- Page 1 Revo 10x16 Mini Lathe Manual LAGUNA TOOLS 2072 Alton Parkway Irvine, California 92606 Ph: 800.234.1976 Model Numbers: MLA10X16-1_2-0130 www.lagunatools.com © 2018, Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. All rights reserved.
-
Page 3: Table Of Contents
Table of contents Page number Safety rules Warranty Noise emission Specification sheet Receiving your machine Introduction to your machine Parts of the machine Where to locate your machine Unpacking your machine Assembly and setup Maintenance and troubleshooting Exploded view drawings... -
Page 4: Safety Rules
Safety Rules As with all machinery, there are certain hazards involved with the operation and use of your new machine. Using it with caution will considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator may result. -
Page 5: Warranty
Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machines and accessories sold to be free of manufacturers’... -
Page 6: Noise Emission
All damage must be noted on the delivery documents and signed by you and the delivery driver. You must then contact the seller (Laguna Tools, Inc.) as soon as is practical. If damage is found after delivery, contact the seller as soon as is practical. -
Page 7: Introduction To Your Machine
Laguna Tools, Inc. endeavors to test machines prior to shipping to customers as movement can take place during transportation. It must be noted that additional machine movement can take place between Laguna Tools and delivery to the end user, and some adjustments may have to be undertaken by the customer. - Page 8 Back tool rest (optional) The back tool rest can be swiveled and adjusted to suit the job being turned on the back faceplate. Variable speed control The variable speed control is Back tool rest located on the front of the lathe. The associated electronics are located in a black box at the rear of the lathe.
-
Page 9: Where To Locate Your Machine
Where to locate your machine Before you remove your machine from the packaging, select the area where you will use your machine. There are no hard-and-fast rules for its location, but below are a few guidelines: 1. There should be an area at the front of the machine suitable for comfortable working. -
Page 10: Assembly And Setup
Assembly and setup The machine comes mostly assembled. You will have to assemble the optional back tool rest holder onto the bed of the machine. Clamping Screws Tool rest moved from the bed of the lathe to the back tool rest holder Back tool rest holder 1. - Page 11 Fitting the tail stock rotating center Ensure that the bore of the tail stock is clean. The rotating center has a No. 2 Morse taper that fits into the tail stock. Push the center into the tail stock bore firmly and ensure that it is securely located.
- Page 12 Wrench flats Face plate Fitting and removing the face plate The face plate has flats for a wrench. To remove the face plate from the head stock spindle, insert the knock out rod or a shaft of the same diameter into the hole on the side of the lathe spindle and loosen the face plate with a wrench.
- Page 13 Tail stock Spindle lock The tail stock can be moved to any position on the bed of the lathe. To move the tail stock, unlock the locking handle, slide the tail stock to the required position and lock. The tail stock spindle can be extended and retracted by rotating the handle located at the back of the tail stock.
- Page 14 1. Disconnect the power to the lathe. 2. Loosen the pulley clamp handle. 3. Move the pulley adjustment handle vertically as far as it can go and lock the pulley clamp handle. 4. Move the drive belt to the required set Electrical control box of pulleys.
-
Page 15: Maintenance And Troubleshooting
3. Fit the knock-out rod into the spindle to control the rotation of the spindle and rotate the face plate until it is removed. 4. To fit the new face plate, reverse the procedure. Maintenance General Keep your machine clean. At the end of each day, clean the machine. Wood contains moisture, and if sawdust or wood chips are not removed, they will cause rust. - Page 16 The machine will not stop This is a very rare occurrence, as the machine is designed to fail-safe. If it should occur and you cannot fix the fault, seek professional assistance. The machine must be disconnected from the power and never run until the fault has been rectified.
-
Page 17: Exploded View Drawings
Parts breakdown and exploded view... - Page 20 PARTS LIST FOR MLA10X16-1/2-0130 Part No. Descriptions Q'ty 003201-101 SET SCREW 1/4"-20NC*1/4" 050932-907 FACE PLATE 030214-002 BALL BEARING 6004 006720-100 WAVE WASHER BWW-6302 660114-000 SENSOR RING 380562-901 COLLAR 090167-000 SPINDLE PULLEY 014331-000 POLY V-BELT 230J-5 000201-101 SET SCREW M4*0.7P*6 171962-901 SENSOR BRACKET 000101-101 CAP SCREW...
- Page 21 950588-000 CONTROL BOX ASSEMBLY AC 120V,60HZ / DC 169V,8A .1 921971-000 DOOR PLATE .2 000302-201 PHLP HD SCREW M4*0.7P*6 .3 000303-203 PHLP HD SCREW M5*0.8P*10 .4 006502-200 EXT TOOTH WASHER 5.3*10(BW-5) .5 008004-200 HEX. NUT M5*0.8P .6 950366-000 MOTOR CIRCUIT BOARD AC 120V,60HZ / DC 169V,8A .7 490463-000 OVERLOAD SWITCH...
- Page 22 006002-040 FLAT WASHER 8*30*3t 921457-000 LEVER ASSEMBLY 250492-615 LEVELING FOOT 006712-100 WAVE WASHER 20.9*26.9BWW-6001 922217-000 CORD ASSEMBLY 453011-028 POWER CORD SJT-18AWG*3C*2000L 473001-012 SWITCH CORD SJT-18AWG*3C*420L 230362-000 LOCK KNOB 021316-000 STRAIN RELIEF MG16A-10B-ST 090166-000 MOTOR PULLEY 003001-106 HEX. BOLT 1/4-20NC*5/8" 006304-100 LOCK WASHER 6.5*12.8*1.5t 009105-200...
- Page 23 360361-000 TAILSTOCK QUILL 360369-901 LEADSCREW 010208-000 RETAINING RING ETW-12 050930-000 TAILSTOCK 010001-000 RETAINING RING STW-10 380856-000 TAILSTOCK LEVER 240053-906 QUILL HANDWHEEL 110019-904 HANDLE 380408-905 TAILSTOCK CLAMP BOLT 360933-905 HANDLE SHAFT 042607-000 SAFETY GLASSES 040005-000 HEX WRENCH 040002-000 HEX WRENCH 2.5mm 040003-000 HEX WRENCH...
- Page 24 Laguna Tools is not responsible for errors or omissions. Specifications subject to change. Machines may be shown with optional accessories. © 2018, Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. All rights reserved.
