- Page 1 User Manual https://www.yadea.com...
- Page 2 INDEX Product Intruduction 1.Product Description 2.Function Description How to Use 1.Scooter Assembly 2.Vehicle Activation 3.Battery Charging 4.Folding and Carrying Safety Warning 1.Correct Driving Instructions 2.Safety Instructions Maintenance and After-sales 1.Maintenance and Servicing 2.After-sales Service Appendix 1.Parameter List 2.Troubleshooting 3.Trademark and Legal Statement...
-
Page 3: Product Introduction
When unpacking the electric scooter, please carefully check the contents of the package. If any missing or damaged, please contact local authorized service station or the after-sales E-mail: afterservice03@Yadea.com. It is recommended to retain the outer packaging for at least... - Page 4 PRODUCT INTRODUCTION Instruction to Handlebar Function Description Function Description Function Description Long press the button to turn on/ off Short press * 1 for headlight switch Short press * 2 for gear switch Short press * 3 for metric switch Turn signal button Power on/off the left/right turn signal.
- Page 5 Fault warning In case of fault, the fault icon lights up and the fault code is displayed. Parking Mode Light up if “Bluetooth Parking” is enabled via “Yadea” App. Multifunction button Battery level Display the remaining battery of the scooter.
-
Page 6: Part2 Function Description
PRODUCT INTRODUCTION PART2 Function Description Mode EN17128 Instruction Push Mode; suitable for pushing the scooter to make beginners Pedestrian Mode Multi-function button 6km/h 6km/h familiar with riding. D Mode 15km/h 15km/h Drive Mode; suitable for daily riding. Sports Mode; recommended to use after mastering the riding skills. S Mode 25km/h 32km/h... -
Page 7: Energy Recovery
Gyroscope The “Bluetooth parking” function is disabled by default before delivery, and can be enabled via “Yadea ” APP after the The scooter’s tilting attitude can be detected over the ride. When the body tilts at an angle of 45°, the power supply of scooter is bound. -
Page 8: How To Use
HOW TO USE PART1 Scooter Assembly Installation Steps Lock the screws with the hex wrench within the installation tool. Unfold the stem and secure the folding wrench to stabilize the scooter. Connect the power cable within the handlebar to the After installation completely, plug the charging main line connector of the vertical stem, and install plug into the charging port and connect the... -
Page 9: Activation Procedure
HOW TO USE PART2 Vehicle Activation Activation Procedure 1 Open the “Yadea” APP.Follow the 2、Scan the QR code on the scooter 3 Watch the video “Driving Guide” in its 4 The scooter is activated successfully. prompts on the APP screen to complete entirety, and then click "Activate"... -
Page 10: Part3 Battery Charging
Attention of the folding buckle, hook the folding Please charge the scooter with Yadea original charger, and do not use any charger of other brand and Model. latch of the stem to the buckle to complete the whole folding steps. - Page 11 How to unfold the scooter How to carry the scooter Rotate the wrench to release it from the hook, and lift up the handlebar. Unfold the stem to its maximum position, hold the stem with hand, and press folding handle until the stem is locked. Attention Make sure that the scooter is turned off before carrying Avoid water sources, heavy loads, impacts, severe...
-
Page 12: Safety Warning
Please conduct a basic inspection on the scooter before each ride. If there are obvious abnormalities or abnormal alarm road conditions. sound, do not use the scooter. For any questions, please contact an authorized service station or after-sales E-mail: afterservice03@Yadea.com to obtain professional guidance or maintenance services. - Page 13 SAFETY WARNING PART1 Correct Driving Instructions Learn to Drive 1 Put one foot onto the deck and use the ot EN her 2 When the scooter starts to slide, put both feet on 3 During the ride, release the thumb throttle to slow 4 During steering, slow down and turn the handlebar foot to push off the ground.
-
Page 14: Part2 Safety Instructions
SAFETY WARNING PART2 Safety Instructions Prohibitions for Riding Do not ride in bad weather, or ride in water. Do not hang heavy objects on the handlebar. Do not ride up or down steps or stairs or jump Do not touch the wheel hub, motor or brake system. over obstacles. - Page 15 · The scooter is a recreational product. You need to master riding skills through practice. Yadea Technology Group Co., Ltd. will not be liable for ·...
-
Page 16: Maintenance And Services
· Do not remove the battery by yourself. If there is any problem, please contact the customer service department of Yadea or professional · Do not wash the scooter with pressure water pipe and water gun or clean it with forcefully. -
Page 17: Part2 After-Sales Service
· To the fullest extent permitted by law, YADEA will repair, replace or refund based on actual circumstances. Unless otherwise required by law or otherwise undertaken by YADEA, the warranty shall be limited to the original country of purchase. -
Page 18: Parameter List
APPENDIX Parameter List Parameter List Parts Items Parameters Parts Items Parameters Type Hall BLDC Product model YDX1 Motor Rated power 800W Unfolding size 1220*585*1310mm Basic infor- Maximum output power 1500W mation 1220*585*555mm Type Self-healing tubeless tires Net weight 29kg Tire... -
Page 19: Troubleshooting
· Yadea Technology Group Co., Ltd. reserves all rights. Batteriespannung zu hoch · Yadea Technology Group Co., Ltd. Reserves the copyright of the Manual which shall be reproduced without written permission. · The right of interpretation of this manual belongs to Yadea Technology Group Co., Ltd.
