MONO Eco Connect Plus
Convection Oven
Quick Start Guide
EN
Oven Serial Number _________________________________
Oven Code
Condenser Serial Number ____________________________ (if fitted)
In the event of an enquiry, please quote these serial numbers.
FG1BX-UK-QSG-0300 | Rev. B23 (July 2023)
138
149
150
153
158
159
MonoEquip.com
170
173
4/5/7/10-Tray | Steam

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco Connect Plus FG159 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mono Eco Connect Plus FG159

Summary of Contents for Mono Eco Connect Plus FG159

  • Page 1 MonoEquip.com MONO Eco Connect Plus Convection Oven Quick Start Guide Oven Serial Number _________________________________ Oven Code Condenser Serial Number ____________________________ (if fitted) In the event of an enquiry, please quote these serial numbers. 4/5/7/10-Tray | Steam FG1BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 2 Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam Quick Start Guide MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 3 The reset button hole can be at position 1 or 2 depending on the model B. Rear panel of 10-tray oven. The reset button hole can be at position 1 or 2 depending on the model Reset button hole on the rear panel of a 7-tray oven FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...

  • Page 4: Safety Symbols

    Indicates a potential hazard with a medium risk that could result in death or serious physical injury if not avoided. Indicates a hazardous situation that could result in minor or moderate CAUTION injury if not avoided MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)

  • Page 5: Electrical Safety Notice

    The supply to this machine must be protected by a 30mA-rated Type ‘A’  Residual Current Device (RCD). Before installation, it is recommended that a qualified and competent  electrician first tests the electrical outlet (power socket) for electrical safety. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...

  • Page 6: General Notices

     Place an out-of-service notice on the oven.  Contact your oven supplier or MONO Equipment for technical assistance.  Ovens must be maintained and serviced at appropriate intervals to ensure the oven operates at optimum levels. See the General Maintenance section on page 36.
  • Page 7 Quick Start Guide Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam Thank you for purchasing this MONO Eco Connect+ oven. “A combination of clean industrial design and the latest technology.” The information in this quick start guide should get your purchase up and running without any problems. There is a complete Installation and Operating Manual available at www.monoequip.com.

  • Page 8: Specifications

    Can be stacked with a 4/5-tray oven only. Base units are 300 mm up to 920 mm high. Only available for Eco Connect Plus and Eco Connect+ Wash ovens.  Available Optional extra  MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)

  • Page 9: Electrical Specifications

    (Contact factory) (Contact factory) 40cm x 60cm 40cm x 80cm 10-Tray 18” x 26” 18” x 30” 415 Vac (50 Hz), 3-phase + neutral + earth 32 Amps 40cm x 60cm 40cm x 80cm FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 10 − Stop using it. Do not attempt any repairs. − Contact MONO Equipment for technical assistance. − Never operate the oven with any covers or panels removed.  All utility connections to the oven must comply with the statuary requirements of ...
  • Page 11 Never climb onto the roof of the oven.  Only use the oven for baking bread, pastries, and cakes.  Contact MONO Equipment for other product-baking machines. No unauthorised modifications to the oven are permitted.  FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)

  • Page 12: Installation

    Figure 2: Main power supply connections NOTE L2 and L3 are for three-phase installations only.  See the Specifications section for electrical specifications.  MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)

  • Page 13: Water Supply

    When operating an oven in a hard water area, ensure that an efficient water-softening device protects the water supply to the oven. MONO Equipment is not responsible for installing and maintaining an adequate water supply to the oven that complies with local and national water regulations.
  • Page 14 It is the customer’s sole responsibility to arrange for adequate ventilation. Any component malfunctioning during the guarantee period found to have been subject to excessive humidity or ambient working temperature above 40 °C (115 °F) would not be covered by the component manufacturer guarantee or MONO’s product warranty. MONO...

  • Page 15: Electrical Supply

    (Figure Figure 3: View of rear connections on a MONO Eco Connect Plus oven  Turn the appropriate valve 90° anti-clockwise ( ) to turn off the water supply.

  • Page 16: Touchscreen Operations

    Create an oven on/off schedule for every day of the week. Manual Bake Baking using manual controls. Favourites Easy selection of most frequently used baking recipe programs. NOTE: The images are for illustration purposes and may differ from your oven. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 17 The oven goes through a boot-up sequence. Please wait. NOTE The images are for illustration purposes and may differ from your oven. When a start-screen (wallpaper) appears, touch the screen anywhere to display the main screen. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 18 USB flash drive (if supported). Select a baking recipe (a) Touch the baking recipe required (e.g., blueberry muffins). (b) If prompted, select Full Load or Half Load depending on the oven loading. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 19 To maintain the heat in the oven, do not leave the door open for longer than needed. The actual oven temperature fluctuates during a bake – this is normal and not an oven fault. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 20 Press the +2 mins to continue the bake for a further two minutes.  This time extension is adjustable in the Settings menu. − 10. Remove the trays and close the door to preserve the heat. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 21 When the time is 00:00, and the Start button is touched, the timer counts upwards until the bake is stopped. If the screen shows HEATING, wait until the oven is up to temperature before touching Start. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 22 6. When the timer is counting down and reaches 00:00, a sounder is heard. A BAKE OVER message also flashes on the screen. Touch Stop to stop the sounder. 7. The bake can be stopped at any time by touching Stop. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)

  • Page 23: Setting The Time And Date

    NOTE Default passwords for the various access levels are in the Passwords section of this manual. However, for security reasons, the passwords section may have been removed. Touch the Time & Date box. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 24 Touch the Home button to return to the main screen. NOTE Default passwords for the various access levels are in the Installation and Operating Manual. However, for security reasons, the passwords section may have been removed. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 25 Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam Setting up a new program Touch the Programs tile. Choose the category or number group required. Touch the Info (i) button of the next free recipe slot. Touch the Options button. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 26 Repeat steps (c) to (e) for each item needed in that baking phase. If required, select the next baking phase (i.e. touch 2) and adjust the items in the same way. Touch Save to confirm the completed recipe settings. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 27 Touch Save to confirm the tray layout. Add the new product recipe to the list. (a) Touch the Save as… box (b) Input a name for the product recipe, and then touch OK. Touch the Home button to finish. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 28 Set a timer Touch a time-setting box. Adjust the bake time required using up and down keys. Touch the OK () button. Repeat steps (a) to (c) to set different bake time sequences, if required. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 29 (a) Touch a heat-setting box. (b) Type in temperature required. (c) Touch OK to confirm the temperature. Start the bake. (a) Load the oven. (b) Touch the Start button (next to the bake time required). FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 30 10. Touch the Stop button at any time to end a bake, and the same settings are useable again. NOTE The settings are reusable until the Cancel button is touched. Then, cancelling clears the settings for the next time the Multi-bake function is needed. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 31 Touch the day an oven operation is required. Set the On-time. (a) Touch the On tile of a time panel. (b) Set the time using the keys in the pop-up box that appears, and then touch Save (A). FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 32 (b) Set the time using the keys in the box that appears, and then touch Save (A). Touch Save (B) to confirm the 7-day timer settings. NOTE Remember to leave the oven in Standby mode for this 7-day timer function to work. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 33 The Standby button turns the oven off until the screen is touched again. Putting the oven into Sleep mode If enabled in the oven settings, the Sleep button instructs the oven to maintain temperature at a pre-set value. FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...

  • Page 34: Daily Cleaning Instructions

    Do not allow the oven cleaner to get on the control panel. Use a nylon brush to scrub the cabinet wheels (if fitted) with a solution of mild detergent and hot water. NOTE: Using too much water eventually rusts the metalwork. MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 35 Figure 5: Location of the two screws for releasing the inner glass A. Undo the two screws to release the inner glass for cleaning Figure 6: Inner glass panel moved away from the door FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...

  • Page 36: General Maintenance

     Unsafe equipment is dangerous. Do not use the appliance. Isolate the power  supply and contact MONO Equipment or your appointed service agent. Check for frayed or bare cables.  Do not use the machine if frayed or bare cables are visible.
  • Page 37 Quick Start Guide Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam (Intentional Empty Page) FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO...
  • Page 38 Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam Quick Start Guide (Intentional Empty Page) MONO FG0BX-UK-QSG-0300 | Rev. B23 (July 2023)
  • Page 39 Oven Disposal Care should be taken when the machine comes to the end of its working life. All parts should be disposed of in the appropriate place, either by recycling or other means of disposal that complies with local regulations. (In the United Kingdom, the Environmental Protection Act 1990 applies.)
  • Page 40 MONO Equipment is the leading designer and manufacturer of bakery equipment in the United Kingdom. This proud heritage of British craftmanship, combined with a reputation for creating high-quality, innovative products, can be traced back to its origins in 1947. All our bakery equipment is manufactured to the most stringent NQA ISO9001:2015 &...
