Installation Example - Becker Centronic VarioControl VC421A Assembly And Operating Instructions Manual

Caution
• Risk of injury by electric shock.
• Must be installed by an authorised electrician!
• Only the back of the hand is protected by the device. No protection
against accidental contact!
• Do not bend, shorten or add extensions to the antenna.
• The programming button must be operated with an insulated tool .
1. Connect the VC421A as follows:
2. Programme the transmitter into the receiver (see section "Programming radio
channels")
3. Secure the device in the box.
Note
Ensure that optimum radio reception is achieved.
Installation example
TC52
EINZEL ZENTRAL
