CIS VCC-FC21U19OP Product Specification & Operational Manual

Uxga resolution cmos color (raw) camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-FC21U19OP
Rev. 900-766-30-00
English
Optical I/F
UXGA Resolution CMOS
Color (RAW) Camera
VCC-FC21U19OP
Product Specification
& Operational Manual
CIS Corporation
©2014 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-FC21U19OP and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-FC21U19OP

Summary of Contents for CIS VCC-FC21U19OP

  • Page 1 VCC-FC21U19OP Rev. 900-766-30-00 English Optical I/F UXGA Resolution CMOS Color (RAW) Camera VCC-FC21U19OP Product Specification & Operational Manual CIS Corporation ©2014 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Remote Communication Function ........................21 Initial Settings ..............................22 CMOS Optical Axis Accuracy ..........................23 Dimensions ..............................24 Cases for Indemnity (Limited Warranty) ......................25 CMOS Pixel Defect ............................25 Product Support ..............................25 ©2014 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    Especially when the read-out line is set in the range of 50 lines to 1 line, heat dissipation is recommended to install the camera. Installation recommended. ・ Install the camera to the place with ambient temperature under 40 ℃. ・ Install the camera to a metallic component. ©2014 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Rev. 900-766-30-00 Product Outline This is to describe VCC-FC21U19OP, UXGA resolution, Opt:C-LINK (Optical) I/F Color (RAW) CMOS Camera. 2M pixels CMOS sensor with diagonal length 12.775mm is utilized. Entire pixels can be read out within 1/126s at Medium Configuration output.

  • Page 5: Specifications

    (21) Shutter speed variable OFF ～ 1/40000s range (22) Trigger shutter mode Fixed Shutter Trigger Mode/ Pulse Width Shutter Trigger Mode (23) Partial Scan Full Frame Scan ～ 1 line (1 line / step) ©2014 CIS Corporation. All rights reserved.
  • Page 6 ※ All the specifications specified in this manual is guaranteed under performance guaranteed temperature. (26) Operation Environment ※All the camera functions operate normally under operation guaranteed temperature. Humidity RH 20～80% with no condensation. -25℃～+60℃ Temperature (27) Storage Environment RH 20～80% with no condensation. Humidity ©2014 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    ±00Fh. At Digital 8bit : Both horizontal and vertical should be under 03h. (Condition: Gain 0dB) ※ 2 seconds shall be waited after turning on power to get the camera operate properly. ©2014 CIS Corporation. All rights reserved.

  • Page 8: Spectral Response (Representative Value)

    VCC-FC21U19OP Rev. 900-766-30-00 4.3. Spectral Response (Representative Value) * Lens characteristics and luminous source characteristics are not considered. ©2014 CIS Corporation. All rights reserved.

  • Page 9: Video Output Format

    VCC-FC21U19OP Rev. 900-766-30-00 4.4. Video Output Format (1) 2Tap Base Configuration Mode : 63fps 2048pixel ・・・ (2) 4Tap Base Configuration Mode : 126fps (Initial Setting) 2048pixel ・・・ ©2014 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    10bit output Partial Scan Mode Full Frame Scan Mode Partial Scan Mode Output image flip vertical Normal Flip Vertical Gain CC Control ON/OFF ON (Gain and WB can be controlled via CC2, CC3, and CC4.) ©2014 CIS Corporation. All rights reserved.
  • Page 11 ※Set the data of the address 003 to 004. Manual White Balance G 050&051 0～767: 0:0dB ～ 767:+12dB ※Set the data of the address 003 to 004. Cursor Indication ON/OFF 061&060 0～2047: Cursor X Address 063&062 0～2047: Cursor Y Address ©2014 CIS Corporation. All rights reserved.
  • Page 12 Input 083 to save the data to EEP-ROM. ※ The data set with 2 Byte shall be set with High Byte (even address) first, then set with Low Byte (odd address). The camera rewrites the internal resister when receiving Low Byte. ©2014 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    VCC-FC21U19OP Rev. 900-766-30-00 External Connector Pin Assignment 6.1. 6 Pins Circular Connector HR10-7R-6PA (HIROSE) Equivalent Pin No. Power IN (DC+12V) Trigger Input FVAL Output Exposure Output LVAL Output ©2014 CIS Corporation. All rights reserved.

  • Page 14: Optical Module Connector Afbr-57D9Amz(Avago)

    VCC-FC21U19OP Rev. 900-766-30-00 6.2. Optical Module Connector AFBR-57D9AMZ(AVAGO) LC duplex Connector 6.3. Optical LINK LED (1) Opt:C-LINK LINK LED ・・・ The LED is lit when connecting the camera and the frame grabber board. ©2014 CIS Corporation. All rights reserved.

  • Page 15: Timing Chart

    Effective Line Video Out (Read Out Pulse) FVAL Out LVAL Out DVAL Out V Blanking : 16H Effective Line : 1088H 1Frame = 1104H(15.824ms) SP Out(Exposure Out) Exposure Time( Address (036&037)) 1H = 14.333us ©2014 CIS Corporation. All rights reserved.

  • Page 16: Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode: 126Fps) *Initial Setting

    Effective Line Video Out (Read Out Pulse) FVAL Out LVAL Out DVAL Out V Blanking : 16H Effective Line : 1088H 1Frame = 1104H(7.912ms) SP Out(Exposure Out) Exposure Time( Address (036&037)) 1H = 7.167us ©2014 CIS Corporation. All rights reserved.

  • Page 17: Fixed Trigger Shutter Mode

    Exposure Time Delay Exposure Time Effective Line : 1088H (Trigger input ignore period) TRIG Input EN TRIG IN SP Out (Exposure Out) 2Tap Base Configuration Mode max 14.333us 4Tap Medium Configuration Mode max 7.167us ©2014 CIS Corporation. All rights reserved.

  • Page 18: Pulse Width Trigger Shutter Mode

    Exposure Time Delay Exposure Time Delay Exposure Time Effective Line : 1088H (Trigger input ignore period) TRIG IN SP Out (Exposure Out) 2Tap Base Configuration Mode max 14.333us 4Tap Medium Configuration Mode max 7.167us ©2014 CIS Corporation. All rights reserved.

  • Page 19: Partial Scan Mode

    FVAL LVAL ① ② ③ ④ ⑤ ① ： V Blanking Line Number ② : Partial Area 1 ③ ： Partial Area 2 ④ ： Partial Area 3 ⑤ ： Total Frame Line Number ©2014 CIS Corporation. All rights reserved.
  • Page 20 Line numbers at partial scan setting can be set from 1 line. However, consumption current will be □ increased by several hundreds mA so that the margin of camera power capacity shall be considered. ©2014 CIS Corporation. All rights reserved.

  • Page 21: Remote Communication Function

    To save the data into EEPROM, please refer to Section 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2014 CIS Corporation. All rights reserved.

  • Page 22: Initial Settings

    Opt:C-LINK (CC1) input Output Data Selection 8bit output Partial Scan Mode Full Frame Scan Mode Output Image Flip Vertical Normal Gain CC Control ON/OFF Baud Rate 9600bps (fixed) Camera Mode 4Tap Medium Configuration Mode ©2014 CIS Corporation. All rights reserved.

  • Page 23: Cmos Optical Axis Accuracy

    VCC-FC21U19OP Rev. 900-766-30-00 11. CMOS Optical Axis Accuracy ©2014 CIS Corporation. All rights reserved.

  • Page 24: Dimensions

    VCC-FC21U19OP Rev. 900-766-30-00 12. Dimensions ©2014 CIS Corporation. All rights reserved.

  • Page 25: Cases For Indemnity (Limited Warranty)

    CMOS pixel defects might be noted with time of usage of the products. Cause of the CMOS pixel defects is the characteristic phenomenon of CMOS itself and CIS is exempted from taking any responsibilities for them. Should you have any questions on CMOS pixel defects compensation, please contact us.
