CIS VCC-HD1000A Product Specification & Operational Manual

3g-sdi/hd-sdi full hd cmos high sensitivity color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev.905-0220-00
3G-SDI/HD-SDI
FULL HD CMOS High Sensitivity Color Camera
VCC-HD1000A
Product Specifications
& Operational Manual
CIS Corporation
©2021 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-HD1000A and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-HD1000A

Summary of Contents for CIS VCC-HD1000A

  • Page 1 Rev.905-0220-00 3G-SDI/HD-SDI FULL HD CMOS High Sensitivity Color Camera VCC-HD1000A Product Specifications & Operational Manual CIS Corporation ©2021 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Indication of OSD Menu ........................... 22 6.3. OSD Menu Hierarchical Structure ......................22 Dimensions ............................... 24 Case for Indemnity (Limited Warranty) ........................ 25 8.1. Product Warranty ............................ 25 8.2. CMOS Defective Pixels ..........................25 8.3. Product Support ............................25 ©2022 CIS Corporation. All rights reserved.

  • Page 3: Precautions

    □ Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera. □ Since VCC-HD1000A is a compact and dense camera, camera temperature rises. Please take appropriate heat dissipation measures, such as installing the camera to a metal plate etc.

  • Page 4: Product Outline

    VCC-HD1000A Rev.905-0220-00 Product Outline VCC-HD1000A is a Full HD color camera with 0.0005 lx super sensitivity. Using a 35mm full size CMOS image sensor, the maximum frame rate achieves 60fps. 3G-SDI interface and features CIS proprietary ISP, “Clairvu ” image processing engine for superb imaging quality and high speed processing. Complies with BT.2020 (Wide color gamut) and BT2100 (Hybrid Log-Gamma).

  • Page 5: Specifications

    ON, OFF(typ.) Edge enhancement OFF, 1~7(typ.2) Color correction Auto, Standard, Fluorescent Light, Tungsten Lamp Chroma adjustment 0%(B/W) ~ 100%(typ.) ~ 200% Color saturation suppression OFF, 1~7(typ.5) Noise reduction OFF, 1~6 Gamma correction ITU-R BT.709, BT.2100(HLG) ©2022 CIS Corporation. All rights reserved.
  • Page 6 (100G) for ±X, ±Y, and ±Z, in 6 directions (without packaging). Operational temperature -5 ~ +45°C Humidity: 20 ~ 80%RH with no condensation. Storage temperature -25 ~ +60°C Humidity: 20 ~ 80%RH with no condensation. ©2022 CIS Corporation. All rights reserved.

  • Page 7: Part Names And Functions

    Use high-frequency BNC cable that comply with 3G-SDI or HD-SDI. Pin No. Signals 3G-SDI/HD-SDI output ④ BNC connector (For GENLOCK signal input) Input analog external sync signals (black burst or 3-values SYNC) via BNC cable. Pin No. Signals Analog external sync. signal input ©2022 CIS Corporation. All rights reserved.
  • Page 8 Front and rear: UNC1/4 Depth 5.5 Center: UNC3/8 Depth 5.5 Please refer to Section 7. Dimensions for details on the screw hole positions. Please note that screws longer than 5.5mm may damage the internal PCB. ©2022 CIS Corporation. All rights reserved.

  • Page 9: Camera Functions

    00:00:00.00 when power is ON, and when signals are input to the LTC IN terminal, time code switches to external time code. Under this condition, if no signal is input to the LTC IN terminal, internal time code starts. Signal format: SMPTE Time code Signal level: 0.5~2 [Vp-p] ©2022 CIS Corporation. All rights reserved.

  • Page 10: Defective Pixel Correction

    Please note that the detected results may not always be the same due to temperature, noise, and other  conditions. Neglecting these instructions may cause not only incorrect pixel defect correction, but also failure of acquiring proper images. ©2022 CIS Corporation. All rights reserved.

  • Page 11: Serial Communication

    To get information of address 10 [Send] GU[sp]10[¥r] [¥r]=CR(0x0D) [Returned value] GU[sp]10[¥r][¥n] [Echo back] [¥n]=LF(0x0A) [Returned value] 50[¥r] [¥n] [Acquired data + Linefeed] [sp]=Space(0x20) [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt (> and space)] ©2022 CIS Corporation. All rights reserved.

  • Page 12: Changing Speed Of Serial Communication

    Baud rate command is not subject to Camera Setting Store/Load command (SU 100/101).  Only when baud rate setting is 9600bps, user can use the optional remote controller RU-100.  Transfer rate of serial communication for RS-232C and RS-422 must be the same.  ©2022 CIS Corporation. All rights reserved.

  • Page 13: Command List

    8: 1080i 50fps This is to set video output format. 9: 1080p 30fps 10: 1080p 29.97fps 11: 1080p 25fps 12: 1080p 24fps 13: 1080p 23.98fps 14: 720p 60fps 15: 720p 59.94fps 16: 720p 50fps ©2022 CIS Corporation. All rights reserved.
  • Page 14 This is to set exposure compensation value. (+12dB)/per 1dB Value This is to set ON/OFF of flicker cancel. 0: Off Flicker Cancel Valid only when video format is 60fps, 1: On 59.94fps, 30fps, and 29.97fps. ©2022 CIS Corporation. All rights reserved.
  • Page 15 User can check the actual values with Current Gain and Current Shutter commands. AE may become unstable with high gain settings (0 x4000000 and over). If you wish to use camera with slow shutter operation, set gain to 0x4000000 and under. ©2022 CIS Corporation. All rights reserved.
  • Page 16 (*2) Memory stores up to five types of settings (0 ~ 4). (*3) Do not shield light to execute this command. If execution of One Push WB is not properly processed, camera will return Runtime Error. ©2022 CIS Corporation. All rights reserved.
  • Page 17 100% output level (without Knee) is Invalid for HLG (Handled as regarded as 100% input level. High) [HLG] 50% output level is regarded as 100% input level. Color Saturation 0~200 This is to set color saturation. ©2022 CIS Corporation. All rights reserved.
  • Page 18 If user specifies the same color as the text 5: Cyan color, error will occur because the selected 6: Yellow letters cannot be recognized. 7: White This is to close OSD menu. OSD Off 1 (Fixed) None (Dedicated to SU) ©2022 CIS Corporation. All rights reserved.
  • Page 19 Store (Equivalent to SU100), this Save 1 (Fixed) None command saves the stored data, the address to store, defective pixel correction data, and baud rate. (Dedicated to SU) ©2022 CIS Corporation. All rights reserved.
  • Page 20 0: Off compatibility mode ON however, changes Mode 1: On made are not subject to reflect. Set this mode ON if you are using a receiving equipment, which outputs no image with HLG75 or BT.2020. ©2022 CIS Corporation. All rights reserved.
  • Page 21  of pixels classified under [P] attribute. User can change only user register data, and cannot remove the factory setting data.  User cannot register the pixels already been registered as factory data.  ©2022 CIS Corporation. All rights reserved.

  • Page 22: Quick Reference Table

    1172D5FF 50.119 3284581 321E65 5011.872 328458065 1393DF51 56.234 3685360 383BF0 5623.413 368536011 15F769CB 63.096 4135042 3F1882 6309.573 413504205 18A592CD 70.795 4639593 46CB69 7079.458 463959349 1BA77535 79.433 5205710 4F6ECE 7943.282 520570952 1F074848 89.125 5840902 592006 ©2022 CIS Corporation. All rights reserved.

  • Page 23: Quick Reference Table For Shutter Settings

    1/11200 89.29 1/100 10000.00 10486 28F6 1/105 9523.81 9986 2702 1/120 8333.33 8738 2222 1/125 8000.00 8389 20C5 1/150 6666.67 6991 1B4F 1/180 5555.56 5825 16C1 1/210 4761.90 4993 1381 1/250 4000.00 4194 1062 ©2022 CIS Corporation. All rights reserved.

  • Page 24: How To Operate Camera With Osd Function

    ┣ Auto Func ┃ ┣ Preset Func ┃ ┣ Preset Temp ┃ ┣ Manual Memory ┃ ┣ Manual Red Gain ┃ ┣ Manual Blue Gain ┃ ┣ One Push WB ┃ ┣ LB Shift ┃ ©2022 CIS Corporation. All rights reserved.
  • Page 25 ┣ Test Pattern ┃ ┣ Position X ┃ ┗ Position Y ┃ ┣ OSD Color ┣ OSD Color (Text/Highlight) ┃ ┗ Default ┃ ┗ Save/Load/Init ┣ Save Settings ┣ Load Settings ┗ Init Settings ©2022 CIS Corporation. All rights reserved.

  • Page 26: Dimensions

    VCC-HD1000A Rev.905-0220-00 Dimensions ©2022 CIS Corporation. All rights reserved.

  • Page 27: Case For Indemnity (Limited Warranty)

    CIS applies defective pixel correction prior to the shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
