  • Page 1 File version: V1.2 Solar Hybrid Inverter User Manual Product Models HES4840S100-H ｜ HES4846S100-H ｜ HES4850S100-H HES4855S100-H ｜ HES4860S100-H SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 1 of 37 F: +86 0755-27325578...
  • Page 2  the only input equipment and it is forbidden to use it in parallel with any other input AC power source so as to avoid damage. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 3: Table Of Contents

    6.2 Meaning of Fault Code ..............................32 6.3 Partial Troubleshooting Measures ..........................33 7. System Maintenance ..........................34 8. Technical Parameters ..........................35 SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 3 of 37 F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 4: General Information

    16. Adopt intelligent adjustable speed fan to dissipate heat efficiently and prolong the service life of the system. 17. Complete short circuit protection, over-voltage and under-voltage protection, overload protection and backfeed SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 5: Introduction To The Basic System

    The specific system wiring mode is determined by the actual application scenario. PV array Generator Utility Home Appliances External Battery packs SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 5 of 37 F: +86 0755-27325578...

  • Page 6: Product Features

    ⑤ Battery terminal Overload protector ⑥ ⑬ AC output CAN communication port ⑦ AC input SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 6 of 37 F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 7: Dimensional Diagram

    File version: V1.2 1.4 Dimensional Diagram Location of Mounting Holes SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 7 of 37 F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 8: Installation Instructions

    PV input current. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 9 125A 100A 2P—200A HES4855S100-H 130A 100A 2P—200A 30mm /2AWG HES4860S100-H 30mm /2AWG 135A 100A 2P—200A SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 9 of 37 F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 10: Installation And Wiring

    Danger of Explosion! NEVER install the Inverter and the lead-acid liquid battery in the same confined space! Do Not install in a confined space where the battery gas may accumulate. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 11 File version: V1.2 Step 2: Open 4 holes in the wall according to the following dimensions, and knock in expansion screws, as shown in the following figure: SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 12 File version: V1.2 Step 3: Hang up the machine and tighten the screws. Step 4: Remove the terminal protection cover. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 12 of F: +86 0755-27325578...
  • Page 13 L: Live Wire N: Neutral Wire : Ground Wire SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 14 O-terminal must firmly compress BAT wire to prevent excessive heating caused by excessive contact impedance; According to the cable sequence and terminal position shown in the following figure, connect the BAT wire properly. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 15 Pay attention to safety in the process of wiring; Do Not close the circuit breaker or fuse, and ensure the "+" and "-"pole leads of each component be connected properly in the process of wiring; the circuit breaker must be SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 16 Note: If the inverter is not working properly or the LCD or indicator light displays abnormally, please refer to Chapter 6 for troubleshooting. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 17: Working Mode

    4. Only Solar: Only PV charging, no mains charging is initiated. This is the most energy-efficient mode and the battery power comes from solar energy, which is usually used in regions with good daylighting conditions. 3.2 Output Mode SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 18: Lcd Screen Operating Instructions

    Hybrid Function: when the battery is not connected or fully charged, the load is powered with the hybrid of PV and Mains Power, with the maximum output power of PV output. 4. LCD Screen Operating Instructions SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 19: Operation And Display Panel

    CHARGE Green Normally On: The charging is completed. FAULT Normally On: Fault status 4.4 Introduction to LCD Screen SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 19 of F: +86 0755-27325578...
  • Page 20 Surveillance Equipment Indicates that the current battery type of Indicates that the battery is fully charged the machine is user-defined SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 20 of F: +86 0755-27325578 W: www.srnesolar.com...
  • Page 21 Setting Interface: display setting contents Real-time data viewing method On the LCD main screen, press the button for page turning to view the real-time data of the machine. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 22: Description Of Setting Parameters

    Reserved 4.5 Description of Setting Parameters Key Operation Instructions: Enter the setting menu and exit the set ting menu, please press , After entering SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 23 The Mains Power is charged first, and PV charging is [06] AC1ST started only when the Mains Power has failed SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 23 of F: +86 0755-27325578 W: www.srnesolar.com...
  • Page 24 [14] 44V Default alarm point alarm will be given, the output will not be shut down, with the Set Range of 40V~52V, Step of 0.4V. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 25 [24] ENA Default over-temperature occurs, shut down output, and restart output after the temperature has dropped. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 25 of F: +86 0755-27325578...
  • Page 26 1-section start [40] 00:00:00 Default Set Range: 00: 00-23: 59: 00 charging time SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 26 of F: +86 0755-27325578...
  • Page 27 Set Range: 00:01: 01-99:12:31 Current date setting [55] 00:00:00 Default Set Range: 00:00: 00-23:59: 59 Current time setting SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 27 of F: +86 0755-27325578...
  • Page 28 Switch to inverter output default than or equal to this setting (valid when BMS [62] 100％ SOC Settings communication is normal) SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 28 of F: +86 0755-27325578...

  • Page 29: Battery Type Parameter List

    (adjustable) 0~250d Equalization charging interval (adjustable) 10~600min Boost duration 120 min. 120 min. 120 min. (adjustable) SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 29 of F: +86 0755-27325578 W: www.srnesolar.com...
  • Page 30 Adjustable for 10~600min Boost duration 120 min 120 min 120 min 120 min 120 min (adjustable) SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 30 of F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 31: Other Functions

    5.4 CAN Communication Interface Communication port can communicate with lithium battery BMS (need to be customized), terminal left interface CANL, terminal right interface CANH. SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...

  • Page 32: Protection

    AC back-feed protection mode） Bypass over-current Built-in AC input overcurrent protection circuit breaker. protection 6.2 Meaning of Fault Code SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 32 of F: +86 0755-27325578...

  • Page 33: Partial Troubleshooting Measures

    【29】 BusVoltLow Low bus voltage protection 【57】 LeakageCurrOver Leak current OOS protection 6.3 Partial Troubleshooting Measures SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 33 of F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 34: System Maintenance

    Bypass AC Input input relay switch is short-circuited, and you need to contact the manufacturer to replace it. 7. System Maintenance SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 34 of F: +86 0755-27325578 W: www.srnesolar.com...

  • Page 35: Technical Parameters

    Disassembling and repair of the inverter without permission. Damage caused by force majeure: damage occurred during transportation or loading and unloading of the inverter. 8. Technical Parameters SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com...
  • Page 36 40Vdc-60Vdc ± 0.6 Vdc (under--voltage alarm/shutdown voltage/over-voltage Battery voltage range alarm/over-voltage recovery … LCD screen can be set) Power saving mode Non-ECO mode ≤100W; ECO mode ≤50W SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 36 of F: +86 0755-27325578 W: www.srnesolar.com...
  • Page 37 Google browser,scan the QR code to download the APP  In the Google Play Store, search for "SmartESS" to download and install  SRNE Solar Co., Ltd. 4-5F,13A Wutong Island, Neihuan Road, Xixiang, Shenzhen,China T: +86 0755-26458295 E: master@szshuori.com Page 37 of F: +86 0755-27325578 W: www.srnesolar.com...
