Rev. 905-0273-Z1
3G-SDI/HD-SDI
FULL HD CMOS Color Camera
VCC-HD5
Product Specifications
& Operational Manual
(Preliminary)
CIS Corporation
©2022 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-HD5 and is the answer not in the manual?

Questions and answers

Summary of Contents for CIS VCC-HD5

  • Page 1 Rev. 905-0273-Z1 3G-SDI/HD-SDI FULL HD CMOS Color Camera VCC-HD5 Product Specifications & Operational Manual (Preliminary) CIS Corporation ©2022 CIS Corporation. All rights reserved.
  • Page 2: Table Of Contents

    Indication of OSD Menu ..........................22 6.3. OSD Menu Hierarchical Structure ........................ 23 Dimensions ................................25 Case for Indemnity (Limited Warranty) ........................26 8.1. Product Warranty ............................26 8.2. CMOS Defective Pixels ..........................26 8.3. Product Support ............................26 ©2022 CIS Corporation. All rights reserved.
  • Page 3: Handling Precautions

    □ Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera module. □ Since VCC-HD5 is a highly dense camera module, please apply appropriate heat dissipation such as installing a metal base to the camera.
  • Page 4: Product Outline

    VCC-HD5 Rev. 905-0273-Z1 Product Outline VCC-HD5 is a 3G-SDI interface, full HD color camera module using a 1/1.8” global shutter CMOS image sensor. Features CIS proprietary ISP, Clairvu™ image processing engine, for superb imaging quality and high speed processing. Supports AE, auto white balance, color correction, edge enhancement, noise reduction, gamma, genlock, external sync, and other function.
  • Page 5: Specifications

    Average, Center-Weighted, Spot, Backlight Compensation Flicker cancellation ON, OFF: Power frequency 50Hz, 60Hz Edge enhancement OFF, 1~7 Color correction Auto, Standard, Fluorescent Light, Tungsten Lamp Saturation adjustment 0%(B/W)~100%(typ.)~200% Cyan suppression adjustment 0~15 Color saturation suppression OFF, 1~7 ©2022 CIS Corporation. All rights reserved.
  • Page 6 The difference does not affect the resolution of the video signal. Some 3G-SDI receivers correspond to either Level A or B, whereas other receivers correspond to both Levels, so please set the camera mode to match your 3G-SDI receiver. ©2022 CIS Corporation. All rights reserved.
  • Page 7: Part Names And Functions

    Connecting to such equipment may cause malfunction. ⑥ Screw holes for camera installation Screw holes to install camera. Please note that depth of the front screw holes and the rear screw holes are different. ©2022 CIS Corporation. All rights reserved.
  • Page 8: External Connector Pin Assignment

    Model name: M03-A41A0 (Marushin Electric Mfg. Co., Ltd) Pin No. Description Power(+5V) *For option TXD(Camera) RXD(Camera) Connection of φ3.5 (4 poles) connector (RS-232C) N.C. N.C. 9 p in D -S u b(f e m ale ) ©2022 CIS Corporation. All rights reserved.
  • Page 9: Camera Functions

    Under this condition, if no signal is input to the LTC IN terminal, internal time code starts with the set time code. Signal Format: SMPTE Time code Signal Level: 0.5 ~ 2[Vp-p] ©2022 CIS Corporation. All rights reserved.
  • Page 10: Defective Pixel Correction

     conditions. Inappropriate data registration of defective pixels may cause difficulties to acquire proper images.  Neglecting these instructions may cause not only incorrect pixel defect correction, but also failure of acquiring proper images. ©2022 CIS Corporation. All rights reserved.
  • Page 11: Serial Communication

    To get the information of the address 10 [Send] GU[sp]10[¥r] [¥r]=CR(0x0D) [Returned value] GU[sp]10[¥r][¥n] [Echo back] [¥n]=LF(0x0A) [Returned value] 50[¥r] [¥n] [Acquired data + Linefeed] [sp]=Space(0x20) [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt (> and space)] ©2022 CIS Corporation. All rights reserved.
  • Page 12: Changing Speed Of Serial Communication

    8: 1080i 50fps This is to set video output format. 9: 1080p 30fps 10: 1080p 29.97fps 11: 1080p 25fps 12: 1080p 24fps 13: 1080p 23.98fps 14: 720p 60fps 15: 720p 59.94fps 16: 720p 50fps ©2022 CIS Corporation. All rights reserved.
  • Page 13 Execute SU 9 6 7 4 2 to set 4x2 block from the The 4 Param: H value: 1~16 coordinate (6, 7). AE Speed 0~15 This is to set AE convergence speed. Exposure 0(-12dB)~12(0dB)~24(+12dB)/ Compensation This is to set exposure compensation value. per 1dB Value ©2022 CIS Corporation. All rights reserved.
  • Page 14 (*1) Due to physical limitation of the sensor and circuit, there are some cases that user cannot control gain, shutter values, and limits as designated by commands. User can check the actual values with Current Gain and Current Shutter commands. ©2022 CIS Corporation. All rights reserved.
  • Page 15 WB CC Shift -10~10 magenta. This is to acquire the current Red Gain. (Dedicated to Current Red Gain None None This is to acquire the current Blue Gain. (Dedicated to Current Blue Gain None None ©2022 CIS Corporation. All rights reserved.
  • Page 16 50% output level is regarded as 100% input level. (*2) The initial setting of VCC-HD5 is Normal. When you are switching the model from VCC-H3N to VCC-HD5 and need the same setting as VCC-HD3N, set Dynamic range to Low. ©2022 CIS Corporation. All rights reserved.
  • Page 17 DC Iris lens used. (*3) When shooting a high luminance object with DC iris function, hunting may occur under some conditions. In such cases, please adjust DC Iris Response Speed or Exposure Compensation Value. ©2022 CIS Corporation. All rights reserved.
  • Page 18 If user specifies the same color as the text 5: Cyan color, error will occur because the selected 6: Yellow letters cannot be recognized. 7: White This is to close OSD menu. OSD Off 1 (fixed) None (Dedicated to SU) ©2022 CIS Corporation. All rights reserved.
  • Page 19 This is to restore camera settings to factory settings. Camera store data, address to store, defective pixel Init 0 (fixed) None correction data, and baud rate are not subject to this command. (Dedicated to ©2022 CIS Corporation. All rights reserved.
  • Page 20 SDI compatibility mode ON, however, SDI Compatibility 0: Off changes made are not subject to Mode 1: On reflect. Set this command ON if you are using a receiving equipment, which outputs no image with HLG75 or BT.2020. ©2022 CIS Corporation. All rights reserved.
  • Page 21 [GU 200] command shows the number of pixels classified under [U] attribute, and [GU 201] command shows the number  of pixels classified under [P] attribute. User can change only user-register data, and cannot remove the factory data upon shipment.  User cannot register the pixels already been registered as factory-data.  ©2022 CIS Corporation. All rights reserved.
  • Page 22: Quick Reference Table

    6658043 006597FB 114.035 41.141 7473400 007208F8 128.000 42.144 8388608 00800000 143.675 43.148 9415894 008FACD6 161.270 44.151 10568984 00A14518 181.019 45.154 11863283 00B504F3 203.187 46.158 13316085 00CB2FF5 228.070 47.161 14946800 00E411F0 251.189 48.000 16461899 00FB304B ©2022 CIS Corporation. All rights reserved.
  • Page 23: Quick Reference Table For Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2996 00000BB4 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1049 00000419 1/1500 000002BB 1/2000 0000020C 1/3000 0000015E 1/4000 00000106 1/6000 000000AF 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2022 CIS Corporation. All rights reserved.
  • Page 24: How To Operate The Camera With Osd Function

    Please note that only representative values are selectable for gain and shutter with OSD menu. If you wish to set  specific values, please use serial command setting. Some hidden items are mode-dependent. For example, when gain mode is Auto, menu does not indicate gain  value. ©2022 CIS Corporation. All rights reserved.
  • Page 25: Osd Menu Hierarchical Structure

    ┃   ┣ Spot Block  ┃   ┗ Flicker Cancel  ┣ White Balance  ┃   ┣ WB Mode  ┃   ┣ Auto Func  ┃   ┣ Preset Func  ┃   ┣ Preset Temp  ┃   ┣ Manual Memory  ┃   ┣ Manual Red Gain  ┃   ┣ Manual Blue Gain  ┃   ┣ One Push WB  ┃   ┣ LB Shift  ┃   ┗ CC Shift  ┣ Image Control  ┃   ┣ Red Balance  ┃   ┣ Green Balance  ┃   ┣ Blue Balance  ┃   ┣ Master Pedestal  ┃   ┣ Red Pedestal  ┃   ┣ Green Pedestal  ┃   ┣ Blue Pedestal  ┃   ┣ Detail  ┃   ┣ Gamma  ┃   ┣ Knee  ┃   ┣ D‐Range  ┃   ┣ Noise Reduction  ┃   ┣ Color Correction  ┃   ┣ Color Saturation  ┃   ┣ Color Suppression  ┃   ┣ Cyan Suppression  ┃   ┣ Color Space  ┃   ┣ Color Adjustment  ┃   ┃  ┣ Magenta (Hue/Saturation/Depth)  ┃   ┃  ┣ Red     (Hue/Saturation/Depth)  ©2022 CIS Corporation. All rights reserved.
  • Page 26 VCC-HD5 Rev. 905-0273-Z1 ┃   ┃  ┣ Yellow  (Hue/Saturation/Depth)  ┃   ┃  ┣ Green   (Hue/Saturation/Depth)  ┃   ┃  ┣ Cyan    (Hue/Saturation/Depth)  ┃   ┃  ┗ Blue    (Hue/Saturation/Depth)  ┃   ┗ SDI Compatibility  ┣ Flip  ┃   ┣ Horizontal Flip  ┃   ┗ Vertical Flip  ┣ LTC  ┃   ┣ LTC Mode  ┃   ┗ LTC Reset  ┣ GenLock  ┃   ┣ V Offset  ┃   ┗ H Offset  ┣ Test Pattern  ┃   ┣ Test Pattern  ┃   ┣ Position X  ┃   ┗ Position Y  ┣ OSD Color  ┃   ┣ OSD Color (Text/Highlight)  ┃   ┗ Default  ┗ Save/Load/Init     ┣ Save Settings     ┣ Load Settings    ┗ Init Settings  ©2022 CIS Corporation. All rights reserved.
  • Page 27: Dimensions

    VCC-HD5 Rev. 905-0273-Z1 Dimensions ©2022 CIS Corporation. All rights reserved.
  • Page 28: Case For Indemnity (Limited Warranty)

    CIS applies defective pixel correction prior to the shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
