- Page 1 Installation Manual - Quick Reference Guide SMA FLEXIBLE STORAGE SYSTEM Increased Self-Consumption with SUNNY ISLAND 3.0M / 4.4M / 6.0H / 8.0H and SUNNY HOME MANAGER FSS-IS-en-42 | Version 4.2 ENGLISH...
- Page 2 The information contained in this document is the property of SMA Solar Technology AG. Publishing its content, either partially or in full, requires the written permission of SMA Solar Technology AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission.
-
Page 3: Table Of Contents
7.4 Commissioning the SMA Flexible Storage System ........ - Page 4 SMA Solar Technology AG FSS-IS-en-42 Installation Manual - Quick Reference Guide...
-
Page 5: Information On This Document
This document summarizes the specific information for the installation of an SMA Flexible Storage System. Circuitry overviews provide the basic principle of how an SMA Flexible Storage System is connected. The structure of the document specifies the chronological sequence for configuration and commissioning. This document does not replace the documentation of the individual products. -
Page 6: Symbols
SMA radio-controlled socket with BLUETOOTH Wireless SMA radio-controlled socket Technology SMA Speedwire Speedwire SMA Speedwire data module for Sunny Island Speedwire data module Sunny Island SMA Speedwire/Webconnect Data Module Speedwire data module Gird-forming generators such as electric generators or utility... -
Page 7: Safety
Quick Reference Guide "SMA Flexible Storage System with Battery Backup Grid"). The SMA Flexible Storage System must only be used in those countries for which it is licensed or in those countries for which it is approved by SMA Solar Technology AG and the grid operator. The grid configuration must be a TN or TT system. -
Page 8: Safety Information
Danger to life from electric shock due to live voltage High voltages are present in the SMA Flexible Storage System. When covers (e.g., an enclosure lid) are removed, live components can be touched, which can result in death or serious injury due to electric shock. - Page 9 Note that the battery charging behavior names used by SMA Solar Technology AG and the battery manufacturer may, in some cases, differ in meaning (for the battery charging behavior of the Sunny Island inverter, see technical information "Battery Management").
-
Page 10: Information And System Description
FNN influence the discharge behavior of the Sunny Island inverter. In systems with one Sunny Island and single-phase PV inverters, the SMA Flexible Storage System reduces the maximum discharge power of the Sunny Island inverter as required. -
Page 11: Requirements Of Vde Application Guide 2510-2
(for details on the SMA Flexible Storage System of SMA Solar Technology AG see the Planning Guidelines "SMA Smart Home" and the Technical Information "List of Approved Lithium-Ion Batteries" at www.SMA-Solar.com). If products are used that have not been approved by SMA Solar Technology AG, the installer is deemed as the manufacturer of the system. -
Page 12: System Information
SMA Solar Technology AG 3.3 System Information Recommendations for battery capacity SMA Solar Technology AG recommends the following minimum battery capacities. The battery capacities apply for a ten-hour electric discharge (C10). • System with one Sunny Island: 100 Ah • System with three Sunny Island inverters: 300 Ah... -
Page 13: System Description
The Sunny Island uses the connected battery for the intermediate storage of excess PV energy. The Sunny Island measures the grid feed-in and the purchased electricity with the SMA Energy Meter or via the energy meter on the Sunny Home Manager. -
Page 14: System With One Sunny Island
4 System With One Sunny Island SMA Solar Technology AG System With One Sunny Island 4.1 Circuitry Overview Figure 1: Circuitry of the SMA Flexible Storage System for TN and TT systems FSS-IS-en-42 Installation Manual - Quick Reference Guide... -
Page 15: Connecting The Sunny Island
SMA Solar Technology AG 4 System With One Sunny Island 4.2 Connecting the Sunny Island Figure 2: Connecting the Sunny Island inverter Position Designation Description / information AC power cable Terminal AC2 Gen/Grid, terminals L, N und PE Utility grid connection with a three-wire cable Conductor cross-section: 6 mm²... - Page 16 4 System With One Sunny Island SMA Solar Technology AG Position Designation Description / information Data cable to Terminal Display Sunny Remote Control Speedwire network cable Terminal ComETH In order to connect the router/network switch, the Speedwire data module Sunny Island must be mounted in the Sunny Island (see Sunny Island Speedwire data module installation manual).
-
Page 17: System With Three Sunny Island Inverters
SMA Solar Technology AG 5 System With Three Sunny Island Inverters 5 System With Three Sunny Island Inverters 5.1 Circuitry Overview Figure 3: SMA Flexible Storage System for TN and TT systems Installation Manual - Quick Reference Guide FSS-IS-en-42... -
Page 18: Connecting The Master
5 System With Three Sunny Island Inverters SMA Solar Technology AG 5.2 Connecting the Master Figure 4: Connecting the master Position Designation Description / information AC power cable Terminal AC2 Gen/Grid, terminals L, N und PE Utility grid connection with a three-wire cable to the line conductor L1 Conductor cross-section: 6 mm²... -
Page 19: Connecting Slave 1 And Slave 2
SMA Solar Technology AG 5 System With Three Sunny Island Inverters Position Designation Description / information Data cable to Terminal Display Sunny Remote Control Speedwire network cable Terminal ComETH In order to connect the router/network switch, the Speedwire data module Sunny Island with the terminal ComETH must be mounted in the Sunny Island (see Speedwire data module Sunny Island installation manual). -
Page 20: Connecting The Sunny Home Manager
6 Connecting the Sunny Home Manager SMA Solar Technology AG Position Designation Description / information AC power cable Terminal AC2 Gen/Grid, terminals L, N und PE Utility grid connection with a three-wire cable Connect slave 1 to line conductor L2, connect slave 2 to line conductor L3. -
Page 21: Commissioning
Requirements: ☐ The SMA Flexible Storage System must be installed in accordance with the circuitry (see Section 4.1 or 5.1). ☐ With a three-phase system, the Sunny Remote Control must be connected to the master. The master is thus defined during basic configuration. - Page 22 7 Commissioning SMA Solar Technology AG When the Sunny Remote Control shows <Init System>, press and hold the button on the Sunny Remote Control. ☑ An acoustic signal sounds three times and the Sunny Remote Control displays the Quick Configuration Guide.
- Page 23 SMA Solar Technology AG 7 Commissioning Set the battery type. LiIon_Ext-BMS: lithium-ion battery VRLA: lead-acid battery with electrolyte absorbed in glass mat or immobilized in gel FLA: lead-acid battery with liquid electrolyte Set the battery capacity for ten-hour electric discharge (for determining the battery capacity, see the Sunny Island Set the nominal voltage of the battery.
- Page 24 7 Commissioning SMA Solar Technology AG If the country data set of the Sunny Island inverter is If the country data set of the Confirm the basic VDE-AR-4105, set the type of feed-in for the PV system Sunny Island inverter is configuration with Y.
-
Page 25: Adjusting The Configuration Of The Sunny Island Inverter
Countries in Which the Configuration Must Be Adjusted In the SMA Flexible Storage System, the Sunny Island inverters are connected to the utility grid and must meet the requirements of the grid operators. Depending on the settings, the Sunny Island inverters fulfill the requirements of the application guide VDE-AR-N 4105:2011-08 or AS4777. -
Page 26: Adjusting The Configuration For Austria
☐ The extended configuration must be performed within the first ten operating hours of the Sunny Island inverter, otherwise an SMA Grid Guard code is required in order to change grid-relevant parameters (application form for the SMA Grid Guard code available at www.SMA-Solar.com). -
Page 27: Preparing Bluetooth Communication
To enable communication between SMA BLUETOOTH devices in the SMA Flexible Storage System, all devices must be set to the same NetID (identification number for SMA Bluetooth network). The NetID is used to distinguish between systems with SMA BLUETOOTH operating in close proximity to one another. - Page 28 "SMA Smart Home"). Requirements: ☐ The SMA Flexible Storage System must be installed in accordance with the circuitry overviews. ☐ The Sunny Home Manager, the Sunny Island and all other Speedwire devices must be connected to the same router. ☐ The basic configuration of the Sunny Island inverter must have been performed (see Section 7.1).
- Page 29 This starts the system. 4. Only when two SMA Energy Meters are installed in the local network, assign the grid feed-in meter and purchased electricity meter to the Sunny Island using Sunny Explorer. To do this, enter the serial number of the grid feed-in meter and purchased electricity meter (see the Sunny Explorer user manual).
-
Page 30: Contact
8 Contact SMA Solar Technology AG 8 Contact If you have technical problems with our products, please contact the SMA Service Line. We require the following information in order to provide you with the necessary assistance: • Displayed error message •... - Page 31 SMA Solar Technology AG 8 Contact Italia SMA Italia S.r.l. United Kingdom SMA Solar UK Ltd. Milano Milton Keynes +39 02 8934-7299 +44 1908 304899 SMA Solar (Thailand) Co., Ltd. 대한민국 SMA Technology Korea Co., Ltd. 서울 +66 2 670 6999...
- Page 32 SMA Solar Technology www.SMA-Solar.com...
