PEERLESS PLC Installation And Assembly

Installation and Assembly - Secure Ceiling Mount
IMPORT T T T T ANT! IMPOR IMPOR ANT! ANT!
IMPOR IMPOR ANT! ANT! Read entire instruction sheet
before you start installation and assembly.
This product must be
installed by a qualified,
R
professional installer.
Before you start check the parts list below to make sure all of the parts listed are included.
description
A support arm retainer
B adapter
C ceiling support arm
D cover plate
E ceiling arm box
F tilt hook box
G M10 x 1.5 x 15 mm penta-pin screw
H retainer pin (long)
I retainer pin (short)
M
F
E
Note: some parts may not appear exactly as illustrated.
IMPORTANT: If you will install an extension
1
column, DO NOT INSTALL THIS PIPE. Begin with
step 2.
Thread threaded, notched pipe (J) into threaded fitting
in ceiling plate (M). Tighten four or five complete turns
leaving slot aligned with one small hole in the side of
the ceiling plate (M) threaded fitting. Insert and tighten
one M5 x .8 x 1 penta-pin
the small penta-pin tool (Q) and a 1/4" driver to drive
screw (O).
Visit the Peerless Web Site at www.peerlessindustries.com
Parts List: Secure Ceiling Mount
qty. part #
1 590-1007
1 590-1009
1 100-1001
1 100-1006
1 100-1005
1 200-1552
8 520-9263
1 5M9-025-X02
1 560-9643
A
D
J
B
N
™ screw (O) as shown. Use
penta-pin tool
IMPOR IMPOR IMPOR IMPORT T T T T ANT! IMPOR
ceiling will safely support the combined weight
of the screen and mounting hardware.
description
J threaded notched pipe
K adhesive vinyl (not shown)
L #14 x 2.5 wood screw
M ceiling plate
N ceiling plate end cap
O M5 x .8 x 10 penta-pin screw
P penta-pin tool ™ (large, not shown) 1
Q penta-pin tool (small, not shown)
L
C
M
J
1 of 4
ISSUED:10-19-01 SHEET #: 200-9264-3 07-26-04
For customer service call 1-800-729-0307 or 708-865-8870.
Model: PLC
ANT! ANT! ANT! Installer must verify that the ANT!
qty. part #
1 200-0008
1 600-1004
4 5S1-015-C03
1 128-1039
2 2PT-22CA01D
3 505-9010
520-9260
1 520-9249
G
O
O
H
I
threaded
fitting
