Excel Quest Owner's Manual page 13

Arm Installation
1. Loosen the arm width adjustment screw from the arm receiver tube at the bottom rear of
the seat frame. See figure 5.
2. Insert the arm into the arm receiver tube, so that the arm pad faces toward the front of the
unit.
3. Adjust the width of the arm.
4. Tighten the arm width adjustment screw to secure the arm in place.
5. Repeat steps 1 – 4 for the opposite side.
Joystick Installation
1.
Loosen the joystick adjustment screw located under the armrest. See figure 6.
2.
Insert the joystick mounting tube into the joystick bracket under the armrest.
3.
Adjust the position of the joystick to a comfortable spot.
4.
Tighten the joystick adjustment screw to secure the joystick.
5.
Connect the joystick cable and secure it by placing it into the Cable tie on the side of the
arm assembly.
EXCEL QUEST | USER MANUAL
Figure 5
13
