6. WIRING REQUIREMENTS

• Suggested wire size
Max. PV Input Current
10A
20A
30A
Rated Charge / Load
Current
10A
20A
30A
• The Adventure Kings Plus MPPT Solar Charge Controller / Regulator is a common-
negative controller, meaning all negative terminals are shared. The suggested method
is to wire the battery, and loads and solar panels to the unit. If instead another earth
point is used in the vehicle, the unit should also be earthed with the earth terminal on
the heatsink.
• Do not connect high power devices such as inverters through the load circuit of the
MPPT Controller.
V1.7
Suggested Solar Wiring
Size
12AWG / 4mm2
10AWG / 6mm2
8AWG / 10mm2
Suggested Battery
Wiring Size
10AWG / 6mm2
10AWG / 6mm2
8AWG / 10mm2
Suggested Load Wiring
Size
12AWG / 4mm2
10AWG / 6mm2
8AWG / 10mm2
