CHANGING TEMPERATURE UNITS (°C TO °F)
Step 1 – Start with the unit on the HOME SCREEN
Step 2 – Press the SET button to enter battery settings interface
Step 3 – Press and hold the BATT button to enter battery type interface
Step 4 – Press the SET button 2x to jump to temperature units interface
Step 5 – Press the + or – buttons (PV/+ or LOAD/-) to set temperature units °C or °F
Step 6 – Press SET to confirm selection and return to battery parameter menu

ADJUST HOME MENU LCD CYCLE TIME

The default cycle time for the home screen is 2 seconds. This can be set from 0 seconds
(no cycling) to 20 seconds. If set to 0 Seconds, you're able to choose which parameters
will stay on your home screen*.
Step 1 – Start with the unit on the HOME SCREEN
Step 2 – Press the SET button to enter PV settings interface
Step 3 – Press and hold the PV button to enter LCD Cycle Time Menu Step 4 – Press
the + or – buttons (PV/+ or LOAD/-) to set from 0~20
Step 4 – Press SET to confirm selection
* Once 0 Seconds has been selected, exit to the home screen by pressing ESC x 2
or wait 10 seconds. Now to set your own home screen display parameters, press the
corresponding button (PV, BATT or LOAD) until the desired parameter is shown.

ADJUST LOAD TYPE / TIMER

The Adventure Kings Plus Solar Charge Controller / Regulator has two sophisticated load
settings available – users can set the load to turn on or off for certain time periods
at certain times or turn on and off manually.
Step 1 – Start with the unit on the HOME SCREEN
Step 2 – Press the SET button to enter load settings interface
Step 3 – Press and hold the LOAD button to enter load type interface
Step 4 – Press the + or – buttons (PV/+ or LOAD/-) to set load type (see table below)
Step 5 – Press SET to confirm selection then SET again to return to battery
parameter menu
