CARRERA GRANDE
Ceiling Fan Owner's Manual
CF787AW00 -
CF787AP00 -
CF787BS00 -
CF787GBZ00 -
CF787GES00 -
CF787ORB00 -
Net Weight:
Part No. F40BP73770001
Model Numbers
Summer White
Antique Pewter
Brushed Steel
25.3
Lbs.
Gilded Bronze
Golden Espresso
Oil Rubbed Bronze
54", 60" or 72" Fan Blades
™
Not Included
Form No. BP7377-1
U.L. Model No.: CF787
Advertisement
Table of Contents
Related Manuals for Emerson CARRERA GRANDE CF787AW00
Summary of Contents for Emerson CARRERA GRANDE CF787AW00
- Page 1 READ AND SAVE THESE INSTRUCTIONS CARRERA GRANDE ™ Ceiling Fan Owner's Manual Model Numbers CF787AW00 - Summer White CF787AP00 - Antique Pewter CF787BS00 - Brushed Steel CF787GBZ00 - Gilded Bronze CF787GES00 - Golden Espresso CF787ORB00 - Oil Rubbed Bronze 54”, 60” or 72” Fan Blades 25.3 Net Weight: Lbs.
-
Page 2: Safety Instructions
6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know enough about electrical wiring, have your fan installed by a licensed electrician. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 3: Unpacking Instructions
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. 1. Check to see that you have received the following... -
Page 4: Electrical Requirements
Electrical Requirements Your new ceiling fan will require a grounded electrical WARNING supply line of 120 volts AC, 60 Hz, 15 amp circuit. The outlet box must be securely anchored and Turning off wall switch is not sufficient. To avoid capable of withstanding a load of at least 50 pounds. - Page 5 4. The blade flanges have an interlocking feature that 6. Position the switch housing assembly on the must be fully engaged before tightening the screw. switch housing plate and align the holes in the Make sure all the flanges are properly engaged switch housing assembly with the holes in the and then tighten the flange screws.
- Page 6 11. Reinstall the hanger ball (Figure 9) on the NOTE: The setscrews must be properly installed as described above, or fan wobble could result. downrod as follows. Route the three 80” motor leads through the hanger ball. Position the pin through the two holes in the downrod and align WARNING the hanger ball so the pin is captured in the...
-
Page 7: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan 2. Carefully lift the fan and seat the hanger WARNING ball/downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 12). Be The fan must be hung with at least 7' of clearance sure the groove in the ball is lined up with tab on from floor to blades (Figure 10). -
Page 8: How To Wire Your Ceiling Fan
NOTE: CEILING COVER Figure 13 OMITTED FOR CLARITY. THREADED STUD LOCKWASHERS (2) Figure 4 NOTE: If you are using an Emerson Light Fixture KNURLED KNOB with your fan, see Light Fixture Owner’s Manual Figure 14 for wiring. WARNING 2. Securely connect the fan motor white wire to the... -
Page 9: Using Your Ceiling Fan
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. U.L. Model No.: CF787... -
Page 10: Energy Efficient Use Of Ceiling Fans
If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Emerson Turn Off When Not in the Room. Ceiling fans cool Retailer for optional mounting accessories. -
Page 11: How To Order Repair Parts
Repair Parts Listing Model No. Description CF787AW00 CF787BS00 CF787GBZ00 CF787GES00 CF787ORB00 CF787AP00 Hanger Ball Assembly, 761655-21 761655-17 761655-77 761655-35 761655-32 761655-34 Consisting of: Hanger Bracket — — — — — — Hanger Ball — — — — — — Downrod (12”) —... -
Page 12: Limited Warranty
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
