Frico Elztrip EZ106N Original Instructions Manual
Elztrip ez100 series
Hide thumbs
Also See for Elztrip EZ106N:
- Original instructions manual (10 pages) ,
- Original instructions manual (12 pages) ,
- Original instructions manual (13 pages)
Related Manuals for Frico Elztrip EZ106N
Summary of Contents for Frico Elztrip EZ106N
- Page 1 Original instructions Elztrip EZ100 600 - 1500 W ..9 ..13 ..15 ..18 ..11 ..21 ..24 ..27 ..29...
- Page 2 Regulation also does not apply to installations in vehicles, offshore or outdoors. Many of Frico's products can be used as both local space heaters (as defined in (EU) 2015/1188) and for technical heating purposes. It is up to the installer responsible for the installation to assess whether the Ecodesign Regulation is applicable or not.
- Page 3 от замерзания и т. д. Также требования Экодизайн не применяются в случае установки оборудования в транспортных средствах, сооружениях на море и на открытых площадках. Многие виды оборудования Frico могут применяться как в качестве приборов локального обогрева (как определено нормативами (EU) 2015/1188) так и в качестве составных частей...
- Page 4 Elztrip EZ100 [mm] [mm] EZ106N EZ111N 1470 1252 EZ115N 1950 1731 EZMVK EZ100 Accessory Type EZMVK...
- Page 5 Elztrip EZ100 a < H Dh = 1,5 - 2 m EZ100 [mm] 1800...
-
Page 6: Technical Specifications
Elztrip EZ100 Technical specifications Type Heat Voltage Amperage Max. surface Dimensions Weight output temperature LxHxW [°C] [mm] [kg] EZ106N 230V~ 870x50x150 EZ111N 1100 230V~ 1470x50x150 EZ115N 1500 230V~ 1950x50x150 Protection class: IP44 CE compliant. Controls Type HxWxD [mm] 87x87x53 TAP16R 87x87x55 TEP44 82x88x25... -
Page 7: Internal Wiring Diagram
Elztrip EZ100 Wiring diagrams Internal wiring diagram 230V ~ Control by thermostat Thermostat only Thermostat and black bulb sensor °C °C °C °C TAP16R TAP16R TAP16R TAP16R °C °C TAP16R TAP16R 230V 230V 230V 230V 230V 230V EZ100 EZ100 EZ100 EZ100 SKG30 SKG30... - Page 8 Elztrip EZ100 Wiring diagrams Control by thermostat - for installations not covered by the Ecodesign Regulation (EU) 2015/1188 230V~ Thermostat...
-
Page 9: Operation
Elztrip EZ100 Installation and operating instructions General Instructions that the guide pegs are fitted into the holes, to Read these instructions carefully before ensure that the heater is fixed in a horizontal installation and use. Keep this manual for position. Fasten the screws. future reference. - Page 10 Elztrip EZ100 - Room temperature control with open eliminated from the element. The drying time can vary from a few hours to a few days. window detection As a preventive measure, the unit should - Black bulb sensor occasionally be run for a short time when it is •...
- Page 11 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
