- Page 1 SITE PREPARATION GUIDE NCR RealPOS 25 (7610)POS Release 2.0 B005-0000-2018 Issue C...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
- Page 3 Audience This book is written for hardware installer/service personnel, system integrators, and field engineers. Notice: This document is NCR proprietary information and is not to be disclosed or reproduced without consent. Safety Requirements The NCR RealPOS 25 conforms to all applicable legal requirements. To view the compliance statements see the NCR RealPOS Terminals Safety and Regulatory Statements (B005-0000-1589).
- Page 4 Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that accept the product’s plug. Repair or replace damaged or worn cords immediately. References • NCR RealPOS 25 User Guide (B005-0000-2017) • NCR RealPOS 25 Hardware Service Manual (B005-0000-2019) • NCR RealPOS 25 Parts Identification Manual (B005-0000-2020)
-
Page 5: Table Of Contents
Terminal and Table Top Stand w/Power Supply Enclosure Terminal w/Customer Display Dimensions 7409-K502 Flush Wall Mount Dimensions VESA Mounting Hole Dimentions NCR 5943 LCD / 5967 12-Inch Touch LCD Dimensions 5943 LCD / 5967 15-Inch Touch LCD Dimensions NCR 5976 2x20 LCD Dimensions Tall Pole Mount Base Plate Mounting Hole Dimensions NCR 5982 6.5-Inch LCD Dimensions... - Page 6 NCR 2181 Cash Drawer Dimensions NCR 2183 Compact Cash Drawer Dimensions NCR 2185 Flip Top Drawer Dimensions NCR 2186 Compact Cash Drawer Dimensions Component Weights Shipping Weight Estimate Service Clearance Requirements Airflow Requirements Electrical Requirements 7610 Terminal Power Requirements Peripheral Power Requirements...
-
Page 7: Ncr Realpos 25 Terminal Site Preparation
Introduction This document provides the information necessary to prepare a site to NCR specifications prior to installing an NCR RealPOS 25 terminal (also referred to as the NCR 7610). Prepare the site properly before installing the terminal because site preparation deficiencies may be difficult to detect and correct after installation. -
Page 8: Customer Responsibilities
• Provide and install floor coverings and environment systems that limit or control static electricity build-up and discharge In general, keep the NCR equipment area free from dust, smoke, lint, and other particles. Restrict smoking, eating, and drinking around the equipment. Avoid locating... -
Page 9: Third Party Peripheral Certification
Third party peripherals must be certified with the POS terminal or a potential ESD issue can occur. Third party peripherals include any electrically powered devices connected to the POS terminal that is not an NCR branded product or a certified solution advocated by NCR. Examples of third party products include printers, external CD- ROM drives, cash drawers, cigarette boxes, pin pad devices, etc. -
Page 10: Environmental Requirements
NCR RealPOS 25 Terminal Site Preparation Environmental Requirements Barometric Pressure The terminal operates within the following barometric pressure conditions: • Maximum operating altitude: 3,000 m (9,843 ft.) • Operating range of pressure: 105 to 69 kPa (15.2 to 10.0 lb./in.) Temperature The terminal operates over the temperature ranges shown below. -
Page 11: Dimensions
NCR RealPOS 25 Terminal Site Preparation Dimensions Terminal w/MSR... -
Page 12: Terminal And Table Top Stand Dimensions
NCR RealPOS 25 Terminal Site Preparation Terminal and Table Top Stand Dimensions Terminal and Table Top Stand w/Power Supply Enclosure... -
Page 13: Terminal W/Customer Display Dimensions
NCR RealPOS 25 Terminal Site Preparation Terminal w/Customer Display Dimensions 7409-K502 Flush Wall Mount Dimensions Note: The Terminal Cable Cover cannot be fully opened when using the Flush Wall Mount but can be easily removed to access the cables and power switch. -
Page 14: Vesa Mounting Hole Dimentions
NCR RealPOS 25 Terminal Site Preparation VESA Mounting Hole Dimentions Third?Party Mounts can be designed for the 7610 Display Head. The back panel of the 7610 has VESA compliant screw holes (M4) that are to be used for this purpose. The M4... -
Page 15: Ncr 5943 Lcd / 5967 12-Inch Touch Lcd Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 5943 LCD / 5967 12-Inch Touch LCD Dimensions 5943 LCD / 5967 15-Inch Touch LCD Dimensions... -
Page 16: Ncr 5976 2X20 Lcd Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 5976 2x20 LCD Dimensions... -
Page 17: Tall Pole Mount
NCR RealPOS 25 Terminal Site Preparation Tall Pole Mount There are four different length posts available for the 5976 display, in four inch increments. Note: Heights greater than 215 mm (8.5 in.) should be screwed to the counter top. -
Page 18: Base Plate Mounting Hole Dimensions
NCR RealPOS 25 Terminal Site Preparation Base Plate Mounting Hole Dimensions NCR 5982 6.5-Inch LCD Dimensions... -
Page 19: Power Supply Dimensions
NCR RealPOS 25 Terminal Site Preparation Power Supply Dimensions Power Supply Bracket... -
Page 20: Ncr 5932-5Xxx Usb Big Ticket Pos Keyboard Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 5932-5xxx USB Big Ticket POS Keyboard Dimensions 5932-65xx PS/2 Compact Keyboard Dimensions... -
Page 21: Ncr 5932-66Xx Usb Compact Keyboard Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 5932-66xx USB Compact Keyboard Dimensions NCR 7167 Printer Dimensions... -
Page 22: Ncr 7168 Printer Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 7168 Printer Dimensions NCR 7197 Thermal Receipt Printer Dimensions... -
Page 23: Ncr 7198 Thermal Receipt Printer Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 7198 Thermal Receipt Printer Dimensions NCR 2181 Cash Drawer Dimensions... -
Page 24: Ncr 2183 Compact Cash Drawer Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 2183 Compact Cash Drawer Dimensions NCR 2185 Flip Top Drawer Dimensions... -
Page 25: Ncr 2186 Compact Cash Drawer Dimensions
NCR RealPOS 25 Terminal Site Preparation NCR 2186 Compact Cash Drawer Dimensions Component Weights Terminal Component lbs. 13.5 7610 Terminal 2181 Cash drawer 13.3 2185 Cash Drawer 12.3 27.0 2186 Cash drawer 12.3 27.0 5943 12.1" LCD 5943 15" LCD 5967 12"... -
Page 26: Shipping Weight Estimate
NCR RealPOS 25 Terminal Site Preparation Shipping Weight Estimate To obtain the total maximum weight of a specific configuration, add the weights of the appropriate individual components. The following table provides an example. Terminal Component lbs. 13.5 Base unit 5943 15-Inch LCD... -
Page 27: Airflow Requirements
NCR RealPOS 25 Terminal Site Preparation Airflow Requirements Do not block the air vents on the terminal or peripherals. These vents are necessary for cooling. Do not place the terminal in an enclosed area where sufficient ventilation is not available. Leave at least 100 mm (4 inches) of clearance on sides where air vents are located. -
Page 28: Electrical Requirements
Note: The RealPOS 25 does not offer an AC convenience outlet for CRT power. A separate country-specific power cord must be ordered separately. Available NCR power cords are described in the System Cables section. -
Page 29: Cable Routing
NCR RealPOS 25 Terminal Site Preparation Cable Routing Peripheral cable connectors are located inside the Terminal Cable Cover on the bottom of the terminal. The cables are routed out the opening in this cover and down through the Terminal Stand. - Page 30 NCR RealPOS 25 Terminal Site Preparation 1. Remove the Stand Cable Cover by pressing the button detents on the sides of the cover and then pivoting the top away from the stand.
-
Page 31: Customer Display Configuration
NCR RealPOS 25 Terminal Site Preparation 2. Route the cables through the Cable Strain Relief and over the Cable Guide as shown below. 3. Replace the Stand Cable Cover. Customer Display Configuration If configured with a Customer Display the cables are routed from the bottom of the... -
Page 32: Custom Enclosures
NCR RealPOS 25 Terminal Site Preparation Custom Enclosures The 7610 can be installed in customer provided custom enclosures, where the 7610 is face-mounted inside the enclosure. Mount the 7610 in the enclosure using screws of the proper length and type for the... - Page 33 NCR RealPOS 25 Terminal Site Preparation Use the dimensioned illustration below for reference when designing the custom enclosure.
-
Page 35: Appendix A: Transientprotection
Improvement of any deficiencies in power quality is a customer responsibility. Malfunction and/or component failure as a result of power quality problems are/is not covered by the NCR Maintenance Agreement. NCR accepts no liability for any such occurrence nor for its consequences. -
Page 36: Data Line Transient Protection
Note: NCR provides a full line of both AC power and data line transient surge suppressors to protect your RealPOS system and reduce downtime and extend the life of the RealPOS Retail Solution. For sizing and product information, please call NCR Site Preparation Services at 800-257-0458.
