SOFT SIDES
EZWS-EDFP217K
INSTALLER
NOTE: It is common practice to ground electrical hardware such as telephones, computers and other devices
to available water lines. This can, however, cause electrical feedback in the plumbing circuit, which
results in an "electrolysis" effect occurring in the fountain. This may result in water which has a
metallic taste to it or has a noticeable increase in the metallic content of the water.
When inspecting plumbing circuit, remember the line may be grounded some distance from the
installation, and may occur outside the building or area in which the unit is being installed.
This condition can be avoided (in most cases) by using recommended materials during installation.
Any drain fittings provided by the installer should be made of plastic which will electronically isolate
the fountain from the remainder of the building's plumbing circuits.
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
EDFP217WS
INSTALLATION & USE MANUAL
Fountains with FLEXI-GUARD
®
and ezH2O
Review these instructions before beginning installation. Be sure that installation
conforms to all plumbing, electrical and other applicable codes.
When installation is complete, ensure these instructions are left in the plastic bag
provided inside the installed unit for future reference.
Service to be performed by authorized service personnel only.
EDFP217WS*F
Bottle Filler
®
LZWS-EDFP217K
Page 1
®
2000000488 (Rev. A - 04/23)
Advertisement
Table of Contents
Related Manuals for Elkay SOFT SIDES EZWS-EDFP217K
Summary of Contents for Elkay SOFT SIDES EZWS-EDFP217K
- Page 1 Any drain fittings provided by the installer should be made of plastic which will electronically isolate the fountain from the remainder of the building’s plumbing circuits. Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov...
- Page 2 EDFP217WS EDFP217WS*F Figure 1 - Rough-in Dimensions 2000000488 (Rev. B - 04/23) Page 2...
- Page 3 EDFP217WS EDFP217WS*F REQUIRED TOOLS AND MATERIALS TO BUBBLER TO BUBBLER These tables show special tools and/or additional materials (not provided) which are necessary to complete installation of these units: Special Tools Description Quantity Item NONE Additional Materials Not Included Quantity Item Description Unplated copper inlet pipe...
- Page 4 EDFP217WS EDFP217WS*F 8. Install fountains with (8) 5/16-18 HHMS & (8) 5/16-18 nuts 27, 28, 29, (provided) (Fig. 5). Connect the ¼” water lines from each 30 & 31 fountain to the remaining openings on the tee at the remote chiller (cut lines to fit as needed).
- Page 5 EDFP217WS EDFP217WS*F FIVE PIN CONNECTOR MAIN BOARD FOUR PIN CONNECTOR WHITE I.R. BOARD SOLENOID WHITE NEUTRAL Basin BLACK LINE VOLTAGE LED BOARD GROUND Locknut GREEN GROUND FLEXI-GUARD BUBBLER DETAIL ® MALE PLUG FEMALE NOTE: RECEPTACLE When installing replacement bubbler and pedestal, tighten locknut only to hold parts snug in position.
- Page 6 EDFP217WS EDFP217WS*F BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 3) When display shows “UNIT TYPE” push program button once the need to be shut down and restarted.
- Page 7 EDFP217WS EDFP217WS*F DRAIN LOCATION JUNCTION MOUNTING MOUNTING DRAIN FILTER (OPTIONAL) FRAME FRAME LOCATIONS NOTE: NOTE: Bottle filler back cover removed from the view for clarity Figure 8 Figure 9 Page 7 2000000488 (Rev. A - 04/23)
- Page 8 Figure 11 – Quick Connect Fittings FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816 REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640 • ELKAY MANUFACTURING COMPANY • 1333 BUTTERFIELD ROAD • DOWNERS GROVE, IL 60515 • 630.574.8484 www.elkay.com 2000000488 (Rev. B - 04/23) Page 8...
