INSTALLATION GUIDE FOR ESF18

SAFETY PRECAUTIONS

WARNING - Risk of fire or electric shock. Basic safety precautions should always be
followed when using electrical equipment.
WARNING - This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and operation of the
product and the hazards involved.
WARNING - Disconnect power to all circuits before wiring fixture.
WARNING - Install in accordance with all national, state, and local codes.
WARNING - Do not connect to an ungrounded supply.
WARNING - Read all fixture markings and labels to ensure correct installation of
fixture.
WARNING – Do not apply power to the fixture until the LED Board assembly is
connected to the driver. If power is applied to the fixture prior to connecting the LED
Board assembly to the driver, this will cause the LED Board to fail and void the
warranty.
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) |
www.luminaireled.net
| © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 1 of 3
