  • Page 1 VCC-HD3N Rev. 905-0160-01 English 3G-SDI/HD-SDI FULL HD CMOS Color Camera VCC-HD3N Product Specifications & Operational Manual CIS Corporation ©2018 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Switch Operation of OSD Menu by Remote Controller ................21 11.2 Indication of OSD Menu .......................... 21 11.3 OSD Menu ............................. 21 Factory Settings ............................. 27 Dimensions ..............................28 Cases for Indemnity ............................29 CMOS Pixel Defect ............................29 Product Support ............................29 ©2018 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply  voltage may cause damages or malfunction of the camera assembly. Since VCC-HD3N is a highly-dense camera module, appropriate heat dissipation shall be considered.  We recommend using a metal base or others to install the camera.

  • Page 4: Product Outline

    VCC-HD3N Rev. 905-0160-01 2. Product Outline VCC-HD3N is a full HD color camera module utilizing a 1/1.8 type global shutter CMOS sensor. Video output 1080 60p/59.94p/50p (3G-SDI), 1080 60i/59.94i/50i/30p/29.97p/25p/24p/23.97p (HD-SDI), 720 60p/59.94p/50p (HD-SDI) are corresponded. Features CIS own designed Image Signal Processor, “Clairvu ”...

  • Page 5: Specifications

    * Same as MANUAL, shutter speed slower than 1/60s will be limited by the frame rate corresponding to the video output format. AUTO, AUTO (Outdoor), ATW, 7 different Preset, MANUAL, User preset 1~5, and OnePush (16) White Balance Adjustment Preset: Range Daylight(5500K), Cloudy(6500K), Shade(8000K), Tungsten(3200K), Fluorescent(White), Fluorescent(Neutral White), Fluorescent(Daylight) ©2018 CIS Corporation. All rights reserved.
  • Page 6 The difference does not affect the resolution of the video signal. Some 3G-SDI receivers correspond to either Level A or B, whereas other receivers correspond to both Levels, so please set the camera mode to match your 3G-SDI receiver. ©2018 CIS Corporation. All rights reserved.

  • Page 7: Part Names And Functions

    Connecting to such equipment may cause malfunction. ⑥ Screw Holes for camera installation 4 screw holes to install the camera. Please be noted that the depth of the front screw holes and the rear screw holes are different. ©2018 CIS Corporation. All rights reserved.

  • Page 8: External Connector Specifications

    6.4 φ3.5mm 4 poles (RS-232C) Connector Model Name Pin No. Description Power(+5V) *For optional TXD(Camera) RXD(Camera) Connection of φ3.5 (4 poles) Connector (RS-232C) N.C. N.C. 9 p in D -S u b(f e m ale ) ©2018 CIS Corporation. All rights reserved.

  • Page 9: Genlock

    LTC IN terminal, it will be switched to the external time code. With this situation, if no signal is input into the LTC IN terminal, it starts self-running from the set time code. ･ Signal Format: SMPTE Time code Signal Level: 0.5 ~ 2[Vp-p] ･ ©2018 CIS Corporation. All rights reserved.

  • Page 10: Defective Pixel Correction

    9.2 How to execute “Defective Pixel Correction” Execute “INIT” to restore the factory settings. ・ Attach the bundled cap to the lens mount for light-blocking, then wait for about 5 seconds. ・ Execute “Defective Pixel Correction” and SAVE. ・ ©2018 CIS Corporation. All rights reserved.

  • Page 11: Serial Communication

    >[sp] [Prompt + space] 【Example of Set Command】 To set 30 to the Command No.10 [Send] SU[sp]10[sp]30[¥r] [Returned value] SU[sp]10[sp]30[¥r][n] [Echo back] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + Space] ©2018 CIS Corporation. All rights reserved.
  • Page 12 VCC-HD3N Rev. 905-0160-01 【Example of SAVE Command】 [Send] SAVE[¥r] [Returned value] SAVE[¥r][¥n] [Echo back] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + Space] ©2018 CIS Corporation. All rights reserved.

  • Page 13: Command List

    To set the Max gain value when gain mode is Magnification×0x10000 0x200000 at Auto. Gain Max Value x1 (0dB) ~ x251 (48dB) (2097152) 10.4.1 Quick Reference Matrix for ※Refer to Settings. 0: Manual Shutter Mode To set shutter control mode. 1: Auto ©2018 CIS Corporation. All rights reserved.
  • Page 14 (Write only) Lower the shutter speed by 1 step (1/4EV) Shutter from the current one. (Shutter value becomes Speed, Plus None bigger.) Valid when Shutter Mode is at Minus Manual. (Write only) ※Note 1 ©2018 CIS Corporation. All rights reserved.
  • Page 15 To set R gain when WB mode is at Manual Red Gain 0 ~ 800(%) and at Preset. (Write Only) One Push 1: Trigger Start None To start operation when WB mode is at One Trigger Push. ©2018 CIS Corporation. All rights reserved.
  • Page 16 Noise Reduction To set the Noise Reduction. 1 : Noise reduction ON 0: Auto 1: Standard Color Correction To set color correction. 2: Fluorescent light 3: Tungsten lamp Color Suppression To set color suppression. ©2018 CIS Corporation. All rights reserved.
  • Page 17 3: Magenta If the same color as the menu Select Color 4: Green color is specified, it will be an 5: Cyan error, because the selected letters 6: Yellow cannot be recognized. 7: White ©2018 CIS Corporation. All rights reserved.
  • Page 18 To initialize the camera settings. INIT None None None INIT with capital letters. To acquire the firmware’s 1: Microcomputer’s version None None version. The letter strings such 2: FPGA’s version as 0.1 shall be responded. ©2018 CIS Corporation. All rights reserved.

  • Page 19: Quick Reference Matrix For Settings

    1321122 001428A2 22.627 27.093 1482910 0016A09E 25.398 28.096 1664510 001965FE 28.509 29.100 1868350 001C823E 32.000 30.103 2097152 00200000 35.919 31.106 2353974 0023EB36 40.317 32.110 2642246 00285146 45.255 33.113 2965821 002D413D 50.797 34.117 3329021 0032CBFD ©2018 CIS Corporation. All rights reserved.

  • Page 20: Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2995 00000BB3 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1048 00000418 1/1500 000002BB 1/2000 0000020C 1/3000 0000015D 1/4000 00000106 1/6000 000000AE 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2018 CIS Corporation. All rights reserved.

  • Page 21: Actual Shutter Value Limited By Output Format

    To set video format. (Level A) Output Format Set Video Format Select video format with ◀/▶ button, 1080p 60fps then push the CENTER button to confirm. (Level B) 1080p 59.94fps (Level B) 1080p 50fps (Level B) ©2018 CIS Corporation. All rights reserved.
  • Page 22 1/50 Shutter Value video output format. 1/60 ※Note 1 1/75 ※Note 2 1/90 ※Note 3 1/100 Gain/Shutter/IRIS 1/105 1/120 1/125 1/150 1/180 1/210 1/250 1/300 1/350 1/420 1/500 1/600 1/700 1/840 1/1000 1/1200 1/1400 ©2018 CIS Corporation. All rights reserved.
  • Page 23 To select the width (Block number) of the metering Spot Block W 1~16 area when Metering Mode is set to “Spot”. To select the height (Block number) of the metering Spot Block H 1~16 area when Metering Mode is set to “Spot”. ©2018 CIS Corporation. All rights reserved.
  • Page 24 None Start Execute One Push WB with the CENTER button. Select the preset number with Set Preset the ◀ / ▶ button, and push Number the CENTER button to save the current WB value. ©2018 CIS Corporation. All rights reserved.
  • Page 25 ※Note 3: The values 0~200 can be set via serial command. ※Note 4: Some gap might occur to the setting values by reboot the power, changing the format, V phase adjustment, or H phase adjustment. ©2018 CIS Corporation. All rights reserved.
  • Page 26 To execute SAVE or NOT SAVE, then get back to the Enter None original screen. Get Save To call up the data of the selected preset number and Data reflect it on the screen with the CENTER button. ©2018 CIS Corporation. All rights reserved.

  • Page 27: Factory Settings

    Color Suppression Color Saturation Edge Enhancement Noise Reduction Gamma BT.709 Master Pedestal Pedestal(RGB) Color Balance (RGB) OSD Menu Color White OSD Select Color Cyan H Flip V Flip GenLock V Offset GenLock H Offset ©2018 CIS Corporation. All rights reserved.

  • Page 28: Dimensions

    VCC-HD3N Rev. 905-0160-01 13. Dimensions 935-0065-00 (Unit: mm) ©2018 CIS Corporation. All rights reserved.

  • Page 29: Cases For Indemnity

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
