Summary of Contents for Frico Infrasmart IP24
- Page 1 Original instructions Infrasmart IP24 IHS20W/B/G24 ..6 ..9 ..12 ..15 ..19 ..26 ..32 ..22 ..29 ..35 ..39...
- Page 2 Infrasmart IP24 - IHSxxx24 Dimensions Operation range of IR-remote: 120° SE: Mottagning fjärrstyr: 120° EN: Operation range of IR-remote: 120° NO: Driftsområde for IR-fjernkontroll: 120° DE: Betriebsbereich der IR-Fernsteuerung: 120° Радиус действия инфракрасного пульта дистанционного управления: 120° FR: Angle de détection de la télécommande IR : 120°...
-
Page 3: Installation Height
Infrasmart IP24 - IHSxxx24 Positioning Installation height 1,8–2,5 m 2–3,5 m Fig.1: The heaters should heat from at least two directions for even heating SE: För jämn uppvärmning bör infrorna värma från minst två håll. NO: For jevn oppvarming bør infraene varme fra minst to sider. - Page 4 Infrasmart IP24 - IHSxxx24 Accessories KLS1KS BCDF IHXH IHXL 92865 KLS1KS 92848 BCDF209010 RAL9010 92849 RAL9005 BCDF209005 92850 BCDF207016 RAL7016 16975 IHXH* 16976 IHXL* 153371 IHG2000SL 2000W *) See separate manual. SE: Se separat manual. NO: Se egen håndbok DE: Siehe separates Handbuch.
-
Page 5: Technical Specifications
Infrasmart IP24 - IHSxxx24 Technical specifications Infrasmart IP24 Item Type Heat Voltage Amperage Colour Max. filament Length Weight number output temperature [°C] [mm] [kg] 92806 IHS20W24 2000 230V~ White 1800 92807 IHS20B24 2000 230V~ Black 1800 92808 IHS20G24 2000 230V~... - Page 6 When the unit is used for the first time or The Frico Infra app is available for both iOS after a long period of disuse, smoke or odour and Android. It has a range of up to 50 m and may result from dust or dirt that has collected can control up to 8 infrared heaters.
- Page 7 Infrasmart IP24 - IHSxxx24 Maintenance Safety The power supply to the unit must be • For all installations of electrically heated disconnected during all service, repair and products should a residual current circuit maintenance work. breaker 300 mA for fire protection be used.
-
Page 8: Remote Control
Control Bluetooth - Frico Infra app Heizstrahlern Infrasmart is controlled via an app, the The Frico Infra app is available for both iOS Individuelle Heizstrahlerbenennung und included remote control, or the built-in push and Android. It has a range of up to 50 m and Kontrolle button. - Page 9 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net.
