8. DISPLAY

The icons on the left of the screen show basic information about how the system is
operating, while the centre and right of the screen will cycle through the information
for the solar, battery and load circuits including displaying voltage, current, power, total
power, battery percentage and more.
ICON INFO
DAY TIME
– SOLAR IS
RECEIVING
SUN LIGHT
NIGHT TIME –
SOLAR IS NOT
RECEIVING
SUN LIGHT
V1.7
ICON INFO
NOT
CHARGING
CHARGING
ICON INFO
NOT
DISCHARGING
THROUGH
LOAD CIRCUIT
DISCHARGING
THROUGH
LOAD CIRCUIT
