Excel Quest Owner's Manual page 12

Seat Installation
1.
Fold the seat backrest down.
2.
Grasp the seat firmly on each side, lift the seat and align the seat pin with the hole in the seat
post receiver. See figure 4.
weight. Removal of arms will reduce the weight of the seat. Please ask for help if you do not feel
capable of safely lifting that much weight.
3.
Insert the seat into the seat post.
4.
Push down on the seat to lock into place. Move the seat from side to side to make sure it is
locked into place.
to the desired position. Release the handle to lock the seat in position.
EXCEL QUEST | USER MANUAL
Refer to the "Technical Specifications" section in this manual for the seat
Figure 4
To rotate your seat, pull up on the seat rotation lever and rotate the seat
Make sure the seat is correctly installed and locked before using your power
chair.
Never pull on the arms or use them as a handle to move the power chair as
they could inadvertently pull out of the receiver bar causing injury.
12
