  • Page 1 Original instructions Champ ..12 ..15 ..19 ..24 ..28 ..32 ..36 ..40 ..45 ..49 ..53 ..57...
  • Page 2 Champ The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Les pages de présentation contiennent principalement des images. Consulter la page correspondant à la langue souhaitée. Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung der verwendeten Texte in englischer Sprache, siehe die entsprechenden Sprachseiten.
  • Page 3: Wall Mounting

    [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] CPF02 CPF12 CPF22 CPF32/33 Wall mounting Ceiling mounting FC Frico Control FC Frico Control Minimum mounting distance Type Type min 850 mm [mm] [mm] CPF02 CPF02 CPF12 CPF12 CPF22 CPF22 CPF32/33 335...
  • Page 4: Open The Unit

    Champ Open the unit Opening the unit FC control box ×2 Control FC control box FC control box Control...
  • Page 5 Champ Connection Frico Control Adjustment louvres EN: The louvres are manually adjusted to the desired angle. FR: Les ailettes peuvent être réglées manuellement à l'angle souhaité. DE: Die Lamellen werden manuell auf den gewünschten Winkel eingestellt. SE: Lamellerna justeras manuellt till önskad vinkel.
  • Page 6 Champ Accessories 3 SWFTN 2 SWB 1. Fan heater Champ 2. Mounting brackets SWB 3. Basic filter SWFTN 4. Filter section, deep-pleated bagfilter EU3 SWF 5. Return air intake SWD 6. Extra air director SWLR 1. Fläktluftvärmare Champ 5 SWD 2.
  • Page 7 Champ Filter section, SWF Service hatch ø20 288 42,3 Item Type Used for [mm] [mm] [mm] [mm] [mm] 10113 SWF1 CPF12 10115 SWF2 CPF22 10117 SWF3 CPF32/33 Guide Return air intake, SWD Item Type Used for [mm] [mm] [mm] [mm]...
  • Page 8 Champ Control systems FC Frico control The fan heater must be supplemented with a FC control system. FCDF - FC Direct FCSF - FC Smart FCCF FCBC10 FCLAP FCCF FCBC05 FCPF - FC Pro FCBF - FC Building FCCF FCBC10...
  • Page 9 Champ Valve systems Item Type Flow range VPFC number [l/s] VPFC15LF DN15 0,012-0,068 238293 238294 VPFC15NF DN15 0,024-0,13 VPFC20 DN20 0,058-0,32 238295 VPFC25 DN25 0,10-0,60 238296 VPFC32 238297 DN32 0,22-1,03 See separate manual. Item Type number 333340 UNSG20R15 G20 x R15...
  • Page 10: Technical Specifications

    Champ Technical specifications Champ (IP44) Voltage motor: 230V~ Item Type Heat Airflow Sound Sound Water Amperage Weight ∆t* number output* power* pressure volume throw [kW] [m³/h] [dB(A)] [dB(A)]* [°C] [l]* [kg] 6V/10V* 6V/10V* 6V/10V* 6V/10V* 6V/10V* 6V/10V* 6V/10V* CPF02 333750...
  • Page 11: Internal Wiring Diagram

    Champ Internal wiring diagram A1 A2 B1 B2 D1 D2 Termination Actuator 230V IN BUS 1 BUS 2 Wiring diagrams for control system in the FC manual.
  • Page 12: General Instructions

    For minimum distance, see diagrams on the Application introduction pages. Champ is a quiet running fan heater which, together with the FC control system, can Mounting with brackets provide fully automatic room heating, The fan heater is mounted on the wall or the adaptable to every unique application.
  • Page 13: Electrical Installation

    (if any). When regulations. the filter section SWF is used and indoor air Champ is fitted with a 1.8 m cable with plug quality is normal, cleaning once a year is usually for connection to earthed outlet sockets. The sufficient.
  • Page 14: Troubleshooting

    Champ Filter section SWF Safety The filter in the filter section SWF is a deep- • Keep the areas around the air intake and pleated bag filter, type EU3 (G85). It must be exhaust grilles free from possible obstructions! replaced when the pressure drop reaches or •...
  • Page 15 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net...
