displayed.(→ Schedule: Configure FTP/SFTP periodic image transmission (FTP/SFTP periodic image transmission setup menu)) Note •...
- Page 71 Schedule：Configure FTP/SFTP periodic image transmission（FTP/SFTP periodic image transmission setup menu） （(Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event action]) The FTP/SFTP periodic image transmission is configured in this section. • To configure FTP/SFTP periodic image transmission settings;...
- Page 72 Refer to “29. Add FTP to the communication protocol of the file transfer function” for information about how to configure the above screen. [Set] button Displayed when “Periodical transmission” is “Off”. Click [Set] to save the settings. [Next] button This will be displayed when “Periodic transmission” is “On”. If you click the [Next] button, the FTP/SFTP periodic transmission schedule will be displayed.
- Page 73 • To configure FTP/SFTP periodic image transmission schedule settings： Refer to “Configure the settings relating to the schedules [Schedule]” for information about how to set the above screen.
- Page 74 [Set] button If you click the [Set] button, setup menu will be displayed. [Back] button If you click the [Back] button, the FTP/SFTP periodic image transmission setup menu will be displayed. ( →Schedule: Configure FTP/SFTP periodic image transmission (FTP/SFTP periodic image transmission setup menu)) Note •...
- Page 75 31. Change “SFTP periodic image transmission error” to “FTP/SFTP periodic image transmission error” in “Save trigger” of SD memory card. <SD memory card supported models only> (Operating Instructions – Configure the basic settings of the camera [Basic] – Configure the settings relating to the SD memory card [SD memory card]) By adding the FTP function to the SFTP function, Change “SFTP periodic image transmission error”...
- Page 76 32. Change the link of “SFTP setup” to “FTP/SFTP setup” in Camera action on alarm (Operating Instructions – Configure the alarm settings [Alarm] – Configure the settings relating to the camera action on alarm occurrence [Alarm]) Click the [Alarm] tab on the “Alarm” page. (→“How to display the setup menu”, “How to operate the setup menu”) The settings related to the camera action on alarm can be configured in this section.
- Page 77 [SNMP transmission upon alarm detection] Click “To SNMP setting” to display the setup menu that can configure the settings relating to SNMP transmission when an alarm occurs. The setup menu will be displayed in a newly opened window. (→“Configure settings relating to FTP/SFTP transmissions of alarm images”) (Operating Instructions –...
- Page 78 33. Add “FTP access to camera” to “Common” in Network setup (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) With the addition of FTP function, “FTP access to camera” was added to “Common” in Network setup. [FTP access to camera] Select “Allow”...
- Page 79 34. Change “SFTP periodic image transmission” to “FTP/SFTP periodic image transmission” in “Schedule” mode (Configure the settings relating to the schedules [Schedule]) By changing the FTP/SFTP function of SFTP function, “SFTP periodic transmission” in “Schedule mode” of schedule setting was changed to “FTP/SFTP periodic transmission”. [Schedule mode] Select an action to be assigned to the schedule from “Schedule mode”.
- Page 80 Position refresh：The camera position will be refreshed at the designated time in the schedule. 1-256：The camera will move to the selected position from the preset position at the designated time in the schedule. Auto track permission：The auto track activation setting set on the [Auto track setting] tab will be permitted during the period of the schedule.
- Page 81 35. Add the log related to FTP/SFTP to system log (Operating Instructions – Others – About the displayed system log) Add a system log related to FTP/SFTP functions. Error display related to FTP/SFTP Category Indication Description ・ The server may be down. Contact the server Server error Failed to find the server.
- Page 82 36. Add Ext.software function (Operating Instructions – Settings) The [Ext.software] menu have been added to the setup menu. ［Ext. software］ Management of the extension software and the schedule setting are available. When the extension software is installed, a link for the screen of the extension software will displayed. (Perform management of the extension software and the schedule setting [Ext.
- Page 83 36.1 Perform management of the extension software and the schedule setting [Ext. software] Management of the extension software and the schedule setting can be performed on the “Ext. software” page. The “Ext. software” page has the [Software mng.] tab, [Operation sched.] tab, and the [Control log] tab. 36.2 Perform the installation, uninstallation and version upgrade of the extension software [Software mng.] Click the “Software mng.”...
- Page 84 “Software mng.” screen When the extension software is installed, unique information of the camera and the registration status of the extension software will be displayed. On this screen, the following operations are available. • Uninstallation of the extension software • Display of the registration status detail screen •...
- Page 85 Unique information [MPR ID] This ID is required to install the extension software. This also has a device ID unique to each camera. [Remaining ROM] The remaining ROM capacity in the camera for the extension software will be displayed. If an extension software to be installed requires more capacity than the ROM capacity displayed here, installation of the extension software is unavailable.
- Page 86 [Status] The installation status of the extension software will be displayed. When “Operable” is displayed, it is in a state that operation of the installed extension software is available. [Setup>>] button In case that the extension software has a unique screen such as a setting screen, it is possible to display the screen.
- Page 87 36.3 Set a schedule of the extension software [Operation sched.] Click the “Operation sched.” tab of the “Ext. software” page. (For menu display and how to operate, refer to “How to display the setup menu” and “How to operate the setup menu”.)
- Page 88 [Operating day of week] Select “Time table 1”, “Time table 2” or “Off” for each day of the week. [Time table 1] [Time table 2] From the pull-down menu, select the start time and the end time of the schedule. To set 24 hours per day, set [00:00] - [00:00].
- Page 89 36.4 Check the control log of extension software [Control log] Up to 200 control logs can be saved on the built-in memory of the camera. When the saved control logs have reached the maximum number, the newer logs will overwrite the older control logs.
- Page 90 37. Add Ext. software mode (Operating Instructions – Configure the basic settings of the camera [Basic] – Configure the settings relating to the SD memory card [SD memory card]) [Ext.software mode] has been added to the SD memory card settings. ［Ext.
- Page 91 38. Add HTML initialization function (Operating Instructions – Reset the settings/Reboot the camera [Default reset] [Load the default HTML files (setup menu).] and [Reset to the default and load the default HTML files.] have been added to the [Default reset] tab. The settings and the HTML data of the camera can be initialized and reboot of the camera can be performed on this page.
- Page 92 39．Add 2fps and 3fps to FTP/SFTP refresh interval, add 1920x1080 to pre-alarm resolution, expand image destination server to 2 locations (Operating Instructions – Configuring the network settings [Network] – Configure advanced network settings [Advanced]) The following have been added to the communication protocol FTP/SFTP function of the file transfer function.
- Page 93 ［Transmission protocol］ Select and set the protocol with the destination server from FTP/SFTP. • SFTP: SFTP is used as the protocol for transmitting with the server. • FTP: FTP is used as the protocol for transmitting with the server. • Default: SFTP IMPORTANT •...
- Page 94 [FTP transmission retry] Select “On” or “Off” to determine whether or not to resend failed FTP transmissions. • On: If transmission fails, transmissions are resent until they are successfully sent. • Off: If transmission fails, the image that failed to be sent is discarded and the next image is sent. •...
- Page 95 Image quality Image 1920x1080 capture 1280x960 size 1280x720 640x360 QVGA 320x180 [Post alarm] • Transmission interval Select the transmission interval for the alarm image transmission from the following. When 60fps mode, 30fps mode or 15fps mode is selected for [Image capture mode]: 0.1fps/ 0.2fps/ 0.33fps/ 0.5fps/ 1fps/ 2fps/ 3fps When 50fps mode, 25fps mode or 12.5fps mode is selected for [Image capture mode]: 0.08fps/ 0.17fps/ 0.28fps/ 0.42fps/ 1fps/ 2fps/ 3fps...
- Page 96 [Directory name] Enter the directory name where the alarm images are to be saved. For example, enter “/ALARM” to designate the directory “ALARM” under the root directory of the server. • Available number of characters: 1 - 256 characters • Unavailable characters: " & ; [File name] Enter the file name used for the alarm image to be transmitted to the server.
- Page 97 [Directory name] Enter the directory name where the alarm images are to be saved. For example, enter “/ALARM” to designate the directory “ALARM” under the root directory of the server. • Available number of characters: 1 - 256 characters • Unavailable characters: " & ; •...
- Page 98 SFTP server settings SFTP server 1 settings SFTP server 2 settings ＜Terminal input/output supported models only＞ Note • When [Transmission protocol] is set to FTP, the SFTP server setting is unavailable. [SFTP server address] Enter the IP address or the host name of the SFTP server. •...
- Page 99 IMPORTANT • When entering the host name for “SFTP server address”, it is necessary to configure the DNS settings on the [Network] tab of the “Network” page. (→“Configure the network settings [Network]”) [Port number] Enter a control port number to be used for the SFTP server. •...
- Page 100 [User name] Enter the user name (login name) to access the FTP server. • Available number of characters: 1 - 32 characters • Unavailable characters: " & : ; ¥ [Password] Enter the password to access the FTP server. • Available number of characters: 0 - 32 characters •...
- Page 101 40．Add 0.5s, 1s, 2s, 3s, and 4s to the alarm deactivation time (Operating Instructions – Configure the alarm settings [Alarm] – Configure the settings relating to the camera action on alarm occurrence [Alarm]) 0.5s, 1s, 2s, 3s, and 4s have been added to the alarm deactivation time. Alarm •...
- Page 102 41．Add schedule setting to switch image quality at sunrise and sunset (Configure the settings relating to the schedules [Schedule]) A function to change the image quality according to the time of sunrise and sunset has been added to the schedule settings.
- Page 103 Configure the settings relating to the schedules [Schedule] On the Schedule page, set the following schedule items. • Alarm permission (Terminal alarm 1,2,3) • Alarm permission (Terminal alarm 1) • Alarm permission (Terminal alarm 2) • Alarm permission (Terminal alarm 3) •...
- Page 104 are set to the image settings of “Scene file is not applied”. Image Quality 3：Scene3（Scene file 3） ：Images are set to the image settings of “Scene file 3” at the designated time in the schedule. When the designated time for the schedule finishes, images are set to the image settings of “Scene file is not applied”.
- Page 105 Note • The colors displayed in Schedule 1 to Schedule 8 represent the colors of the lines displayed in the schedule column at the bottom of the screen. • If the setting time for position refresh and image quality is set at the same time, the image quality will be applied after position refresh is completed.
- Page 106 How to change the image quality based on the time of sunrise/sunset 1. Set the sunrise/sunset times from [Scene settings linked to sunrise and sunset times]. [To scene setting (image quality adjustment)] This is a link to the image quality adjustment for scene setting. [Basic settings] This is a link to the basic settings for setting the time zone.
- Page 107 42．Add enable/disable setting to SNMP agent setting (Operating Instructions – Configuring the network settings [Network] – Configure the settings relating to SNMP) “Enable/Disable” setting for “SNMP” has been added to “SNMP” in the “Advanced” tab of the Network page. SNMP setting ・...
- Page 108 43．Add corridor view mode to image capture mode (Operating Instructions – About the live image types – About image capture mode) Corridor view is a function that corrects the distortion of the upper and lower parts of the fisheye image and displays them side by side.
- Page 109 43.2.1 Types of images that can be displayed by image capture mode type The types of images that can be displayed in “Corridor” and “Fisheye + Corridor” are as follows. Image capture mode Corresponding Image capture mode Image type type installation location 1 monitor Corrido...
- Page 110 43.3 Play back images on the SD memory card Regardless of the resolution of the images saved on the SD memory card, they will be displayed in the size determined according to the “Image capture mode” and “Recording format” settings on the playback page.
- Page 111 44 Add 1280x720 image capture size for Stream (1) and Stream (2) (4 mega pixel model only) (Operating Instructions – Configure the settings relating to images [Stream]) (Operating Instructions – Detailed Settings – Configure the settings relating to images and audio [Image/Audio] – Configure the settings relating to Stream [Image])
- Page 112 Stream Stream (1)/ Stream (2) ［ Image capture size ］ Image capture mode Stream(1) Stream(2) 4 mega pixel [16:9] (30fps mode) 2688x1520 1280x720 4 mega pixel [16:9] (25fps mode) 2560x1440 640x360 1920x1080 320x180 1280x720 4 mega pixel [16:9] (30fps Quad mode) 2688x1520 1280x720 4 mega pixel [16:9] (25fps Quad mode)
- Page 113 45．Add title edit icon next to camera title (Operating Instructions – Monitor images on a PC – About the “Live” page) You can edit the camera title by adding a title edit icon next to the camera title, and then clicking it. ①...
- Page 114 46．Add SD memory card file system format to the “SD memory card” settings (Operating Instructions – Configure the basic settings of the camera [Basic]) – Configure the settings relating to the SD memory card [SD memory card]) SD memory card file system type has been added to [SD Memory Card File System Format].
- Page 115 [Ext. software mode] Set this setting to “On” when the installed Ext. software uses the SD memory card of this product. • On: The Ext. software can use the SD memory card of this product. In that case, you will not be able to use functions of this product such as recording to the SD memory card.
