- Page 1 Operating Manual SUNNY ISLAND 3.0M / 4.4M / 6.0H / 8.0H SUNNY REMOTE CONTROL SI30M-44M-60H-80H-BE-en-32 | Version 3.2 ENGLISH...
- Page 2 The information contained in this document is the property of SMA Solar Technology AG. Publishing its content, either partially or in full, requires the written permission of SMA Solar Technology AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission.
-
Page 3: Table Of Contents
SMA Solar Technology AG Table of Contents Table of Contents Information on this Document........... . . 7 1.1 Validity . - Page 4 Table of Contents SMA Solar Technology AG 7.2 Data Storage on SD Memory Card............33 7.2.1 Inserting the SD Memory Card .
- Page 5 SMA Solar Technology AG Table of Contents 10.6.2 Questions Regarding the Sunny Remote Control..........78 10.6.3 Questions Regarding the Battery .
- Page 6 Table of Contents SMA Solar Technology AG 13.2.2.2 Battery (220#) ............... . . 112 13.2.2.3 External/Backup (230#).
-
Page 7: Information On This Document
1 Information on this Document 1.1 Validity This document is valid for the following device types: • SI3.0M-11 (Sunny Island 3.0M) with firmware version 3.2 • SI4.4M-11 (Sunny Island 4.4M) with firmware version 3.2 • SI6.0H-11 (Sunny Island 6.0H) with firmware version 3.1 •... -
Page 8: Typographies
1 Information on this Document SMA Solar Technology AG Symbol Explanation Content that is relevant for SMA Flexible Storage Systems. Content that is relevant for off-grid systems. Information that is important for a specific topic or goal, but is not safety-relevant ☐... -
Page 9: Security
SMA Solar Technology AG. Unauthorized alterations will void guarantee and warranty claims and usually void the operating license. SMA Solar Technology AG shall not be held liable for any damage caused by such alterations. Any use of the product other than that described in the Intended Use section does not qualify as appropriate. - Page 10 2 Security SMA Solar Technology AG Danger to life from electric shocks due to live voltage and risk of injury from short-circuit currents High voltages are present inside the Sunny Island. When the enclosure lid is removed, live components can be touched, which can result in death or serious injury due to electric shock.
-
Page 11: Information On Handling Batteries
SMA Solar Technology AG 2 Security Destruction of the Sunny Island inverter due to electrostatic discharge (ESD) By touching electronic components within the Sunny Island, you can damage or destroy the Sunny Island. • Do not touch any electronic assemblies. - Page 12 Note that the battery charging behavior names used by SMA Solar Technology AG and the battery manufacturer may, in some cases, differ in meaning (for the battery charging behavior of the Sunny Island inverter, see "Battery Management" technical information).
-
Page 13: Product Description
SMA Solar Technology AG 3 Product Description 3 Product Description 3.1 Sunny Island The Sunny Island is a battery inverter and controls the electrical energy balance in off-grid systems, in battery backup systems, or in systems for increased self-consumption. In a battery backup system, you can also use the Sunny Island for increased self-consumption. -
Page 14: Type Label
The type label clearly identifies the product. The type label is located on the right-hand side of the enclosure. You will find the following information on the type label: • Address of SMA Solar Technology AG • Device type (Model) •... - Page 15 SMA Solar Technology AG 3 Product Description Symbols on the Type Label Symbol Explanation Danger to life due to high voltages The product operates at high voltages. All work on the product must be carried out by qualified persons only.
-
Page 16: Sunny Remote Control
3 Product Description SMA Solar Technology AG 3.4 Sunny Remote Control You can configure and control the system from a central location using the Sunny Remote Control display. Figure 3: Layout of the Sunny Remote Control Position Designation Explanation Display Four-line display shows operating data (e.g., operating state, display values) and events, warnings, or errors on the Sunny Island inverter. -
Page 17: Compatable Communication Product
SMA Flexible Storage System (see Quick Reference Guide of the Sunny Island inverter). Sunny Portal is an Internet portal for visualization of the data of the PV system, of SMA radio-controlled sockets and of other components of the SMA Flexible Storage System. In addition, Sunny Portal serves as a user interface for configuring the Sunny Home Manager and SMA radio-controlled sockets (see User Manual of the SUNNY HOME MANAGER in SUNNY PORTAL). -
Page 18: Starting And Stopping The System
4 Starting and Stopping the System SMA Solar Technology AG 4 Starting and Stopping the System 4.1 Switching on the Sunny Island Requirements: ☐ The load-break switch in the DC cable must be closed. ☐ The Sunny Island must not have switched itself off (see Section 10.7 "Charging the Battery After Automatic Shutdown in Off-Grid Systems", page 81). -
Page 19: Stopping The System
SMA Solar Technology AG 4 Starting and Stopping the System 4.3 Stopping the System If you stop the system, the Sunny Island switches from operation into standby mode. In standby mode, the Sunny Island discharges the battery due to its standby consumption. Tip: For longer shut-down periods, switch off the Sunny Island (see Section 4.4, page 19). -
Page 20: Setting Time-Controlled Inverter Operation In Off-Grid Systems
4 Starting and Stopping the System SMA Solar Technology AG Procedure: • Press and hold the "Off" button on the Sunny Island until an acoustic signal sounds. ☑ The inverter LED is off on all Sunny Island inverters. 4.6 Setting Time-Controlled Inverter Operation in Off-Grid Systems Example: Parameter settings for time-controlled inverter operation You want to operate the Sunny Island in inverter operation every Sunday from 10:00 a.m.
