Elkay EZH2O Refrigerated Floor
Standing Bottle Filling Station,
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
DSSBF8SP DSSBF8SP-W1
Filtered
INSTALLATION MANUAL
Pre-installation steps for Connected
models only
Install Zurn Gateway and Register Product in
1. Install Zurn Gateway (required and sold separately)
per the gateway instructions manual, if an existing
gateway is not within communication range.
2. Be sure the gateway is powered on and connected
(per gateway installation instructions) prior to
installing your bottle filler. Serial number located
on back of the Gateway, is required to register the
gateway to your tenant
3. If you have not already set up an tenant account
and your administrator access, request at
844-987-6737 or
zurnconnectedproducts@zurn.com
4. Log into plumbsmart.zurn.com
5. Register Connected product in plumbSMART
using plumbSMART Registration ID located on
plumbSMART ID Registration Label,
(see Fig. 4, pg. 14). (Watch How-To videos to
get started. Located in the support section inside
the portal.)
Page 1
plumbSMART

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZH2O and is the answer not in the manual?

Questions and answers

Related Manuals for Elkay EZH2O

Summary of Contents for Elkay EZH2O

  • Page 1 DSSBF8SP DSSBF8SP-W1 Elkay EZH2O Refrigerated Floor Standing Bottle Filling Station, Filtered Pre-installation steps for Connected models only Install Zurn Gateway and Register Product in plumbSMART 1. Install Zurn Gateway (required and sold separately) per the gateway instructions manual, if an existing gateway is not within communication range.

  • Page 2: General Information

    In keeping with our policy of continuing technical area at their own discretion and risk. Elkay product improvement, Elkay reserves the right to assumes no responsibility for results obtained or change specification without notice.

  • Page 3: Warranty

    DSSBF8SP DSSBF8SP-W1 2. Safety 1.6 Warranty This product is covered by a Limited Warranty and Elkay Think Safety will not be held responsible for damage of any kind in connection with the installation of the product. THINK SAFETY! Refer to the Elkay website http://www.elkay.com/...

  • Page 4: Personal Protection

    Placing fingers in or around the cutting blades (GFCI). could result in serious personal injury. • If an extension cord is required, always use an OSHA approved extension cord. (630) 574-8484 2000002005 Page 4 Elkay Manufacturing Company (Rev. B - 01/25)
  • Page 5 DSSBF8SP DSSBF8SP-W1 Elkay Manufacturing Company Page 5 (630) 574-8484 2000002005 (Rev. B - 01/25)

  • Page 6: Tools And Supplies

    Fasteners to anchor unit to floor (varies due to flooring surface) Flat washers P-trap with 1-1/2” inlet (single unit) Quarter turn shut-off valve with angled 3/8” outlet (filtered units) (630) 574-8484 2000002005 Page 6 Elkay Manufacturing Company (Rev. B - 01/25)
  • Page 7 Use at least 3/8” O.D. unplated copper tube for supply line. b. Pipe should extend 3” (76mm) maximum from wall. c. Install a quarter-turn, installer supplied, shut-off valve. Elkay Manufacturing Company Page 7 (630) 574-8484 2000002005 (Rev. B - 01/25)
  • Page 8 Note: P-trap is installer supplied part. 3. Remove the lower front panel by removing the two hex screws on the cooler unit using a 5/16” socket or nut driver. Lower Front Panel (630) 574-8484 2000002005 Page 8 Elkay Manufacturing Company (Rev. B - 01/25)
  • Page 9 Note: Filter label should be readable from the front of the filter during installation. MMDDYY Filter Elkay Manufacturing Company Page 9 (630) 574-8484 2000002005 (Rev. B - 01/25)
  • Page 10 5/16” socket or nut driver. Lower Front Panel (630) 574-8484 2000002005 Page 10 Elkay Manufacturing Company (Rev. B - 01/25)

  • Page 11: Cleaning Instruction

    6. Place a towel under the filter to absorb any water that leaks out of the filter when it is removed. Elkay Manufacturing Company Page 11 (630) 574-8484 2000002005 (Rev. B - 01/25)

  • Page 12: Protective Cap

    Note: Filter label should be readable from the front of the filter during installation. Top Cover Filter 17. Install the 4 phillips screws using a phillips screwdriver. 12. Restore power back to the unit. (630) 574-8484 2000002005 Page 12 Elkay Manufacturing Company (Rev. B - 01/25)
  • Page 13 KEEP new and used batteries OUT OF REACH of CHILDREN • Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body. Elkay Manufacturing Company Page 13 (630) 574-8484 2000002005 (Rev. B - 01/25)
  • Page 14 ID Front of Filter Back of Filter Fig. 3 Fig. 4 Scan for trouble shooting and to sign up for auto replenishment of authentic Elkay filters. 3/8” Water Inlet 1 or 2 or 3 Fig. 5 WATERSENTRY® Filter Detail...
  • Page 15 DSSBF8SP DSSBF8SP-W1 Elkay Manufacturing Company Page 15 (630) 574-8484 2000002005 (Rev. B - 01/25)

  • Page 16: Error Description

    DSSBF8SP DSSBF8SP-W1 Enhanced EZH2O Error Codes Error Error Description Corrective Action Code Bottle filler area obstructed Remove obstruction. • Clean lens on IR sensor • Unplug unit for at least 30 seconds and restart • • If error repeats, replace IR sensor...
  • Page 17 Filter Status Bottles Saved Fig 7: Cooler Top View Fig 8: Cooler Front View Filter Status Bottles Saved Fig 10: Rear View Fig 9: Front View with Aerator Elkay Manufacturing Company Page 17 (630) 574-8484 2000002005 (Rev. B - 01/25)
  • Page 18 1000005219 Kit - IR Sensor K+ 1000004573 Kit - Solenoid 120V (BF) 98546C Kit - Aerator Replacement 1000005077 Nameplate - Elkay Filtered 98549C Kit - Hardware & Waterway (BF) 1000004546 Harness - Bottle Filler 1000004549 Harness - LED/IR Board 1000004547...
  • Page 19 This Limited Warranty gives specific legal rights and in some states of the United States there may be other rights which vary from state to state. DATE OF INSTALLATION _________________________ SERIAL NUMBER _________________________ (To Be Filled in By Installer) Form to be left with the owner by the installer. Elkay Manufacturing Company Page 19 (630) 574-8484 2000002005 (Rev. B - 01/25)
  • Page 20 FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816 PRINTED IN U.S.A. REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640 ELKAY MANUFACTURING COMPANY • 1333 BUTTERFIELD ROAD • DOWNERS GROVE, IL 60515 • 630.574.8484 • www.elkay.com (630) 574-8484 2000002005 Page 20 Elkay Manufacturing Company (Rev.
