Locating Materials On A Fan Module - EMC HD400 Disassembly Instructions Manual

Table 3 Assemblies on the Front and Rear
Item Component
1 Front Panel Assembly
2 3 Fan Modules
3 2 Power Supplies

9.0.2.1 Locating materials on a Fan Module

Figures 5a and 5b, along with Table 4 identify components on the fan module.
8
Figure 5a – Components on Fan Module
Item Component
4 Suitcase Assembly
5 Suitcase Assembly Handle
WEEE Disassembly Instructions for the
HD400 Disk Processor Enclosure
6
7
10
