SET BUTTON
The SET button is used to manually step through the 5 stored output values.
1. While in Measure mode, select either the current or the voltage mode.
2. Short press the Mode button to Select the SOURCE mode.
Press the SET button and the value stored in memory location 01 will be sourced. "MEM.01"
3.
appears in the display.
4. Each press of the SET button will step through the 5 memory locations.
5. The arrow buttons can be used to adjust the value in each memory location.
STEP/MEM BUTTON
The STEP/MEM button is used to automatically step through the 5 stored output values. The meter
can be set for a single cycle of the stored values or a continuous cycle.
1. While in Measure mode, select either the current or the voltage mode.
2. Short press the Mode button to Select the SOURCE mode.
Press and HOLD the STEP/MEM button. "STEPS" (single cycle) and "STEPC" (continuous
3.
cycle) will alternately appear in the display. Release the button when the desired mode is
displayed.
4. In single cycle mode the meter will source the current or voltage displayed in MEM01 for 5
seconds. The meter will then advance to MEM02 for 5 seconds. This will continue through
MEM05 and then step down through the memory locations. The cycle will end when MEM01
has been reached.
5. In the continuous mode the cycle will continue until manually stopped.
Short press the MEM button to stop the cycle. "END" will briefly appear in the display.
6.
STORING VALUES INTO MEMORY
The default values stored in the memory locations are:
Memory
Location
M1
M2
M3
M4
M5
To change the values in memory:
1. While in Measure mode, select either the current or the voltage mode.
2. Short press the Mode button to Select the SOURCE mode.
3. Press the SET button to select the memory location to be changed.
4. Press the arrow buttons to adjust to the new value
5. Short press the MEM button to store the value. The memory location icon will blink while the
value is being stored.
mA
4.00mA
8.00mA
12.00mA
16.00mA
20.00mA
%
0.0%
25%
50%
75%
100%
5
mV
0mV
500mV
1000mV
1500mV
2000mV
PRC15-en-US_V1.5 03/21
V
0V
5V
10V
15V
20V
