CIS DCC-HD3 Product Specification & Operational Manual

3g-sdi/hd-sdi cmos color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DCC-HD3
Rev. 905-0118-00
English
3G-SDI/HD-SDI
CMOS Color Camera
Camera Assembly Unit
DCC-HD3
Product Specification
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCC-HD3 and is the answer not in the manual?

Questions and answers

Related Manuals for CIS DCC-HD3

Summary of Contents for CIS DCC-HD3

  • Page 1 DCC-HD3 Rev. 905-0118-00 English 3G-SDI/HD-SDI CMOS Color Camera Camera Assembly Unit DCC-HD3 Product Specification & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Operating temperature of main parts ..................... 8 7.2. How to measure the temperature of the device surface ................8 7.3. <Reference> surface temperature of each device in the CIS chassis (29mm×29mm×77mm)......9 GenLock ..............................9 LTC (Longitudinal Time code) ........................9 Defective Pixel Correction .......................... 10 10.1.
  • Page 3 DCC-HD3 Rev. 905-0118-00 Product Support ............................29 ©2017 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    Assembly without appropriate heat dissipation may cause damages or malfunction. Product Outline DCC-HD3 is provided as an assembly unit that is a part of CIS full HD color camera module with Gen Lock function, VCC-HD3, utilizing a 1/3 type MOS image sensor.

  • Page 5: Packaging

    None. OLPF and a filter on a sensor board are attached at the time of delivery. (14) Gain Setting AGC (Max. Gain : 0dB~48dB) ※ Some noises might be noticeable when MANUAL: 0dB~48dB gain setting is set to high. ©2017 CIS Corporation. All rights reserved.
  • Page 6 ※Operation guaranteed: All the camera functions operate normally under operation guaranteed temperature. (36) Storage Environment Storage Temperature: -25 ~ + 60℃, Humidity: 20 ~ 80%RH with no condensation. (*1) Applied when embedded in VCC-HD3, chassis typed camera. ©2017 CIS Corporation. All rights reserved.

  • Page 7: Parts Name And Functions

    Use a 4 pins plug of your own to connect to the RS-232C signals. (Please be noted no 4 pins plug is bundled.) With connecting to the optional remote controller, OSD (On Screen Display) operation will be enabled. ©2017 CIS Corporation. All rights reserved.

  • Page 8: External Connector Specifications

    Pin No. 3G-SDI/HD-SDI output 6.3. PD-VC01 CN4 (4 pins) Model: BM4B-SRSS-TB (JST) Pin No. IRIS_DUMP+ IRIS_DUMP- IRIS_DRIVE- IRIS_DRIVE+ 6.4. PD-VC01 CN5 φ 3.5mm 4 poles (RS-232C) Connector Model: Pin No. *For optional Power(+5V) TXD(Camera) RXD(Camera) ©2017 CIS Corporation. All rights reserved.

  • Page 9: Guideline For Thermal Design

    Tape a thermocouple on the device surface, make a slit in the heat conducting sheet, and then make the heat-sink be appressed onto it to measure temperature. (E.g.： Temperature measurement of the FPGA surface) ©2017 CIS Corporation. All rights reserved.

  • Page 10: Reference> Surface Temperature Of Each Device In The Cis Chassis (29Mm×29Mm×77Mm)

    DCC-HD3 Rev. 905-0118-00 7.3. <Reference> surface temperature of each device in the CIS chassis (29mm×29mm×77mm) 25℃ 40℃ 45℃ Ambient temperature Image sensor FPGA 55.7 70.7 75.7 51.7 66.7 71.7 SDI IC 55.1 70.1 75.1 GenLock Input analog external sync signals (black burst or 3-value SYNC) to the EXT SYNC IN terminal of 6pins connector to enable Gen Lock function.

  • Page 11: 10. Defective Pixel Correction

    The command sent from the PC will be received by the camera, and then echoed back. ・ The end of the command shall be judged by >[sp]. ・ Please issue the next command when the prior command is completed. ・ ©2017 CIS Corporation. All rights reserved.
  • Page 12 To set 30 to the Command No.10 [Send] SU[sp]10[sp]30[¥r]or[¥n] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + space] 【Example of SAVE Command】 [Send] SAVE[¥r]or[¥n] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + space] ©2017 CIS Corporation. All rights reserved.

  • Page 13: Command List

    Valid when Shutter Mode is at Manual 1. Shutter Value [s]×0x100000 (17476) *Shutter speed slower than 1/60s will be 1/25s ～ 1/13600s 1/60s limited by the frame rate corresponding to the video output format. ※Refer to 11.4.2 Quick Reference Matrix. ©2017 CIS Corporation. All rights reserved.
  • Page 14 ※ Note1). There would be a margin of error between the set shutter value and the actual shutter value. Please refer to the chart in the Section 11.4.3 for the details. ※ Note2). Flicker cancel function is invalid at 50fps, 25fps, 24fps, and 23.97fps regardless of their settings. ©2017 CIS Corporation. All rights reserved.
  • Page 15 To set R gain when WB mode is at Manual and Red Gain 0～800(%) at Preset. (Write Only) One Push 1: Trigger Start None To start operation when WB mode is at One Trigger Push. ©2017 CIS Corporation. All rights reserved.
  • Page 16 Noise Reduction To set the Noise Reduction. 1 : Noise reduction ON 0: Auto 1: Standard Color Correction To set color correction. 2: Fluorescent light 3: Tungsten lamp Color Suppression 0～7 To set color suppression. ©2017 CIS Corporation. All rights reserved.
  • Page 17 3: Magenta If the same color as the menu Select Color 4: Green color is specified, it will be an 5: Cyan error, because the selected letters 6: Yellow cannot be recognized. 7: White ©2017 CIS Corporation. All rights reserved.
  • Page 18 None None The letter strings such as 0.1 shall 2: FPGA’s version be responded. To start detection of pixel defects Please refer to the Section 10. SDDW None Defective Pixel Correction, for the details. ©2017 CIS Corporation. All rights reserved.

  • Page 19: Quick Reference Matrix For Settings

    2965821 002D413D 50.797 34.117 3329021 0032CBFD 57.018 35.120 3736700 0039047C 64.000 36.124 4194304 00400000 71.838 37.127 4707947 0047D66B 80.635 38.130 5284492 0050A28C 90.510 39.134 5931642 005A827A 101.594 40.137 6658043 006597FB 114.035 41.141 7473400 007208F8 ©2017 CIS Corporation. All rights reserved.

  • Page 20: Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2995 00000BB3 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1048 00000418 1/1500 000002BB 1/2000 0000020C 1/3000 0000015D 1/4000 00000106 1/6000 000000AE 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2017 CIS Corporation. All rights reserved.

  • Page 21: 11.4.3 Actual Shutter Values Limited By Video Output Format

    1/6172 1/6800 1/6800 1/6794 1/7237 1/6412 1/7562 1/7555 1/8000 1/7562 1/8508 1/8306 1/8010 1/8003 1/8306 1/9600 1/9745 1/9736 1/9745 1/9745 1/9736 1/11200 1/11389 1/11379 1/11787 1/11389 1/11379 1/11787 1/13600 1/13701 1/13690 1/14911 1/13701 1/13689 ©2017 CIS Corporation. All rights reserved.

  • Page 22: 12. How To Operate The Camera With Osd Function

    Set Video Format 1080i 50fps Select video format with button, ／ 1080p 30fps then push the CENTER button to confirm. 1080p 29.97fps 1080p 25fps 1080p 24fps 1080p 23.97fps 720p 60fps 720p 59.94fps 720p 50fps ©2017 CIS Corporation. All rights reserved.
  • Page 23 Shutter Value 1/500 video output format. 1/600 ※Note 1 1/700 ※Note 2 1/840 ※Note3 1/1000 1/1200 1/1400 1/1700 1/2000 1/2400 1/2800 1/3400 1/4000 1/4800 1/5600 1/6800 1/8000 1/9600 1/11200 1/13600 ©2017 CIS Corporation. All rights reserved.
  • Page 24 ※Note 4): Flicker cancel function is invalid at 50fps,25fps,24fps, and 23.97fps, regardless of their settings. ※Note 5): With DC Iris, hunting might occur depending on conditions when shooting bright objects. In such case, adjusting DC Iris Response speed or Exposure Compensation values might help ©2017 CIS Corporation. All rights reserved.
  • Page 25 Push. None Start Execute One Push WB with the CENTER button. Select the preset number with the button, and push the Set Preset ／ 1～5 Number CENTER button to save the current WB value. ©2017 CIS Corporation. All rights reserved.
  • Page 26 Tungsten lamp Color 0～7 To set color suppression. Suppression ON/OFF LTC ON/OFF. Set LTC Reset None To reset LTC with the CENTER button. ※Note 3)：The values 0～200 can be set via serial command. ©2017 CIS Corporation. All rights reserved.
  • Page 27 To execute SAVE or NOT SAVE, then get back to the original Enter None screen. To call up the data of the selected preset number and reflect 0～3 Get Save Data it on the screen with the CENTER button. ©2017 CIS Corporation. All rights reserved.

  • Page 28: Factory Settings

    Manual Blue Gain Color Correction Standard Color Suppression Color Saturation Edge Enhancement Noise Reduction Contrast Standard Master Pedestal Pedestal(RGB) Color Balance (RGB) OSD Menu Color White OSD Select Color Cyan H Flip V Flip ©2017 CIS Corporation. All rights reserved.

  • Page 29: Dimensions

    DCC-HD3 Rev. 905-0118-00 Dimensions ©2017 CIS Corporation. All rights reserved.

  • Page 30: Cases For Indemnity (Limited Warranty)

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
