BUTURE JR600 - Stick Vacuum Cleaner Manual

WARNING

[Read this user manual carefully before first use. Keep this manual for further guidance in case]

Please read the user manual carefully before using the product and take safety protection measures to avoid malfunctions caused by accidental operation. If the product is given to another person, please make sure to also include this user manual.
The product provides a free 2-year warranty by default. To extend the warranty to 3 year, please contact sales@ibuture.com in time to activate.
If you have any questions, please contact sales@ibuture.com.

Personal Safety

1. Store it indoors in a dry place and out of the reach of children.
2. This product is suitable for children 10 years old and above. Users with reduced physical functions, sensory or intellectual abilities, or lack of experience and knowledge are advised to use the product safely supervision or guidance and to be aware of the hazards involved.
3. Please pay attention to safety when children or pets near the vacuum cleaner.
4. Children should not clean or use the product without supervision.
5. Use only manufacturer's recommended attachments as described in this manual; misuse or use of any accessory or attachment other than those recommended may present a risk of personal injury.
6. Take extra care when cleaning stairs.
7. Keep the appliance and accessories away from the hot surface.
8. Do not block the appliances' openings or hinder airflow, keep openings free of any objects including dust, lint, clothing, fingers (and all parts of the body).

Electrical Safety

1. Only use batteries and chargers supplied by the manufacturer.
2. Never modify the charger in any way.
3. Do not pull the cord to disconnect it from a socket, grasp the plug and pull to disconnect it.
4. Keep the charger cord away from hot surfaces and sharp edges.
5. The supply cord cannot be replaced. If the cord is damaged the charger should be discarded and replaced.
6. Do not handle the charger or the appliance with wet hands.
7. Do not store, or charge the appliance outdoors.
8. The charger must be removed from the socket before removing the battery, cleaning, or maintaining the appliance.

Battery Safety

1. This appliance includes Li-ion batteries, do not incinerate batteries or expose them to high temperatures, as they may explode.
2. Liquid ejected from the battery may cause irritation or burns.
3. In an emergency contact professional help immediately.
4. Leaks from the battery cells can occur under extreme conditions. Do not touch any liquid that leaks from the battery. If the liquid gets on the skin, wash immediately with soap and water. If the liquid gets into the eyes, flush them immediately with clean water for a minimum of 10 minutes and seek medical attention. Wear gloves to handle the battery and dispose of it immediately in accordance with local regulations.
5. When the battery pack is not in use, keep it away from paper clips, coins, keys, nails, screws, or other small metal objects that could make a connection from one terminal to another.
6. When you dispose of the appliance remove the battery and dispose of the battery safely in accordance with local regulations.

CONTENT OF PACKAGE

Please check and confirm the accessories and parts according to the following sheet before using. If any part is missing or defective, please contact sales@ibuture.com for customer service in time.

Main Body

Accessories List

KNOW YOUR PRODUCT

Product Details

Digital LED Screen

Tip: The" " " " icon will only be displayed when the vacuum is blocked.

Accessory Usage

1. Crevice Brush
   Suitable for cleaning small gaps such as doors and windows, corner of stairs, etc.


2. 2 in 1 Brush
   Suitable for cleaning sofas, seats, etc.



3. Floor Brush
   Suitable for cleaning floor tiles, floors, as well as short and medium hair carpets.



4. Cleaning Brush
   Remove hair, rubbish, and micro dust from the accessories or filters.



ASSEMBLING

Install the Battery

• Slide forward in the direction of the arrow, and the lock is fastened on the rack.


Install the Dust Cup

• Align the protruding part of the main unit with the recessed part of the dust box, push it forward.


Install the Machine

CHARGING

Two Charging Ways

USING

Start the Vacuum Cleaner

In the OFF state, press the ON/OFF button to start the vacuum cleaner.

Change Suction Grade

Rotate Clockwise after Power On or in AUTO Mode

	Press the ON/OFF button to turn on the vacuum, AUTO will display blue light. The vaccum works in AUTO mode, it can automatically adjust the power according to the amount of dust.
	Turn the knob clockwise, and AUTO will display white light. The vacuum enters the manual mode.(10 gears to choose in manual mode)
	When turn clockwise to the MAX mode, MAX will displays red light.
	When the vacuum is on MAX mode turn the knob counterclockwise, the suction power reduces. When the suction power back to lowest, it will be back into AUTO mode. AUTO displays blue light.

Rotate Counterclockwise after Power On or in AUTO Mode

	Press the ON/OFF button to turn on the vacuum, AUTO will display blue light. The vaccum works in AUTO mode, it can automatically adjust the power according to the amount of dust.
	Adjust the knob counterclockwise, the vacuum enters the MAX mode, and MAX will display red light.
	In the MAX mode, continue to adjust counterclockwise, the suction power reduces will in turn (10 gear can be adjusted).
	When the vacuum is on MAX mode, turn the knob clockwise, the suction power back to lowest, it will be back into AUTO mode. AUTO displays blue light.

Adjust the Length of the Tube according to Different Needs

Press the button behind the tube and pull out the tube at the same time to extend the tube.
Press the button and pull the tube back to shorten the tube.

MAINTENANCE

Clean the Motor

Wipe the motor with a soft dry cloth.

Clean the Dust Cup and Filter

*It is recommended to clean once a week and replace it once every 2 months.

1. When the dust reaches the "MAX" mark of the dust cup, please clean it up as soon as possible, or it will affect the vacuuming effect.



2. Press the dust cup cover release button to open the cover and dump the garbage into the trash can.



3. Pull back the button to remove the dust cup.



4. Grab the HEPA filter handle to remove the HEPA filter, sponge and stainless steel filters.



5. Scrape the HEPA filter with a cleaning brush.



6. Rotate the metal filter clockwise to remove it from the filter holder.



8. Leave it to completely dry before installing to the vacuum.


9. Rotate the HEPA filter, sponge and metal filter counterclockwise into the dust cup.



Clean the Air Filter

*It is recommended to clean once every six months and replace it once a year.

Clean the Floor Brush

TROUBLESHOOTING

If there is any problem during use, please check the following troubleshooting table.
If the problem can't be solved, please contact the after-sales email: sales@ibuture.com.

Turn off the vacuum cleaner before maintenance. Otherwise it may cause electric shock or other personal injury.

*When the vacuum cleaner does not work properly, the icon on the screen will light up in red.

Air Channel/Dust Sensor Blocked

When the aluminum tube or dust cup is blocked, the vacuum stops working, cannot be turned on within 10s, and the ""shows red.

Solution: Clean the aluminum tube and the filters in the dust cup.

Brush Roller Tangled

Common Trouble
