INSTALLATION INSTRUCTIONS
Air Conditioner
This air conditioner uses the refrigerant R410A.
Model No.
Indoor Units
Indoor Units
Type
Type
Middle Static
F3
Pressure Duct
Indoor Units
Type
Type
Middle Static
F3
Pressure Duct
ENGLISH
Read through the Installation Instructions before you proceed with the installation.
In particular, you will need to read under the "IMPORTANT!" section at the top of the page.
15
22
S-15MF3E5AN S-22MF3E5AN S-28MF3E5AN S-36MF3E5AN S-45MF3E5AN S-56MF3E5AN S-60MF3E5AN
73
90
S-73MF3E5AN S-90MF3E5AN S-106MF3E5AN S-112MF3E5AN S-140MF3E5AN S-160MF3E5AN
Rated Capacity
28
36
Rated Capacity
106
112
45
56
140
160
WEB-ACXF60-50860-00-EN
60

Advertisement

Table of Contents
loading

Related Manuals for Panasonic S-15MF3E5AN

Summary of Contents for Panasonic S-15MF3E5AN

  • Page 1 This air conditioner uses the refrigerant R410A. Model No. Indoor Units Rated Capacity Indoor Units Type Type Middle Static S-15MF3E5AN S-22MF3E5AN S-28MF3E5AN S-36MF3E5AN S-45MF3E5AN S-56MF3E5AN S-60MF3E5AN Pressure Duct Rated Capacity Indoor Units Type Type Middle Static S-73MF3E5AN S-90MF3E5AN S-106MF3E5AN S-112MF3E5AN S-140MF3E5AN S-160MF3E5AN...

  • Page 2: Table Of Contents

    CONTENTS Page Page IMPORTANT ......3 7. HOW TO INSTALL WIRELESS REMOTE CONTROLLER ....39 Please Read Before Starting NOT E 1.

  • Page 3: Important

    • IMPORTANT! Pay close attention to all warning and caution notices given in this manual. Please Read Before Starting This symbol refers to a hazard or WARNING unsafe practice which can result in This air conditioner must be installed by the sales dealer severe personal injury or death.
  • Page 4 When Transporting • It may need two or more people to carry out the installation work. • Be careful when picking up and moving the indoor and outdoor units. Get a partner to help, and bend your knees when lifting to reduce strain on your back. Sharp edges or thin aluminum fins on the air conditioner can cut your fingers.
  • Page 5 When Connecting Refrigerant Tubing Pay particular attention to refrigerant leakages. WARNING • When performing piping work, do not mix air except for specified refrigerant in refrigeration cycle. It causes capacity down, and risk of explosion and injury due to high tension inside the refrigerant cycle. •...
  • Page 6 Others WARNING • Do not sit or step on the unit. You may fall down accidentally. CAUTION • Do not touch the air inlet or the sharp aluminum fins of the outdoor unit. You may get injured. • Do not stick any object into the FAN CASE. You may be injured and the unit may be damaged.

  • Page 7: General

    1. GENERAL This booklet briefly outlines where and how to install the air conditioning system. Please read over the entire set of instructions for the indoor and outdoor units and make sure all accessory parts listed are with the system before beginning. 1-1.

  • Page 8: Type Of Copper Tube And Insulation Material

    1-3. Type of Copper Tube and Insulation Material If you wish to purchase these materials separately from a local source, you will need: Deoxidized annealed copper tube for refrigerant tubing. Foamed polyethylene insulation for copper tubes as required to precise length of tubing. Wall thickness of the insulation should be not less than 8 mm.

  • Page 9: Site

    2. SELECTING THE INSTALLATION SITE 2-1. Indoor Unit AVOID: ● areas where leakage of flammable gas may be expected. ● places where large amounts of oil mist exist. ● direct sunlight. ● locations near heat sources which may affect the performance of the unit. ●...

  • Page 10: How To Install The Indoor

    3. HOW TO INSTALL THE INDOOR UNIT 3-1. Required Minimum Space for Installation and Maintenance Services ● This air conditioner is usually installed above the ceiling or behind the wall so that the indoor unit and ducts are not visible. Only the air intake and air outlet ports are visible from below. ●...
  • Page 11 < Vertical installation > Duct Inspection access 450 × 450 (Field supply) Grille * Min. 650 Min. Min. 250 Min. 20 Unit: mm • Lower side air intake with duct : 300 mm • Lower side air intake without duct : 200 mm • Front side air intake : 150 mm * Make it possible to open / close for maintenance services for the drain pan, the heat exchanger and filter fixed inlet.
  • Page 12 Detailed dimensions of indoor unit Type Q’ty 15, 22, 28, 36, 45, 56 450 (Pitch 150 × 3) 60, 73, 90 1,067 1,000 750 (Pitch 150 × 5) 106, 112, 140, 160 1,467 1,400 1,050 (Pitch 150 × 7) 1,192 a) Refrigerant tubing joint (liquid tube) b) Refrigerant tubing joint (gas tube) c) Upper drain port VP20 (ø26 mm)

  • Page 13: Preparation Before Installation

    3-2. Preparation Before Installation 3-2-1. Main Types of Installation Case A (Standard installation) Case B Horizontal installation in the ceiling, Horizontal installation in the ceiling, lower rear side air intake side air intake Rear side air intake Lower side air intake Case C Case D Vertical installation on the sidewall, lower...
  • Page 14 Case B and Case D are shown below. For Case B and Case D, replace the cover plates in the procedure shown in the figure. Type 15, 22, 28, 36, 45, 56 Type 60, 73, 90, 106, 112, 140, 160 1.

  • Page 15: Fix The Indoor Unit

    3-3. Fix the Indoor Unit 3-3-1. Horizontal Installation Depending on the ceiling type: a) Insert suspension bolts. b) Use existing ceiling supports or construct a suitable support. Hole-in-anchor Ceiling tiles Concrete Insert Hole-in-plug Ceiling support Suspension bolt (M10 or 3/8”) (field supply) WARNING It is important that you use extreme care in supporting the indoor unit inside the ceiling.
  • Page 16 ● This shows an example of installation. Air outlet duct Bolt anchor Suspension bolt Air outlet grille Indoor unit Ceiling material ● Check to make sure the unit is installed in a horizontal position by using a level. Water leakage may occur if the unit is not installed horizontally. 3-3-2.

  • Page 17: Installing The Drain Pipe

    3-4. Installing the Drain Pipe (1) Prepare standard hard PVC pipe (O.D. 26 mm) for the drain and use the supplied hose band to prevent water leaks. The PVC pipe must be purchased separately. The transparent drain part on the unit allows you to check drainage. CAUTION ●...
  • Page 18 3-4-1. Horizontal Installation NOT E Make sure the drain pipe has a downward gradient (1/100 or more) and that there are no water traps. CAUTION ● Do not install an air bleeder as this may cause water to spray from the drain pipe outlet.
  • Page 19 3-4-2. Vertical Installation ● Replace the drain cap Remove the drain cap from the bottom drain port and reinstall it to the upper drain port. The drain cap can be inserted easily by using a screwdriver or similar tool to push the drain cap into the drain port on the main unit.
  • Page 20 How to make drain pump ineffective and changing heating intake temperature Operating the High-spec Wired Remote Controller (CZ-RTC5B) After completing the address setting under Section “TEST RUN” of the outdoor unit installation instructions, carry out the 20:30 (THU) following procedure. 1.
  • Page 21 Operating the Timer Remote Controller (CZ-RTC4) Setting Item Code “ ” and “ ” 1. Press and hold down the buttons simultaneously for 4 or more seconds. , the unit no., item code and detailed data will blink on the LCD display.) 2.
  • Page 22 Operating the Wired Remote Controller (CZ-RTC6 series) 1. Keep pressing the buttons simultaneously for 4 or more seconds. The “Maintenance func” screen appears on the LCD display. Maintenance func XX / XX ECONAVI nanoeX RC. setting mode Black 2. Press the button to see each menu.
  • Page 23 NOT E Make sure the drain pipe has a downward gradient (1/100 or more) and that there are no water traps. CAUTION ● Do not install an air bleeder as this may cause water to spray from the drain pipe outlet.

  • Page 24: Checking The Drainage

    3-5. Checking the Drainage 3-5-1. Horizontal Installation Only After wiring and drain piping are completed, use the following procedure to check that the water will drain smoothly. For this, prepare a bucket and wiping cloth to catch and wipe up spilled water.

  • Page 25: Connecting Duct To Air Intake Port Side

    3-6. Connecting Duct to Air Intake Port Side (1) Install the duct (field supply). See the figure for the dimension of the installation hole. Use M4 self-tapping screws for installation. Type 15, 22, 28, 36, 45, 56 8-ø3.2 hole For M4 self-tapping screw 80.6 Type 60, 73, 90 12-ø3.2 hole...

  • Page 26: Electrical Wiring

    4. ELECTRICAL WIRING 4-1. General Precautions on Wiring (1) Before wiring, confirm the rated voltage of the unit as shown on its nameplate, then carry out the wiring closely following the wiring diagram under Section 4-3. WARNING (2) This equipment is strongly recommended to be installed with Earth Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD).

  • Page 27: Wire Length And Wire Diameter For Power Supply System

    4-2. Wire Length and Wire Diameter for Power Supply System Indoor unit (B) Power supply cable Type Time delay fuse or circuit capacity Min. 2.5 mm Max. 90 m * 15 A Control wiring (C) Inter-unit (between outdoor and (E) Remote control wiring for group (D) Remote control wiring indoor units) control wiring control...

  • Page 28: Wiring System Diagrams

    4-3. Wiring System Diagrams Indoor unit (No. 1) Power supply ex.) Type MF3 (for Europe) 220-230-240V~ 50-60Hz Outdoor unit Power supply INV unit 380-400-415V 3N~ 50Hz Ground Remote controller Ground Indoor unit (No. 2) Power supply Inter-outdoor-unit control wiring 220-230-240V~ 50-60Hz Ground Power supply Outdoor unit...
  • Page 29 CAUTION (1) When linking the outdoor units in a network, disconnect the terminal extended from the short plug from all outdoor units except any one of the outdoor units. (When shipping: In shorted condition.) For a system without link (no wiring connection between outdoor units), do not remove the short plug.
  • Page 30 WARNING Loose wiring may cause the terminal to overheat or result in unit malfunction. A fire hazard may also occur. Therefore, ensure that all wiring is tightly connected. When connecting each power wire to the terminal, follow the instructions on “How to connect wiring to the terminal”...
  • Page 31 ■ Wiring samples Indoor unit (No. 2) Use this screw when connecting the shield Earth wiring: for the Inter-unit control wiring to ground. Make the earth wiring 25 - 30 mm longer : Functional earthing) than connecting wires to L, N. Remote control wiring for group control Remote control wiring...
  • Page 32 ■ When connecting with 3WAY VRF outdoor unit < In the case of Solenoid Valve Kit (CZ-P56HR3, CZ-P160HR3) + Solenoid Valve Controller (CZ-CAPE2) > Read the Installation Instructions of Solenoid Valve Controller before installation. 1. Install the Solenoid Valve Control PCB as illustrated below. NOTE: Be careful not to pinch the core and wiring when installing the Solenoid Valve Control PCB.
  • Page 33 < In the case of Solenoid Valve Kit (CZ-P456HR3, CZ-P656HR3, CZ-P856HR3, CZ-P4160HR3) > Read the Installation Instructions of Solenoid Valve Kit before installation. Air intake side Solenoid Valve Relay Kit 3-Way connect wire 3WAY (5P, Black) Air intake side...
  • Page 34 ■ When connecting to the optional parts < Connecting to Schedule Timer > Read the Installation Instructions of Schedule Timer before installation. 1. Connect the inter-unit control wiring and Schedule timer communications wiring together. 2. Thread Schedule timer power wiring through the wire saddle and connect it to T10 connector. Wire saddle Schedule timer power wiring...

  • Page 35: How To Process Tubing

    5. HOW TO PROCESS TUBING 5-1. Connecting the Refrigerant Tubing Use of the Flaring Method Many of conventional split system air conditioners employ the flaring method to connect refrigerant tubes that run between indoor and outdoor units. In this method, the copper tubes are flared at each end and connected with flare nuts.

  • Page 36: Connecting Tubing Between Indoor And Outdoor Units

    5-2. Connecting Tubing Between Indoor and Outdoor Units NOT E When connecting to the mini VRF 8HP, 10HP (outdoor units type LE1 only), select the main tube by using the following values. For details, refer to the installation instructions of the outdoor unit. Indoor unit 106 112 140 160 Type F3...

  • Page 37: Insulating The Refrigerant Tubing

    5-3. Insulating the Refrigerant Tubing Tubing Insulation ● Thermal insulation must be applied to all units tubing, Two tubes arranged together including distribution joint (field supply). * For gas tubing, the insulation material must be heat Liquid tube Gas tube resistant to 120°C or above.

  • Page 38: Taping The Tubes

    5-4. Taping the Tubes (1) At this time, the refrigerant tubes (and electrical wiring if local codes permit) should be taped together with armoring tape in 1 bundle. To prevent condensation from overflowing the drain pan, keep the drain hose Clamp separate from the refrigerant tubing.

  • Page 39: How To Install The Timer Remote Controller Or High-Spec Wired Remote Controller

    6. HOW TO INSTALL THE TIMER REMOTE CONTROLLER OR HIGH-SPEC WIRED REMOTE CONTROLLER (OPTIONAL PART) NOT E Refer to the Installation Instructions attached to the optional Timer Remote Controller or optional High-spec Wired Remote Controller. 7. HOW TO INSTALL WIRELESS REMOTE CONTROLLER NOT E Refer to the Installation Instructions attached to the optional Wireless Remote Controller.

  • Page 40: Checklist After Installation

    9. CHECKLIST AFTER INSTALLATION WORK □ Work List Content Check Possibility of Failure & Checkpoint Are the indoor units installed following the □ There is a possibility of light injure or loss of Installation content of Section “2. SELECTING THE property.

  • Page 41: External Static Pressure

    10. EXTERNAL STATIC PRESSURE SETTING For middle static pressure duct type indoor units, the ventilating resistance so-called “external static pressure” becomes greatly different depending on the connected duct length, shape, number of air outlet ports and types of filters. When installing this unit, be sure to carry out the external static pressure setting in order to operate in the rated airflow volume.
  • Page 42 Flow of External Static Pressure Start external static pressure Finish the ducting and electrical wiring and prepare it for use. (Note (1)) setting External static pressure should be set during initial operations after installation (before the cooling and heating test run). When operating with group control (connecting multiple indoor units with one wired remote controller), make the middle static pressure duct type to the main unit.
  • Page 43 2) If multiple air outlets and air inlets are included, adjust the airflow volume ratio of all of them until they meet the design airflow ratio. 3) Make sure the address setting has been completed. (2) The operation check will be completed in approximately three minutes if the settings have been made correctly.

  • Page 44: How To Set On Indoor Unit Control Pcb

    10-1. How to Set on Indoor Unit Control PCB Turn off the power breaker to halt the supply of electricity to the indoor unit control PCB. Open the electrical component box cover, then check the indoor unit control PCB. (Fig. 10-1) Change the dip switch (SW001) of the indoor unit control PCB according to the setting selected in Table 10-1.

  • Page 45: Operating The High-Spec Wired Remote Controller (Cz-Rtc5B)

    10-2. Operating the High-spec Wired Remote Controller (CZ-RTC5B) How to set the external static pressure 1. Keep pressing the buttons 20:30 (THU) simultaneously for 4 or more seconds. The “Maintenance func” screen appears on the LCD display. START Maintenance func 20:30 (THU) 1.
  • Page 46 Table 10-2 Setting the external static pressure Indoor unit type Item code 15, 22, 28, 36, 112, 140, 90, 106 45, 56, 60, 73 External static pressure of the rated airflow volume (Pa) 0010 0009 0008 0007 0006 0005 0004 40 * 50 * 0003...
  • Page 47 Change the display from “OFF” to “ON” by pressing the Test run 20:30 (THU) button. Test run Then press the button. Change ] Confirm The “Maintenance func” screen appears on the LCD Maintenance func 20:30 (THU) 1. Outdoor unit error data display.

  • Page 48: Operating The Timer Remote Controller (Cz-Rtc4)

    10-3. Operating the Timer Remote Controller (CZ-RTC4) 10-3-1. Setting Item Code “ ” 1. Press and hold down the buttons simultaneously for 4 or more seconds. , the unit no., item code and detailed data will blink on the LCD display.) 2.
  • Page 49 10-3-2. Auto Airflow Volume Control Operations and External Static Pressure Setting- Check Operation 1. Press and hold down the button for 4 or more seconds. “ ” will be displayed on the LCD display. ° 2. Press the button to start the test run. °...

  • Page 50: Operating The Wired Remote Controller (Cz-Rtc6 Series)

    10-4. Operating the Wired Remote Controller (CZ-RTC6 series) Stop the system before performing these steps. How to set the external static pressure 1. Keep pressing the buttons simultaneously for 4 or more seconds. The “Maintenance func” screen appears on the LCD display.
  • Page 51 Table 10-4 Setting the external static pressure Indoor unit type Item code 15, 22, 28, 36, 112, 140, 90, 106 45, 56, 60, 73 External static pressure of the rated airflow volume (Pa) 0010 0009 0008 0007 0006 0005 0004 40 * 50 * 0003...
  • Page 52 The “Maintenance func” screen appears on the LCD display. Maintenance func XX / XX Test run Sensor info. Service check 9. Press the button. TEST “TEST” will be displayed on the LCD display. 10. Press the button. Test run will be started. TEST Test run setting mode screen appears on the LCD display.
  • Page 53 External static pressure 130Pa, 50Pa Indoor Units Type 15, 22, 28 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa...
  • Page 54 External static pressure 130Pa, 50Pa Indoor Units Type 36, 45 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa...
  • Page 55 External static pressure 130Pa, 50Pa Indoor Units Type 56 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa Airflow Volume (m...
  • Page 56 External static pressure 130Pa, 50Pa Indoor Units Type 60, 73 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa...
  • Page 57 External static pressure 130Pa, 40Pa Indoor Units Type 90 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Limit line Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa...
  • Page 58 External static pressure 130Pa, 40Pa Indoor Units Type 106 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa Airflow Volume (m...
  • Page 59 External static pressure 130Pa, 50Pa Indoor Units Type 112, 140 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa...
  • Page 60 External static pressure 130Pa, 50Pa Indoor Units Type 160 Indoor Fan Performance PQ diagram (Fig. 10-2) External static pressure 150Pa, 90Pa Airflow Volume (m /minute) External static pressure 120Pa, 30Pa Airflow Volume (m /minute) External static pressure 140Pa, 70Pa Airflow Volume (m /minute) External static pressure 110Pa, 10Pa Airflow Volume (m...

  • Page 61: Appendix

    11. APPENDIX ■ Care and Cleaning WARNING ● For safety, be sure to turn the air conditioner off and also to disconnect the power before cleaning. ● Do not pour water on the indoor unit to clean it. This will damage the internal components (fan motor, etc.) and cause an electric shock hazard.
  • Page 62 CAUTION ● Certain metal edges and the condenser fins are sharp and may cause injury if handled improperly; special care should be taken when you clean these parts. ● Periodically check the outdoor unit to see if the air outlet or air intake is clogged with dirt or soot.

  • Page 63: Troubleshooting

    ■ Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or a service center. ● Indoor unit Symptom Cause ● Sound of refrigerant liquid flowing inside unit Noise Sound like streaming water during ●...
  • Page 64 ● Check Before Requiring Services Symptom Cause Remedy Air conditioner does not run at Power failure or after power failure Press ON/OFF operation button on remote all although power is turned controller again. ● Switch on power if breaker is turned off. Operation button is turned off.

  • Page 65: Important Information Regarding The Refrigerant Used

    ■ Tips for Energy Saving Avoid ● Do not block the air intake and outlet of the unit. If either is obstructed, the unit will not work well, and may be damaged. ● Do not let direct sunlight into the room. Use sunshades, blinds or curtains. If the walls and ceiling of the room are warmed by the sun, it will take longer to cool the room.
  • Page 66 WEB-ACXF60-50860-00-EN DC0223-0...
