  • Page 1 OWNER’S MANUAL WR250X 32D-28199-E1...
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the WR250X, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 WR250X OWNER’S MANUAL ©2007 by Yamaha Motor Co., Ltd. 1st edition, September 2007 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ....4-1 Adjusting the clutch lever free Pre-operation check list ....4-2 play ..........6-21 DESCRIPTION ........2-1 Adjusting the brake lever free Left view ...........2-1 OPERATION AND IMPORTANT play ..........6-22 Right view .........2-2 RIDING POINTS........
  • Page 7 TABLE OF CONTENTS Replacing a turn signal light bulb ..6-35 Replacing the license plate light bulb ..........6-36 Replacing an auxiliary light bulb ..6-36 Supporting the motorcycle .....6-37 Front wheel ........6-37 Rear wheel ........6-38 Troubleshooting ......6-40 Troubleshooting charts ....6-41 MOTORCYCLE CARE AND STORAGE ...........7-1 Matte color caution ......7-1 Care ..........7-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAUW0200 TIONS. motorist’s blind spot. Many accidents involve inexperi- MOTORCYCLES SINGLE Safe riding enced operators. In fact, many op- TRACK VEHICLES. THEIR SAFE Always make pre-operation erators who have been involved in USE AND OPERATION ARE DEPEN- checks. Careful checks may help accidents do not even have a cur- DENT UPON THE USE OF PROPER prevent an accident.
  • Page 9 Modifications made to this motorcycle juries. The use of a safety helmet is the not approved by Yamaha, or the re- When loading within this weight limit, single most critical factor in the preven-...
  • Page 10 SAFETY INFORMATION Cargo accessory weight stallation and use of non-Yamaha the motorcycle due to aerody- should be kept as low and close to accessories. Use extreme caution namic effects. Wind may at- the motorcycle as possible. Make when selecting and installing any ac-...
  • Page 11 SAFETY INFORMATION refueling. a flammable source, (e.g., a ker- Take care not to spill any gaso- osene heater, or near an open line on the engine or exhaust flame), otherwise it could catch system when refueling. fire. Never refuel while smoking or in When transporting the motorcycle the vicinity of an open flame.

  • Page 12: Description

    DESCRIPTION EAU10410 Left view 1. Front fork rebound damping force adjusting screw (page 3-13) 8. Helmet holder (page 3-13) 2. Fuse box (page 6-32) 9. Front fork compression damping force adjusting screw (page 3-13) 3. Coolant reservoir (page 6-12) 4. Shock absorber assembly compression damping force adjusting screw (page 3-15) 5.

  • Page 13: Right View

    DESCRIPTION EAU10420 Right view 1. Rear brake fluid reservoir (page 6-23) 2. Air filter element (page 6-15) 3. Rear brake light switch (page 6-22) 4. Engine oil filler cap (page 6-9) 5. Engine oil level check window (page 6-9) 6. Shock absorber assembly rebound damping force adjusting dial (page 3-15)

  • Page 14: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-9) 2. Left handlebar switches (page 3-8) 3. Main switch/steering lock (page 3-1) 4. Multi-function display (page 3-3) 5. Right handlebar switches (page 3-8) 6. Brake lever (page 3-10) 7. Throttle grip (page 6-18) 8.

  • Page 15: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 the engine stalls. 2. Push the key in from the “OFF” po- Main switch/steering lock sition, and then turn it to “LOCK” while still pushing it. EAU10660 3. Remove the key. All electrical systems are off. The key To unlock the steering can be removed.

  • Page 16: Indicator And Warning Lights

    “ON”. If the warning light does not come on 6. Engine trouble warning light “ ” for a few seconds, then go off, have a Yamaha dealer check the electrical cir- EAU11020 Turn signal indicator light “ ” cuit. This indicator light flashes when the...

  • Page 17: Multi-Function Display

    Be sure to stop the vehicle before If the warning light does not come on making any setting changes to the for a few seconds, then go off, have a multi-function display. Yamaha dealer check the electrical cir- cuit. ECA10020 1 2 3 CAUTION: Do not operate the engine if it is overheated.
  • Page 18 INSTRUMENT AND CONTROL FUNCTIONS tal distance traveled) “SELECT 2” and “RESET” but- two tripmeters (which show the tons. distance traveled since they were When the key is turned to “ON”, all last set to zero) of the display segments of the a fuel reserve tripmeter (which multi-function display will appear shows the distance traveled since...
  • Page 19 INSTRUMENT AND CONTROL FUNCTIONS If the fuel level warning light comes on ter must be stopped. (see page 3-2), the display will auto- matically change to the fuel reserve tripmeter mode “F” and start counting the distance traveled from that point. In this case, push the “SELECT 2”...
  • Page 20 INSTRUMENT AND CONTROL FUNCTIONS the digits. Pushing and holding either Changing from the basic mode to Manual start button will increase or decrease the the measurement mode The manual start is the default setting digits continuously until the button is re- With the odometer selected, push the for the stopwatch.
  • Page 21 Yamaha dealer. 3. Push the “SELECT 1” button and Calibrate the distance-compensation NOTE: “SELECT 2” button together to tripmeter as follows.

  • Page 22: Handlebar Switches

    If the display indicates any error codes, combination with the stopwatch. note the code number, and then have a Yamaha dealer check the vehicle. Resetting the distance-compensation tripmeter 1. Check that the stopwatch mea- 1. Dimmer switch “...

  • Page 23: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS Right EAU12500 EAU12820 Clutch lever Horn switch “ ” Press this switch to sound the horn. EAU12660 Engine stop switch “ ” Set this switch to “ ” before starting the engine. Set this switch to “ ”...

  • Page 24: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU12890 EAU12941 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal The shift pedal is located on the left The brake lever is located at the right The brake pedal is on the right side of side of the engine and is used in com- handlebar grip.

  • Page 25: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU44361 EAU13211 Fuel tank cap Fuel To remove the fuel tank cap 1. Insert the key into the lock and turn it counterclockwise as shown. 1. Key 2. Fuel tank cap 1. Fuel level 2. Turn the key clockwise, and then 2.

  • Page 26: Catalytic Converter

    Your Yamaha engine has been de- or other materials that easily signed to use premium unleaded gaso- burn. line with a research octane number of Do not allow the engine to idle 95 or higher.

  • Page 27: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU14281 EAU45200 Helmet holder Adjusting the front fork This front fork is equipped with rebound damping force adjusting screws and compression damping force adjusting screws. EWA10180 WARNING Always adjust both fork legs equal- ly, otherwise poor handling and loss of stability may result.
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS rebound damping force and thereby 2. To increase the compression Compression damping setting: soften the rebound damping, turn the damping force and thereby harden Minimum (soft): adjusting screw on each fork leg in di- the compression damping, turn the 20 click(s) in direction (b)* Standard: rection (b).

  • Page 29: Front Fork Bleeding

    This will in- Spring preload adjustment should be crease the spring preload and harden made by a Yamaha dealer, since this the front suspension. If this occurs, service requires special tools and tech- bleed the front fork as follows.
  • Page 30 INSTRUMENT AND CONTROL FUNCTIONS the adjusting screw in direction (b). 1. Distance A 1. Rebound damping force adjusting dial 1. Compression damping force adjusting Spring preload: Rebound damping setting: screw Minimum (soft): Minimum (soft): Distance A = 216 mm (8.50 in) 25 click(s) in direction (b)* Compression damping setting: Standard:...

  • Page 31: Exup System

    EAU41940 EXUP system range. To obtain a precise adjustment, Always have a Yamaha dealer This model is equipped with Yamaha’s it would be advisable to check the num- service the shock absorber. EXUP (EXhaust Ultimate Power valve) ber of clicks of each damping force ad- system.

  • Page 32: Sidestand

    Yamaha dealer check the system be- the operator in fulfilling the respon- fore riding. sibility of raising the sidestand be- fore starting off. Therefore, check this system regularly as described below and have a Yamaha dealer re- 3-18...
  • Page 33 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 34: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15593 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 35: Pre-Operation Check List

    If necessary, add recommended coolant to specified level. 6-12 Check cooling system for leakage. Check operation. If soft or spongy, have Yamaha dealer bleed hydraulic system. Check lever free play. Adjust if necessary. Front brake Check brake pads for wear.
  • Page 36 PAGE Make sure that operation is smooth. Check cable free play. Throttle grip 6-18, 6-27 If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. Make sure that operation is smooth. Control cables 6-27 Lubricate if necessary.

  • Page 37: Operation And Important Riding Points

    To start the engine after a their functions before riding. position. turnover, be sure to turn the main Consult a Yamaha dealer re- The transmission is in gear with switch to “OFF” and then to “ON”. Fail- garding any control or function...

  • Page 38: Shifting

    1. Shift pedal should be on, otherwise have a 2. Neutral position Yamaha dealer check the electrical cir- cuit. Shifting gears lets you control the amount of engine power available for 3. Start the engine by pushing the starting off, accelerating, climbing hills, start switch.

  • Page 39: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS the neutral position, do not EAU16810 EAU16841 Tips for reducing fuel Engine break-in coast for long periods of time consumption There is never a more important period with the engine off, and do not in the life of your engine than the period tow the motorcycle for long dis- Fuel consumption depends largely on between 0 and 1600 km (1000 mi).

  • Page 40: Parking

    If any engine trouble should occur ans or children are not likely to during the engine break-in period, touch them. immediately have a Yamaha dealer Do not park on a slope or on soft check the vehicle. ground, otherwise the vehicle may overturn.

  • Page 41: Periodic Maintenance And Minor Repair

    Yamaha dealer certain maintenance work correctly. do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 42: Periodic Maintenance And Lubrication Chart

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 43 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √ √ √ √ Check for cracks or damage. 8 * Brake hoses Replace.
  • Page 44 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Brake pedal pivot Lubricate with lith- √...
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check operation and free play. Adjust the throttle cable free Throttle grip hous- √...

  • Page 46: Removing And Installing Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18771 page 3-12.) Removing and installing 2. Remove the bolts and collars. panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed.
  • Page 47 PERIODIC MAINTENANCE AND MINOR REPAIR To install the panel Panel C 1. Place the panel in the original po- sition, and then install the collars To remove the panel and bolts. 1. Remove the bolts. 1. Bolt 2. Panel B To install the panel 1.

  • Page 48: Checking The Spark Plug

    Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. If the spark plug shows signs of elec- trode erosion and excessive carbon or other deposits, it should be replaced.

  • Page 49: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR plug gap should be measured with a of the correct torque is 1/4–1/2 turn EAU45140 Engine oil and oil filter wire thickness gauge and, if necessary, past finger tight. However, the spark element adjusted to specification. plug should be tightened to the speci- fied torque as soon as possible.
  • Page 50 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Start the engine, warm it up for NOTE: several minutes, and then turn it The engine oil should be between the off. minimum and maximum level marks. 3. Place an oil pan under the engine to collect the used oil.
  • Page 51 PERIODIC MAINTENANCE AND MINOR REPAIR install and tighten the oil filler cap. Recommended oil: See page 8-1. Oil quantity: Without oil filter element replace- ment: 1.30 L (1.37 US qt) (1.14 Imp.qt) With oil filter element replacement: 1.40 L (1.48 US qt) (1.23 Imp.qt) NOTE: 1.

  • Page 52: Coolant

    The coolant level should be checked so it will not seize. If this occurs, before each ride. In addition, the cool- have a Yamaha dealer repair the ant must be changed at the intervals vehicle. specified in the periodic maintenance After checking the oil pressure, and lubrication chart.
  • Page 53 PERIODIC MAINTENANCE AND MINOR REPAIR coolant, have a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced. EWA10380 WARNING Never attempt to remove the radiator cap when the engine is hot.
  • Page 54 PERIODIC MAINTENANCE AND MINOR REPAIR 8. Remove the coolant drain bolt to EWA10380 WARNING drain the cooling system. Never attempt to remove the radiator cap when the engine is hot. 1. Bolt 5. Remove the coolant reservoir cap. 1. Coolant drain bolt 9.

  • Page 55: Cleaning The Air Filter Element And Check Hose

    17. Start the engine, and then check the vehicle for coolant leakage. If If water has been used instead coolant is leaking, have a Yamaha of coolant, replace it with cool- ant as soon as possible, other- dealer check the cooling system.
  • Page 56 3. Unhook the holding clip, and then not dripping. pull the air filter element out. Recommended oil: Yamaha foam air filter oil or other quality foam air filter oil 6. Pull the sponge material over the air filter element frame.

  • Page 57: Adjusting The Engine Idling Speed

    If the specified idling speed cannot be idling speed, turn the screw in di- obtained as described above, have a rection (a). To decrease the en- Yamaha dealer make the adjustment. gine idling speed, turn the screw in direction (b). 6-17...

  • Page 58: Checking The Throttle Cable Free Play

    To prevent this cle, note the following points regarding from occurring, the valve clearance the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart.
  • Page 59 WARNING glass fragments in it, or if the sidewall is Because loading has an enormous cracked, have a Yamaha dealer re- impact on the handling, braking, place the tire immediately. performance and safety characteris-...

  • Page 60: Spoke Wheels

    Yamaha dealer, who has the age before each ride. If any dam- cannot be guaranteed. necessary professional knowl- age is found, have a Yamaha After extensive tests, only the edge and experience. dealer replace the wheel. Do not tires listed below have been ap-...

  • Page 61: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU22032 in direction (b). free play, turn the adjusting nut Adjusting the clutch lever free 3. If the specified clutch lever free in direction (b). play play could be obtained as de- 7. Tighten both locknuts. scribed above, tighten the locknut and skip the rest of the procedure, otherwise, proceed as follows.

  • Page 62: Adjusting The Brake Lever Free Play

    A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system. If there is air in the hy- draulic system, have a Yamaha dealer bleed the system before 1. Locknut 1. Rear brake light switch operating the motorcycle.

  • Page 63: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level peared, have a Yamaha dealer replace brake pads the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 64: Changing The Brake Fluid

    Changing the brake fluid ing it to become ineffective. lower the boiling point of the fluid Have a Yamaha dealer change the Before riding, check that the brake fluid and may result in vapor lock. brake fluid at the intervals specified in...

  • Page 65: Drive Chain Slack

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU22760 both chain pullers are in the same posi- Drive chain slack tion for proper wheel alignment. The drive chain slack should be checked before each ride and adjusted if necessary. EAU22773 To check the drive chain slack 1.

  • Page 66: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23022 ECA11110 Tightening torque: Cleaning and lubricating the CAUTION: Axle nut: drive chain Do not use engine oil or any other lu- 125 Nm (12.5 m·kgf, 90.4 ft·lbf) The drive chain must be cleaned and bricants for the drive chain, as they lubricated at the intervals specified in may contain substances that could...

  • Page 67: Checking And Lubricating The Cables

    If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. Recommended lubricant: Engine oil EWA10720 WARNING...

  • Page 68: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23142 bricated if necessary. Recommended lubricant: Checking and lubricating the Lithium-soap-based grease Recommended lubricants: brake and clutch levers Brake lever: Silicone grease Brake lever Clutch lever: Lithium-soap-based grease Clutch lever The operation of the brake and clutch levers should be checked before each ride, and the lever pivots should be lu- 6-28...

  • Page 69: Checking And Lubricating The Sidestand

    2. While applying the front brake, If the sidestand does not move up push down hard on the handlebars and down smoothly, have a Yamaha several times to check if the front dealer check or repair it. fork compresses and rebounds smoothly.

  • Page 70: Checking The Steering

    If any damage is found or the front fork does not operate smoothly, Securely support the vehicle so that have a Yamaha dealer check or re- there is no danger of it falling over. pair it. 2. Hold the lower ends of the front fork legs and try to move them for- ward and backward.

  • Page 71: Checking The Wheel Bearings

    Therefore, keep sparks, flames, cigarettes, etc., To charge the battery away from the battery and pro- Have a Yamaha dealer charge the bat- vide sufficient ventilation when tery as soon as possible if it seems to charging it in an enclosed have discharged.

  • Page 72: Replacing The Fuses

    Replacing the fuses CHILDREN. sealed-type (MF) battery charg- The main fuse is located behind panel er, have a Yamaha dealer D. (See page 6-6.) charge your battery. To store the battery 1. If the model will not be used for...

  • Page 73: Replacing The Headlight Bulb

    3. Turn the key to “ON” and turn on amperage. the electrical circuit in question to check if the device operates. 4. If a fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-33...
  • Page 74 ECA10660 7. Have a Yamaha dealer adjust the CAUTION: headlight beam if necessary. Do not touch the glass part of the headlight bulb to keep it free from...

  • Page 75: Tail/Brake Light

    1. Remove the turn signal light lens If the tail/brake light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Turn signal light bulb 3. Insert a new bulb into the socket, push it in, and then turn it clock- wise until it stops.

  • Page 76: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24310 EAU45220 Replacing the license plate Replacing an auxiliary light light bulb bulb 1. Remove the license plate light unit If the auxiliary light bulb burns out, re- by removing the screws. place it as follows. 1.

  • Page 77: Supporting The Motorcycle

    EWA10820 wheel or performing other maintenance WARNING requiring the motorcycle to stand up- It is advisable to have a Yamaha right. Check that the motorcycle is in a dealer service the wheel. stable and level position before starting Securely support the motorcy- any maintenance.

  • Page 78: Rear Wheel

    To remove the rear wheel ing the brake caliper onto the brake EWA10820 disc. WARNING It is advisable to have a Yamaha 2. Insert the wheel axle. dealer service the wheel. 3. Install the wheel axle pinch bolts Securely support the motorcy- and axle nut.
  • Page 79 PERIODIC MAINTENANCE AND MINOR REPAIR 6. Push the wheel forward, and then remove the drive chain from the rear sprocket. NOTE: The drive chain does not need to be disassembled in order to remove and install the rear wheel. 7. Remove the wheel. ECA11070 CAUTION: 1.

  • Page 80: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 81: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 82 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 83: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10771 CAUTION: advice on what products to use be- used.
  • Page 84 MOTORCYCLE CARE AND STORAGE contact with strong or abrasive washing. ECA10790 cleaning products, solvent or CAUTION: thinner, fuel (gasoline), rust re- Do not use warm water since it in- After normal use movers or inhibitors, brake flu- creases the corrosive action of the Remove dirt with warm water, a mild id, antifreeze or electrolyte.

  • Page 85: Storage

    7. Wax all painted surfaces. NOTE: dry place and, if necessary, protect it 8. Let the motorcycle dry completely Consult a Yamaha dealer for advice on against dust with a porous cover. before storing or covering it. what products to use.
  • Page 86 MOTORCYCLE CARE AND STORAGE fuel from deteriorating. pivoting points of all levers and 3. Perform the following steps to pro- pedals as well as of the sidestand/ tect the cylinder, piston rings, etc. centerstand. from corrosion. 5. Check and, if necessary, correct a.

  • Page 87: Specifications

    SPECIFICATIONS EAU2633N Lubrication system: Fuel: Wet sump Recommended fuel: Engine oil: Dimensions: Premium unleaded gasoline only Type: Fuel tank capacity: Overall length: SAE 20W-40 7.6 L (2.01 US gal) (1.67 Imp.gal) 2115 mm (83.3 in) Fuel reserve amount: Overall width: 2.1 L (0.55 US gal) (0.46 Imp.gal) 810 mm (31.9 in) -20 -10...
  • Page 88 SPECIFICATIONS Operation: Size: Front brake: Left foot operation 140/70R17M/C 66H Type: Gear ratio: Manufacturer/model: Single disc brake BRIDGESTONE/BT090R RADIAL G 1st: Operation: Loading: 37/14 (2.643) Right hand operation 2nd: Maximum load: Recommended fluid: 29/16 (1.813) 185 kg (408 lb) DOT 4 3rd: * (Total weight of rider, passenger, cargo Rear brake:...
  • Page 89 SPECIFICATIONS Battery: Engine trouble warning light: Model: Fuses: YTZ7S Voltage, capacity: Main fuse: 12 V, 6.0 Ah 30.0 A Headlight: Headlight fuse: 15.0 A Bulb type: Signaling system fuse: Halogen bulb Bulb voltage, wattage × quantity: 10.0 A Ignition fuse: Headlight: 7.5 A 12 V, 60 W/55.0 W...

  • Page 90: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 91 EAU26460 Model label 1. Model label The model label is affixed to the loca- tion shown. Record the information on this label in the space provided. This in- formation will be needed when ordering spare parts from a Yamaha dealer.
  • Page 92 INDEX Parking ............5-4 Part locations..........2-1 Air filter element and check hose, Front and rear brake pads, checking ..6-23 Periodic maintenance and lubrication cleaning ..........6-15 Front fork, adjusting .........3-13 chart ............6-2 Auxiliary light bulb, replacing ....6-36 Front fork, bleeding........3-15 Pre-operation check list......
  • Page 93 INDEX Turn signal switch ........3-9 Valve clearance ........6-18 Vehicle identification number.....9-1 Wheel bearings, checking .......6-31 Wheel (front) ..........6-37 Wheel (rear)..........6-38 Wheels.............6-20...
  • Page 96 YAMAHA MOTOR CO., LTD. YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED ON RECYCLED PAPER PRINTED IN JAPAN PRINTED IN JAPAN 2007.11–0.1×1 ! 2007.11–0.1×1 !
