Middle Static Pressure Duct
<At horizontal installation>
<At vertical installation>
Model No.
INDOOR UNIT
Middle Static Pressure Duct
(Type F3)
S-15MF3E5AN
S-73MF3E5AN
S-22MF3E5AN
S-90MF3E5AN
S-28MF3E5AN
S-106MF3E5AN
S-36MF3E5AN
S-112MF3E5AN
S-45MF3E5AN
S-140MF3E5AN
S-56MF3E5AN
S-160MF3E5AN
S-60MF3E5AN
● Connectable outdoor unit lineup
This booklet is the operating
instructions for indoor unit. Regarding
the outdoor unit, see the operating
instructions supplied with the outdoor
unit.
OUTDOOR UNIT
Refrigerant type : R410A
mini VRF (Type LE1, LE2)
2WAY VRF (Type ME2)
3WAY VRF (Type MF3)
(Type F3)
ENGLISH
Before operating the unit, read these operating instructions thoroughly and
keep them for future reference.
Panasonic Corporation
1006, Oaza Kadoma, Kadoma City,
Osaka 571-8501, Japan
Operating Instructions
Air Conditioner
WEB-ACXF55-35940-00-EN
Advertisement
Table of Contents
Related Manuals for Panasonic S-15MF3E5AN
Summary of Contents for Panasonic S-15MF3E5AN
- Page 1 <At horizontal installation> ENGLISH Before operating the unit, read these operating instructions thoroughly and keep them for future reference. <At vertical installation> Model No. INDOOR UNIT Middle Static Pressure Duct (Type F3) S-15MF3E5AN S-73MF3E5AN S-22MF3E5AN S-90MF3E5AN S-28MF3E5AN S-106MF3E5AN S-36MF3E5AN S-112MF3E5AN S-45MF3E5AN...
-
Page 2: Table Of Contents
Thank you for purchasing this Panasonic product. Safety Precautions This product is a commercial air conditioner indoor unit. Installation Instructions attached. The following symbols used in this manual, alert you to Contents potentially dangerous conditions to users, service personnel or... - Page 3 WARNING If the refrigerant comes in contact Do not use modified with a flame, it produces toxic cord, joint cord, gases. extension cord or unspecified cord to prevent For safety, be sure to turn the overheating and fire. air conditioner off and also to disconnect the power before cleaning or servicing.
- Page 4 CAUTION This appliance is intended to be used Do not turn the air conditioner on by expert or trained users in shops, and off from the power mains switch. in light industry and on farms, or for Use the ON/OFF operation button. commercial use by lay persons.
-
Page 5: Precautions For Use
Precautions for Use Installation Disposal of Old Equipment Only for European Union and countries with This air conditioner must be installed properly by qualified recycling systems installation technicians in accordance with the Installation This symbol on the products, packaging, and/ Instructions provided with the unit. -
Page 6: Names Of Parts
Names of Parts INDOOR UNIT (Middle Static Pressure Duct) Type F3 At standard installation (Horizontal installation in the ceiling, rear side air intake) Air outlet duct * Suspension bolt * Indoor unit Ceiling material * Air-outlet grille * * Field supplied OUTDOOR UNIT mini VRF (Type LE1, LE2) 2WAY VRF (Type ME2) -
Page 7: Maintenance
Maintenance „ Outdoor unit WARNING The internal coil and other components of the outdoor unit must be cleaned periodically. For safety, be sure to turn the air conditioner off and disconnect • Consult your dealer or service center. the power before cleaning. (Otherwise, electric shock or injury may result because the fan is rotating at high speed.) Do not pour water on the indoor unit. -
Page 8: Nanoe™ X Function
nanoe™ X Function Display during operation of nanoe™ X Example: Initial screen of remote controller CZ-RTC5B CZ-RTC6 series room A 20:30 (THU) SET TEMP. MODE FAN SPEED COOL °C °C °C FLAP : Under operation of nanoe™ X : Under operation of nanoe™ X Definition of nanoe™ X nanoe™... -
Page 9: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation •... -
Page 10: Before Requesting Services
Troubleshooting Before Requesting Services Symptom Cause Action Power failure or after power failure Press the power ON/OFF button on the remote controller. The air conditioner does • If the breaker is turned off, turn the power on. not operate The operation (power) button is turned off. •... -
Page 11: Connectable Outdoor Unit
Connectable Outdoor Unit Europe Outdoor unit type 4 HP 5 HP 6 HP 8 HP 10 HP 1-phase U-4LE2E5 U-5LE2E5 U-6LE2E5 – – 3-phase U-4LE2E8 U-5LE2E8 U-6LE2E8 – – 3-phase U-8LE1E8 U-10LE1E8 – – – 3-phase U-8ME2E8 U-10ME2E8 – – –... -
Page 12: Specifications
Middle Static Pressure Duct Model Name Model Name S-15MF3E5AN S-22MF3E5AN S-28MF3E5AN S-36MF3E5AN S-45MF3E5AN S-56MF3E5AN S-15MF3E5AN S-22MF3E5AN S-28MF3E5AN S-36MF3E5AN S-45MF3E5AN S-56MF3E5AN 220 - 230 - 240 V～ 50 - 60 Hz 220 - 230 - 240 V～ 50 - 60 Hz... - Page 13 Specifications Indoor unit Indoor unit Middle Static Pressure Duct Model Name S-60MF3E5AN S-73MF3E5AN S-90MF3E5AN 220 - 230 - 240 V～ 50 - 60 Hz Power source Cooling capacity 20,500 24,900 30,700 BTU/h Sensible Latent 10.0 Heating capacity 24,200 27,300 34,100 BTU/h Cooling electric 0.079...
- Page 14 Specifications Specifications Indoor unit Indoor unit Middle Static Pressure Duct Model Name S-106MF3E5AN S-112MF3E5AN S-140MF3E5AN S-160MF3E5AN 220 - 230 - 240 V～ 50 - 60 Hz Power source 10.6 11.2 14.0 16.0 Cooling capacity 36,200 38,200 47,800 54,600 BTU/h 11.0 Sensible Latent 11.4...
-
Page 15: Outdoor Unit
Specifications Outdoor unit mini VRF (Type LE1, LE2) 2WAY VRF (Type ME2) 3WAY VRF (Type MF3) NOTE Refer to the Operating Instructions attached to the outdoor unit. - Page 16 Customer care number ( Toll free ) : 1800 103 1333 ,1800 108 1333 Please see the Panasonic website for further information on collection centers, etc. or call the customer care toll-free number http://www.panasonic.com/in/corporate/sustainability/panasonic-india-i-recycle-program.html Do’s & Don’ts: E-waste (Management) Amendment Rules 2018 S.No.
