Pickering 20-534A User Manual

Gpib high density switching matrix module with self-test
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
pickering
User Manual
SYSTEM 10/20
GPIB High Density Switching
Matrix Module with Self-Test
(Model No. 20-534A)
*Please contact Pickering for alternative
PXI/LXI/USB solutions
Issue 6.1 July 2019
pickeringtest.com
pickering
HIGH DENSITY SWITCHING MATRIX MODULE 20-534A
Page (1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20-534A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pickering 20-534A

Summary of Contents for Pickering 20-534A

  • Page 1 User Manual SYSTEM 10/20 GPIB High Density Switching Matrix Module with Self-Test (Model No. 20-534A) *Please contact Pickering for alternative PXI/LXI/USB solutions Issue 6.1 July 2019 pickeringtest.com pickering HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page (1)
  • Page 2 © COPYRIGHT (2019) PICKERING INTERFACES. ALL RIGHTS RESERVED. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
  • Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

  • Page 4: Product Safety

    STATIC SENSITIVE To indicate that static sensitive devices are present and handling precautions should be followed. REED RELAY MODULE 40-110/115/120/125 GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125 HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page (IV) Page (IV) Page (IV)

  • Page 5: Table Of Contents

    Section 6 Trouble Shooting .................6.1 Installation Problems ............6.1 Section 7 Maintenance Information ............7.1 Relay Lookup Tables .............7.1 PCB and Component Layout ..........7.6 Please use the hyperlinked text to navigate to the page required HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page (V)
  • Page 6 THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page (VI)

  • Page 7: Warnings And Cautions

    Unused slots in the System 10/20 chassis are populated with blanking plates to prevent access to user I/O signals that may be present. Blanking panels are available to order from Pickering in a variety of slot widths. If the product is not used in this manner for example by using an extender card then additional care must be taken to avoid contact with exposed signals.
  • Page 8 THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page (VIII)
  • Page 9 Switching Performance The highest density System 20 double pole matrices currently available from Pickering Interfaces. The 20-534A range of 64 x 4 and 20-535A range of 32 x 8 matrix modules include automatic isolation switching, plug-in expansion and built-in self-test to give complete *Please contact Pickering for alternative switching confidence.
  • Page 10 Selected Channel to Ground: <100pF Mechanical Characteristics & Connectors Open Input to Output: <4pF All 20-534A/535A model versions are housed in a shielded 6U Bandwidth: 5MHz height (262mm) Eurocard module and are 160mm deep. Panel width for all versions is 1.8 Inches.
  • Page 11 SECTION 1 - TECHNICAL SPECIFICATION pickering Ordering Information Very High Density Switching Matrix – 20-534A/535A Product Order Codes Mating Connectors & Cabling 64x4 Matrix, Ruthenium Reed, 1-Pole 20-534A-021 96-Pin ZIF Connector 10-964A-001 64x4 Matrix, Ruthenium Reed, 2-Pole 20-534A-022 ZIF Connector Pins, 100 off...
  • Page 12 Product Order Codes 32 x 10 Matrix, Ruthenium Reed, 1-Pole 20-535A-021 32 x 10 Matrix, Ruthenium Reed, 2-Pole 20-535A-022 HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 1.4...

  • Page 13: Technical Description

    The module comprises a SIMM Controller PCB Assy and a Relay PCB Assy populated with electro- mechanical relays. Additional driver ICs are fitted on the Relay PCB. The 20-534A module is available as a 64 x 4 Matrix utilising either SPST or DPST Normally Open relays. The drivers on the Relay PCB are fed with serial data from the SIMM Controller PCB.
  • Page 14 Please contact Pickering if you wish to discuss your matrix application in greater detail. Pickering can build large Matrix systems constructed and tested to your exact requirements, (especially if your application involves switching RF or very high isolation signals), please contact the sales office for further details.
  • Page 15 SECTION 2 - TECHNICAL DESCRIPTION pickering 20 x 12 Matrix 20 x 12 Matrix 20 x 12 Matrix 20 x 12 Matrix HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 2.3...
  • Page 16 SECTION 2 - TECHNICAL DESCRIPTION pickering THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 2.4...

  • Page 17: Installation

    The module is designed for indoor use only. PRE-OPERATION CHECKS (UNPACKING) 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident. 2. Position the chassis relative to any other equipment the module(s) will connect with. Ensure the chassis is not connected to the electrical supply.
  • Page 18 To achieve the correct initialisation of the sytem, ensure any slave chassis are powered up before the master chassis. Figure 3.2 - Module Guide Rail Position Figure 3.3 - A Partially Built System 20 Front Access Chassis GENERAL PURPOSE REED RELAY MODULE 20-110/115/120/125 HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 3.2 Page 3.2...

  • Page 19: Software Installation

    SECTION 3 - INSTALLATION SECTION 3 - INSTALLATION pickering pickering Figure 3.4 - Module Insertion in a Pickering 20-935A-001 Front Access Chassis SOFTWARE INSTALLATION Refer to the Pickering manual 10-921M. pickeringtest.com For the latest version of the driver please refer to our web site where links to our Software Download page will provide the driver software for the various programming environments encountered.

  • Page 20: Self-Test

    High On Resistance, Low Off Resistance. This string is not intended to be processed by the user’s software, it is suitable for copying directly onto the screen of your control computer. This information will then indicate maintenance required (please contact Pickering for further help).
  • Page 21 ANALOGUE TEST ANALOGUE TEST FAIL ? RELAY COIL TEST RELAY COIL TEST FAIL ? SELF TEST FAILURE SELF TEST PASS ERROR LED ON USE DIAGNOSTIC? COMMAND Figure 3.5 - Self-Test: Basic Flow Diagram HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 3.5...
  • Page 22 SECTION 3 - INSTALLATION pickering THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 3.6...

  • Page 23: Programming Guide

    “0,0" - 0,0 indicates no coordinates set. Note: The 10-920 Interface imposes a maximum limit allowing up to 100 crosspoints to be on at any one time (this is to prevent the power supply becoming overloaded). HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 4.1...
  • Page 24 Return diagnostic string (self-test fail details, if any). Refer to Section 2 for further details *TST? Execute Full Self-Test (IEEE-488.2 query) For further details on programming see the manual for the interface module that is being used. HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 4.2...

  • Page 25: Connector Information

    LED (yellow) Self-Test TEST Currently Running LED (red) error found during self-test WARN LED (red) warning Relays drifting out of range Config Connection Figure 5.1 - Front Panel (20-534A) HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 5.1...
  • Page 26 SECTION 5 - CONNECTOR INFORMATION pickering 1 2 3 4 5 6 7 8 96 Way ZIFF Upper Connector 96 Way ZIFF Lower Connector Figure 5.2 - Pin Outs for 20-534A-021 (Single Pole) HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 5.2...
  • Page 27 X57.2 X58.1 X58.2 X59.1 X59.2 X60.1 X60.2 X61.1 X61.2 X62.1 X62.2 X63.1 X63.2 X64.1 X64.2 Y1.1 Y1.2 Y2.1 Y2.2 Y3.1 Y3.2 Y4.1 Y4.2 Figure 5.3 - Pin Outs for 20-534A-022 (2 Pole) HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 5.3...
  • Page 28 SECTION 5 - CONNECTOR INFORMATION pickering THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 5.4...

  • Page 29: Trouble Shooting

    Refer to the Warnings and Cautions at the front of this manual INSTALLATION PROBLEMS The Plug & Play functionality of Pickering switch cards generally ensures trouble-free installation, however for the GPIB/RS-232 Interface to work correctly there must be at least one switching module present in the rack.
  • Page 30 SECTION 6 - TROUBLE SHOOTING pickering THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 6.2...

  • Page 31: Relay Lookup Tables

    J1 TO M1 FOR ROWS C TO F IN COLUMN 1 SELF-TEST RELAYS J2 TO M2 FOR ROWS C TO F IN COLUMN 2 GENERAL PURPOSE REED RELAY MODULE 10-110/115/120/125 HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 7.1 Page 7.1...
  • Page 32 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.2 - Relay Look-up Table - 1 Pole Matrix relays (Module 20-534A-021) 20-534A RELAY PCB - Signal Path with relay energised Signal Relay Signal Relay Signal Relay Signal Relay X1-Y1 X1-Y2 X1-Y3 X1-Y4...
  • Page 33 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.2 (Cont) - Relay Look-up Table - 1 Pole Matrix relays (Module 20-534A-021) 20-534A RELAY PCB - Signal Path with relay energised Signal Relay Signal Relay Signal Relay Signal Relay X33-Y1 X33-Y2 X33-Y3...
  • Page 34 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.3 - Relay Look-up Table - 2 Pole Matrix relays (Module 20-534A-022) 20-534A RELAY PCB - Signal Path with relay energised Signal Relay Signal Relay Signal Relay Signal Relay X1.1-Y1.1 X1.1-Y2.1 X1.1-Y3.1 X1.1-Y4.1 X1.2-Y1.2...
  • Page 35 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.3 (Cont) - Relay Look-up Table - 2 Pole Matrix relays (Module 20-534A-022) 20-534A RELAY PCB - Signal Path with relay energised Signal Relay Signal Relay Signal Relay Signal Relay X33.1-Y1.1 X33.1-Y2.1 X33.1-Y3.1 X33.1-Y4.1...

  • Page 36: Pcb And Component Layout

    SECTION 7 - MAINTENANCE INFORMATION pickering PCB AND COMPONENT LAYOUT Figure 7.1 - SIMM Controller (A/PC/178) HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 7.6...
  • Page 37 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16 F17 F18 F19 F20 F21 F22 F23 F24 F25 F26 F27 F28 F29 F30 F31 F32 C13 C14 Matrix Self Test Isolation Spare SPARE Relay Relay Relay Relay Figure 7.2 - 64 x 4 Matrix PCB Assy (A/PC/153) HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 7.7...
  • Page 38 SECTION 7 - MAINTENANCE INFORMATION pickering THIS PAGE INTENTIONALLY BLANK HIGH DENSITY SWITCHING MATRIX MODULE 20-534A Page 7.8...
