Summary of Contents for Gree SOLEUSAIR SG-WAC-06SE
-
Page 2: Important Safety Instructions
Thank you for choosing a Soleus Air powered by Gree Air Conditioner. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new air conditioner. -
Page 3: Electrical Requirements
ELECTRICAL REQUIREMENTS The electrical ratings for your air conditioner are listed on the model and serial number label located on the front left side of the unit (when facing the front). Specific electrical requirements are listed in the chart below. Follow the requirements below for the type of plug on the power supply cord. -
Page 4: Packing List
PACKING LIST 2/5” 3/4” Sash Lock (1) Screw (4) Screw (6) Packing List: • Sash Lock (1) • Window Air Conditioner • Window Sash Seal • Remote Control • 3/4” Screw for Sash Lock & Accordion • AAA Batteries (2) Panels (6) •... -
Page 5: Specifications
SPECIFICATIONS • Noise level is measured at a distance of 3.28 ft away from the front of the unit in cooling mode. • Power consumption is measured when the fan runs at the highest speed setting. • These specifications are for reference only. For actual data, please refer to the rating label on the unit. Model SG-WAC-06SE SG-WAC-06ESE... - Page 6 INSTALLATION & ASSEMBLY INSTRUCTIONS Some assembly is required for your new air conditioner. Please read and follow these instructions carefully. 1. This air conditioner is designed to be installed in a FIG. 1 standard double-hung window with a window width between 21”...
- Page 7 ASSEMBLY & INSTALLATION (CONT.) Storm Window Requirements Accordion Panel Installation A storm window frame will not allow the air conditioner to Now that you have installed the top rail, you can now install tilt properly which in turn will keep it from draining properly. the accordion panels on each side.
- Page 8 ASSEMBLY & INSTALLATION (CONT.) 3. To secure the lower sash into place, use the sash lock Sash Lock and Foam Seal Installation and a 3/4” screw as shown below (See FIG. 12) MOUNTING HARDWARE FIG. 13 3/4” Screws Sash Lock Tools Needed: 4.
-
Page 9: Using Your Air Conditioner
USING YOUR AIR CONDITIONER 1. Power Button: Turns the air conditioner on and Electronic Control Panel & Remote Control 2. Digital Display: Displays the current room tem- perature or the amount of time left on the timer. Shows the Set Temp when setting the tempera- When the light is on the unit is in This display always shows the room temperature or timer set mode. - Page 10 USING YOUR AIR CONDITIONER (Cont.) • Freezing Conditions: This is a cooling only air • Fan Only Mode: Use Fan Only mode at Low, conditioner. It is not designed for freezing outdoor Med, or High fan speed to provide air circulation conditions.
-
Page 11: Care And Cleaning
Cabinet Cleaning CARE AND CLEANING To clean the air conditioner cabinet: Clean your air conditioner to keep it looking new and to minimize dust build up. Unplug the air conditioner to prevent shock or • a fire hazard. The cabinet and front panel of Air Filter Cleaning the air conditioner may be dusted with an oil- The air filter should be checked at least once... -
Page 12: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTIONS The Air Conditioner will not start The air conditioner is unplugged • Make sure the air conditioner is plug is pushed completely into the outlet • Check the house fuse/circuit The fuse is blown/circuit breaker is breaker box and replace the fuse tripped. - Page 13 TROUBLESHOOTING (CONT.) PROBLEM POSSIBLE CAUSES SOLUTIONS Water is dripping outside Hot and Humid weather. • This is normal The air conditioner is not correctly • Water is dripping inside the room For proper water drainage, make tilted outside. sure the air conditioner is slightly tilted downward from the front of the unit to the rear.
-
Page 14: Warranty
One Year Limited Warranty Soleus International, Inc. warrants the accompanying Soleus Air Powered by Gree Air Conditioner to be free of defects in material and workmanship for the applications specified in its operation instruction for a period of ONE (1) year from the date of original retail purchase in the United States.
