CIS NDI DCC-4KNDI Product Specification & Operation Manual

4k uhdtv cmos af zoom color camera module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev. 905-0235-Z2
NDI
®
4K UHDTV CMOS
AF ZOOM Color Camera Module
DCC-4KNDI
Product Specification
& Operational Manual
(Preliminary)
CIS Corporation
For More Information Please Call Aegis Electronic Group, Inc. *CA- (760) 729-2026 AZ- (480) 635-8400 * aegis-g2@aegiselect.com * http://www.aegis-elec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NDI DCC-4KNDI and is the answer not in the manual?

Questions and answers

Related Manuals for CIS NDI DCC-4KNDI

Summary of Contents for CIS NDI DCC-4KNDI

  • Page 1 Rev. 905-0235-Z2 ® 4K UHDTV CMOS AF ZOOM Color Camera Module DCC-4KNDI Product Specification & Operational Manual (Preliminary) CIS Corporation For More Information Please Call Aegis Electronic Group, Inc. *CA- (760) 729-2026 AZ- (480) 635-8400 * aegis-g2@aegiselect.com * http://www.aegis-elec.com...

  • Page 2: Table Of Contents

    Rev.905-0235-Z2 Table of Contents Handling Precautions .............................. 1 Camera Handling Precautions ........................1 Restrictions on Applications .......................... 1 Disclaimers (Exception Clause) ........................1 Product Outline ..............................2 Features ..............................2 Accessories ..............................2 Specifications ................................. 3 General Specifications ..........................3 External Connectors .............................

  • Page 3: Handling Precautions

    □ Do not apply excessive voltage. (Use only the specified voltage.) When using an AC adaptor, use only the CIS optional AC adaptor. Unstable or improper power supply voltage may cause damages or malfunction of the camera module and may cause a smoke, fire, and rupture.

  • Page 4: Product Outline

    ※ CIS control software is provided for evaluation purpose only. CIS should be held harmless for any damage arising from the use of this control software. The purpose of this control software is restricted to the evaluation and testing of this product only, and is not intended for commercial use by the customer.

  • Page 5: Specifications

    DCC-4KNDI Rev.905-0235-Z2 Specifications General Specifications Electrical Specifications Pickup Device type 1/1.8” color CMOS sensor device Unit cell Size 2.0µm (H) × 2.0µm (V) Resolution 2160p： 3840 (H) × 2160 (V) 1080p： 1920 (H) × 1080 (V) Aspect ratio 16 : 9 Video output format ®...
  • Page 6 DCC-4KNDI Rev.905-0235-Z2 Electrical Specifications (continued) Gamma Complies with BT.709 curve: Contrast -2, -1, 0, +1, +2 Complies with BT.2100 (HLG) curve Dynamic range Low (for better SNR), Normal, High Knee point OFF, 100%, 95%, 90%, 85%, 80%, 75% Color gamut BT.709, BT.2020 -100 ～...

  • Page 7: External Connectors

    Do not connect the optional AC adaptor while supplying power by PoE. 5V/4A input, outer diameter φ 5.5mm / inner diameter φ 2.1mm. Use only CIS optional AC adaptor (model name: 5V-5A-S2-A-A). Issues associated with the use of a third party’s AC adaptor are out of warranty.

  • Page 8: Line Input

    DCC-4KNDI Rev.905-0235-Z2 3.2.4. Line Input Model name： MJ-074N-R (Marushin Electric Mfg. Co., Ltd.) Connectφ 3.5mm, 3-pole stereo mini plug. 2 (ring) 3 (sleeve) 1 (chip) Pin No. Signals Line input (L) Line input (R) 3.2.5. Pin Jack for Communication Model name： MJ-069-R (Marushin Electric Mfg. Co., Ltd.) Connect φ...

  • Page 9: Connector For External Led

    DCC-4KNDI Rev.905-0235-Z2 3.2.6. Connector for External LED Model name： 53261-0271 (MOLEX) 330Ω Connector Pin No. Function Connect cathode (-) of external LED_1. Connect anode (+) of external LED_1. Connect cathode (-) of external LED_2. Connect anode (+) of external LED_2. 3.2.7.

  • Page 10: Camera Functions

    DCC-4KNDI Rev.905-0235-Z2 Camera Functions Defective Pixels Correction In addition to the correction of defective pixels data registered upon shipment, we provide a method to update the defective pixels correction data. Please refer to Section 5.1.2, Serial Command List for details. 4.1.1 Defective Pixels Data Type There are two types of defective pixels data.

  • Page 11: Notes For Defective Pixels Correction

    DCC-4KNDI Rev.905-0235-Z2 4.1.3 Notes for Defective Pixels Correction To save data registered or deleted by a defective pixels correction command (SU 200~203), execute Save  command (SU705). Init command (SU 700) does not restore defective pixels correction data. Use SU 203 to delete all data. ...

  • Page 12: Camera Operation

    DCC-4KNDI Rev.905-0235-Z2 Camera Operation There are three kinds of methods to control the camera. □ Control via serial communication (RS-232) All camera functions are supported.  □ Control via HTTP All camera functions are supported.  □ Control by NDI ®...
  • Page 13 DCC-4KNDI Rev.905-0235-Z2 regarded as Decimal. ・ Parameters are analyzed from the head to identifiable letters. Some inappropriate letters are ignored and some are regarded as errors. ・ Please refer to “Section 5.1.2. Serial Command List” for details on address and data. ・...

  • Page 14: Serial Command List

    DCC-4KNDI Rev.905-0235-Z2 5.1.2 Serial Command List Video Format Initial Function Address Setting Value Description Value 0: 3840×2160p 60fps 1: 3840×2160p 59.94fps 2: 3840×2160p 50fps 3: 3840×2160p 30fps 4: 3840×2160p 29.97fps 5: 3840×2160p 25fps 6: 3840×2160p 24fps This is to set NDI ®...
  • Page 15 DCC-4KNDI Rev.905-0235-Z2 AE related (continued) Initial Function Address Setting Value Description Value The 1 Parameter: Max value This is to set shutter variable range when shutter Exposure time [s]×0x100000 0x4444 mode is Auto. (*1) Setting range: (17476) Shorter value than 1 frame length must be set. 1/13600～1/23.98s 1/60s Max<Min is invalid.
  • Page 16 DCC-4KNDI Rev.905-0235-Z2 AE related (continued) Initial Function Address Setting Value Description Value 0: -12dB 1: -11dB Exposure This is to set exposure compensation value. Compensation 12: 0dB Set value 12 is equivalent to 0dB. Value Settable per 1dB. 23: +11dB 24: +12dB This is to set ON/OFF of flicker cancel.
  • Page 17 DCC-4KNDI Rev.905-0235-Z2 WB related Initial Function Setting Value Description Address Value 0: Manual WB Mode 1: Auto This is to set White Balance (WB) mode. 2: Preset This is to choose the memory to store setting values when WB Manual 0～4 WB Mode is with Manual.
  • Page 18 DCC-4KNDI Rev.905-0235-Z2 Image Quality related Initial Function Setting Value Description Address Value 0: Off Detail This is to set details. 1(Low)~7(High) 0: BT.709 -2 This is to set gamma type and contrast. 1: BT.709 -1 0~4 are the curves comply with BT.709. 2: BT.709 Gamma Contrast changes in the range of -2 ~ +2.
  • Page 19 DCC-4KNDI Rev.905-0235-Z2 Image Quality related (continued) Initial Function Setting Value Description Address Value 0～200 Color Saturation This is to set color saturation. 0～15 Cyan Suppression This is to set suppression for Cyan saturation. The 1 Parameter: Selection of color This is to set color adjustment values. 0: Magenta There are three kinds of adjustment items for 1: Red...
  • Page 20 DCC-4KNDI Rev.905-0235-Z2 Lens Control related Initial Function Setting Value Description Address Value The 1 Parameter: Move mode This is to move the zoom lens. 0: To specify the absolute zoom position There are three kinds of way to specify. 1: To specify the relative zoom position Select with move mode.
  • Page 21 DCC-4KNDI Rev.905-0235-Z2 Lens Control related (continued) Initial Function Setting Value Description Address Value Current Zoom This is to acquire the current zoom speed. None None Speed (GU Only) (*6) Current Focus This is to acquire the current focus speed None None Speed (GU Only) (*6)
  • Page 22 DCC-4KNDI Rev.905-0235-Z2 OSD related Function Address Setting Value Initial Value Description 0: 1 push OSD Up button None 1: continuous push 0: 1 push OSD Down button None 1: continuous push Commands to operate OSD. 0: 1 push Send commands every 60msec for OSD Right button None 1: continuous push...
  • Page 23 DCC-4KNDI Rev.905-0235-Z2 Others Initial Function Setting Value Description Address Value User can store four kinds of camera settings. Execute SAVE (SU 705 1) to save the registered values into the nonvolatile memory. 0～3 Camera Setting Store The registered data and where to store (the value for this address) are not subject to Init command (SU 700 0).
  • Page 24 Reset command (SU 9999) to restore the setting. (Reflects changes made after rebooting). CIS remote controller, RU-100, operates only with 9600bps. This is to restore settings to factory settings. No need to execute SAVE command. Please reboot the camera after executing this command.
  • Page 25 DCC-4KNDI Rev.905-0235-Z2 Defective Pixels Correction Function Setting Value Initial Value Address This is to detect defective pixels (white The 1 Parameter: defect) and register them as user Threshold level: 0 ~ 4095 register data. Defective pixels are Detection of output value, which exceeds the The 2 Parameter: Registration mode.
  • Page 26 DCC-4KNDI Rev.905-0235-Z2 Lens Adjustment Initial Function Address Setting Value Function Value This is to set gain for fine tuning focus position. Valid as a gain against temperature offset parameter. Specify values in the multiple of 16. (The initial value Gain for fine tuning 0 (x0) ～32 (x2) of 16 means x1).

  • Page 27: Quick Reference Table For Gain Settings

    DCC-4KNDI Rev.905-0235-Z2 5.1.3 Quick Reference Table for Gain Settings Gain Value (Mag.×0x10000) Magnification 1.000 0.000 65536 00010000 1.122 1.003 73561 00011F59 1.260 2.007 82570 0001428A 1.414 3.010 92681 00016A09 1.587 4.014 104031 0001965F 1.782 5.017 116771 0001C823 2.000 6.021 131072 00020000 2.245 7.024...

  • Page 28: Quick Reference Table For Shutter Settings

    DCC-4KNDI Rev.905-0235-Z2 5.1.4 Quick Reference Table for Shutter Settings Shutter Value (Exposure time [s]×0x100000) Exposure time [s] 1/23.98 43734 0000AAD6 1/24 43691 0000AAAB 1/25 41943 0000A3D7 1/29.97 34987 000088AB 1/30 34953 00008889 1/50 20972 000051EC 1/59.94 17494 00004456 1/60 17476 00004444 1/90 11651...

  • Page 29: Quick Reference Table For Iris Settings

    DCC-4KNDI Rev.905-0235-Z2 5.1.5 Quick Reference Table for Iris Settings Aperture Value ((1/F2)×0x100000) F Value 22.6 2048 00000800 19.0 2896 00000B50 16.0 4096 00001000 13.5 5792 000016A0 11.3 8192 00002000 9.51 11585 00002D41 8.00 16384 00004000 6.73 23170 00005A82 5.66 32768 00008000 4.76 46340...

  • Page 30: How To Operate Camera With Osd Function

    DCC-4KNDI Rev.905-0235-Z2 5.1.6 How to Operate Camera with OSD Function In addition to operation by serial communication explained earlier, you can operate the camera with OSD menu on a monitor screen by connecting an optional remote controller (TBD) to the camera. Note that OSD menu does not appear on NDI ®...

  • Page 31: How To Operate Camera With Http

    DCC-4KNDI Rev.905-0235-Z2 How to Operate Camera with HTTP You can operate camera with HTTP. Basically, WEB API defines all function. By executing Web API, you can operate camera and control camera settings. Web UI is also prepared for camera control via Web browser. 5.2.1 Web API Specification Protocol HTTP...

  • Page 32: Camera Related Api

    DCC-4KNDI Rev.905-0235-Z2 5.2.2 Camera Related API You can execute serial commands via Web API. Use serial commands in the command list as they are. Function Execution of GU command Request URI /api/v1/cam/gu/<addr>  code: 0=normal completion Other than 0 = error occurred Response message: Acquired information (with normal completion) or error message (when error occurred) This is to execute GU command.

  • Page 33: Network Related Api

    DCC-4KNDI Rev.905-0235-Z2 5.2.3 Network Related API Function Acquisition of device name Request URI /api/v1/net/get/devname  code: 0=normal completion Other than 0 = error occurred Response message: Device name (with normal completion) Explanation This is to acquire device name. Initial value 4kndi $ curl http://192.0.2.10/api/v1/net/get/devname ...
  • Page 34 DCC-4KNDI Rev.905-0235-Z2 Function Acquisition of NDI ® group Request URI /api/v1/net/get/ndigroup  code: 0=normal completion Other than 0 = error occurred Response message: NDI ® group (with normal completion). Explanation This is to acquire NDI ® group. Initial value None (empty letter string) $ curl http://192.0.2.10/api/v1/net/get/ndigroup ...
  • Page 35 DCC-4KNDI Rev.905-0235-Z2 Function How to transmit NDI ® Request URI /api/v1/net/get/nditransmission  code: 0=normal completion Other than 0 = error occurred Response message: Information on how to transmit with normal completion. This is to acquire information on how to transmit NDI ®...
  • Page 36 DCC-4KNDI Rev.905-0235-Z2 Function Setting IP address /api/v1/net/set/ipaddr/dhcp  Request URI /api/v1/net/set/ipaddr/static/<address>/<netmask>  /api/v1/net/set/ipaddr/static/<address>/<netmask>/<gateway>  code: 0=normal completion Other than 0 = error occurred Response message: dhcp or static with normal completion This is to set IP address. By specifying dhcp, you can get an IP address from DHCP server. When DHCP server is not found, Auto IP function works and automatically assigns a link local address with 169.254.ddd.ddd format.

  • Page 37: System Related Api

    DCC-4KNDI Rev.905-0235-Z2 5.2.4 System related API Function Acquisition of HTTP authentication information Request URI /api/v1/sys/get/auth  code: 0=normal completion Other than 0 = error occurred Response message: HTTP authentication information (with normal completion) This is to acquire HTTP authentication information. none: No HTTP authentication is required. (You can access HTTP without authentication.) basic: HTTP basic authentication is set.

  • Page 38: How To Operate Camera Via Web Browser

    DCC-4KNDI Rev.905-0235-Z2 Function Reboot Request URI /api/v1/sys/reboot  code: 0=normal completion Other than 0 = error occurred Response message: none Explanation This is to reboot after returning response. $ curl http://192.0.2.10/api/v1/sys/reboot  Example {"code": 0, "message": ""} Function Factory reset Request URI /api/v1/sys/factoryreset  code: 0=normal completion Other than 0 = error occurred Response message: none This is the same as Factory Rest (SU 9999 1) with serial command to restore all settings to factory...

  • Page 39: Dimensions

    DCC-4KNDI Rev.905-0235-Z2 Dimensions For More Information Please Call Aegis Electronic Group, Inc. *CA- (760) 729-2026 AZ- (480) 635-8400 * aegis-g2@aegiselect.com * http://www.aegis-elec.com...

  • Page 40: Case For Indemnity (Limited Warranty) And Others

    CIS applies defective pixels correction prior to the shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
